Kawasaki Vulcan 1700 Vaquero ABS SE - 2014 Specifications and Reviews
2014
General information | |
| Category: | Touring |
| Year: | 2014 |
| Model: | Kawasaki Vulcan 1700 Vaquero ABS SE |
Engine and Transmission Specifications | |
| Transmission type,final drive: | Belt |
| Gearbox: | 6-speed |
| Cooling system: | Liquid |
| Lubrication system: | Semi-dry sump |
| Ignition: | TCBI with Digital Advance |
| Fuel control: | SOHC |
| Fuel system: | Injection. DFI with dual 42mm throttle bodies |
| Valves per cylinder: | 4 |
| Bore x stroke: | 102.0 x 104.0 mm (4.0 x 4.1 inches) |
| Compression: | 9.5:1 |
| Torque: | 146.45 Nm (14.9 kgf-m or 108.0 ft.lbs) @ 2750 |
| Engine details: | 52° V-twin |
| Engine type: | V2, four-stroke |
| Capacity: | 1700.00 ccm (103.73 cubic inches) |
Brakes, suspension, Frame and wheels | |
| Rear brakes diameter: | 300 mm (11.8 inches) |
| Rear brakes: | Single disc |
| Front brakes diameter: | 300 mm (11.8 inches) |
| Front brakes: | Double disc. ABS. Two-piston calipers. |
| Rear tyre dimensions: | 170/70-16 |
| Front tyre dimensions: | 130/90-16 |
| Rear suspension travel: | 79 mm (3.1 inches) |
| Rear suspension: | Swingarm with twin air-assisted shocks, with 4-way rebound damping |
| Front suspension travel: | 140 mm (5.5 inches) |
| Front suspension: | 45mm hydraulic fork |
| Trail: | 178 mm (7.0 inches) |
| Rake (fork angle): | 30.0° |
| Frame type: | Steel, double-cradle with box-section single-tube backbone |
Physical measures and capacities | |
| Fuel capacity: | 20.06 litres (5.30 gallons) |
| Wheelbase: | 1,666 mm (65.6 inches) |
| Ground clearance: | 145 mm (5.7 inches) |
| Overall width: | 970 mm (38.2 inches) |
| Overall length: | 2,510 mm (98.8 inches) |
| Overall height: | 1,290 mm (50.8 inches) |
| Seat height: | 729 mm (28.7 inches) If adjustable, lowest setting. |
| Weight incl. oil, gas, etc: | 383.1 kg (844.5 pounds) |
Other specs | |
| Light: | 30W halogen headlights / 5W taillight / 18W stoplight |
| Instruments: | Speedometer, odometer, clock, fuel gauge and coolant temp light |
| Wheelbase: | 1,255 mm (49.4 inches) |
| Rear tyre: | 25/10-12 |
| Front tyre: | 25/8-12 |
| Rear Suspension: | Swingarm with single shock, preload adjustment / 7.1 in. |
| Front Suspension: | MacPherson strut / 6.7 in. |
| Driveline: | Selectable four-wheel drive with Variable Front Differential Control, shaft |
| Bore x Stroke: | 80.0 x 72.0 mm (3.1 x 2.8 inches) |
| Compression: | 8.3:1 |
| Model: | Kawasaki Prairie 360 4x4 |
| Comments: | Electronic cruise control. Feature-rich, AM/FM/WB audio system with iPod and XM radio compatibility. |
| Color options: | Candy Burnt Orange |
| Factory warranty: | 36 months |
| Carrying capacity: | Saddle bags |
| Starter: | Electric |
