Kawasaki Vulcan 1600 Nomad - 2009 Specifications and Reviews

Not Rated stars Average rating: Not Rated from 0 votes
.

General information

Category:Touring
Year:2009
Model:Kawasaki Vulcan 1600 Nomad


Engine and Transmission Specifications

Transmission typefinal drive:Shaft drive (cardan)
Gearbox:5-speed
Cooling system:Liquid
Ignition:TCBI dual plug with digital advance
Fuel control:SOHC
Valves per cylinder:4
Fuel system:Injection
Bore x stroke:102.0 x 95.0 mm (4.0 x 3.7 inches)
Compression:9.0:1
Stroke:4
Engine type:Single cylinder
Capacity:1552.00 ccm (94.70 cubic inches)

Physical measures and capacities

Wheelbase:1,689 mm (66.5 inches)
Overall length:2,515 mm (99.0 inches)
Seat height:719 mm (28.3 inches) If adjustable, lowest setting.
Dry weight:350.2 kg (772.0 pounds)

Kawasaki Vulcan 1600 Nomad dimensions and frame

Rear brakes:Single disc
Front brakes:Double disc
Rear tyre dimensions:170/70-16
Front tyre dimensions:150/80-16
Rear suspension:Dual air-assisted shocks with four-way rebound damping / 3.9 in.
Front suspension:41mm hydraulic fork / 5.9 in.
Rake (fork angle):32.0°
Frame type:High-tensile steel, double cradle


Speed and acceleration

Color options:Metallic Diablo Black, Two-Tone: Metallic Ocean Blue / Neutron Silver, Two-Tone: Candy Fire Red / Metallic Diablo Black
Fuel capacity:20.06 litres (5.30 gallons)
