Kawasaki Vulcan 1700 Vaquero ABS SE - 2014 Specifications and Reviews
The 2014 Kawasaki Vulcan 1700 Vaquero ABS SE is a heavyweight cruiser touring bike ideal for riders seeking comfortable long-distance travel. Powered by a 1700cc V-twin engine delivering strong low-end torque, it combines classic styling with modern amenities including ABS and fuel injection. Best known for its relaxed ergonomics and highway-focused performance, it suits experienced cruiser enthusiasts prioritizing comfort and reliability.
General information | |
| Category | Touring |
| Year | 2014 |
| Model | Kawasaki Vulcan 1700 Vaquero ABS SE |
Engine and Transmission Specifications | |
| Transmission type,final drive | Belt |
| Gearbox | 6-speed |
| Cooling system | Liquid |
| Lubrication system | Semi-dry sump |
| Ignition | TCBI with Digital Advance |
| Fuel control | SOHC |
| Fuel system | Injection. DFI with dual 42mm throttle bodies |
| Valves per cylinder | 4 |
| Bore x stroke | 102.0 x 104.0 mm (4.0 x 4.1 inches) |
| Compression | 9.5:1 |
| Torque | 146.45 Nm (14.9 kgf-m or 108.0 ft.lbs) @ 2750 |
| Engine details | 52° V-twin |
| Engine type | V2, four-stroke |
| Capacity: | 1700.00 ccm (103.73 cubic inches) |
| | |
Brakes, suspension, Frame and wheels | |
| Rear brakes diameter | 300 mm (11.8 inches) |
| Rear brakes | Single disc |
| Front brakes diameter | 300 mm (11.8 inches) |
| Front brakes | Double disc. ABS. Two-piston calipers. |
| Rear tyre dimensions | 170/70-16 |
| Front tyre dimensions | 130/90-16 |
| Rear suspension travel | 79 mm (3.1 inches) |
| Rear suspension | Swingarm with twin air-assisted shocks, with 4-way rebound damping |
| Front suspension travel | 140 mm (5.5 inches) |
| Front suspension | 45mm hydraulic fork |
| Trail | 178 mm (7.0 inches) |
| Rake (fork angle) | 30.0° |
| Frame type | Steel, double-cradle with box-section single-tube backbone |
Physical measures and capacities | |
| Fuel capacity | 20.06 litres (5.30 gallons) |
| Wheelbase | 1,666 mm (65.6 inches) |
| Ground clearance | 145 mm (5.7 inches) |
| Overall width | 970 mm (38.2 inches) |
| Overall length | 2,510 mm (98.8 inches) |
| Overall height | 1,290 mm (50.8 inches) |
| Seat height | 729 mm (28.7 inches) If adjustable, lowest setting. |
| Weight incl. oil, gas, etc | 383.1 kg (844.5 pounds) |
Other specs | |
| Light | 30W halogen headlights / 5W taillight / 18W stoplight |
| Instruments | Speedometer, odometer, clock, fuel gauge and coolant temp light |
| Wheelbase | 1,255 mm (49.4 inches) |
| Rear tyre | 25/10-12 |
| Front tyre | 25/8-12 |
| Rear Suspension | Swingarm with single shock, preload adjustment / 7.1 in. |
| Front Suspension | MacPherson strut / 6.7 in. |
| Driveline | Selectable four-wheel drive with Variable Front Differential Control, shaft |
| Bore x Stroke | 80.0 x 72.0 mm (3.1 x 2.8 inches) |
| Compression | 8.3:1 |
| Model | Kawasaki Prairie 360 4x4 |
| Comments | Electronic cruise control. Feature-rich, AM/FM/WB audio system with iPod and XM radio compatibility. |
| Color options | Candy Burnt Orange |
| Factory warranty | 36 months |
| Carrying capacity | Saddle bags |
| Starter | Electric |
Rider Reviews
Add a Comment
Related Motorcycle Specifications
More Kawasaki Motorcycles
Related Variants
2024 Kawasaki Vulcan 1700 Vaquero ABS
2023 Kawasaki Vulcan 1700 Vaquero ABS
2020 Kawasaki Vulcan 1700 Vaquero ABS
2019 Kawasaki Vulcan 1700 Vaquero ABS
2018 Kawasaki Vulcan 1700 Vaquero ABS
2017 Kawasaki Vulcan 1700 Vaquero ABS
2016 Kawasaki Vulcan 1700 Vaquero ABS
2015 Kawasaki Vulcan 1700 Vaquero ABS
2014 Kawasaki Vulcan 1700 Vaquero ABS
2012 Kawasaki Vulcan 1700 Vaquero
⚠ Safety Recalls (1)
Kawasaki Motors Corp., U.S.A. (Kawasaki) is recalling certain model year 2009-2015 Vulcan 1700 Voyager and 2011-2015 Vulcan 1700 Vaquero motorcycles manufactured February 2, 2009, to March 20, 2015. In the affected vehicles, an ignition wire may chafe due to contact with the fuel tank, resulting in a short circuit and possible engine stall.
Risk: An engine stall increases the risk of a crash.
Remedy: Kawasaki will notify owners, and dealers will install additional shielding and padding to prevent the ignition wire from shorting. Any igniton switch that has damaged wires will be replaced. These repairs will be performed free of charge. The recall began on September 15, 2015. Owners may contact Kawasaki customer service at 1-866-802-9381. Kawasaki's number for this recall is MC15-10.
Source: NHTSA. View all Kawasaki recalls →
