Cruisers

2009Kawasaki Vulcan 1700 Voyager

Rate this bike

43 fields on record

The 2009 Kawasaki Vulcan 1700 Voyager is a cruiser-touring machine designed for riders seeking comfortable long-distance travel. Powered by a 1700cc V-twin engine producing substantial low-end torque, it excels at highway cruising with its relaxed riding position and generous cargo capacity. Known for blending cruiser styling with practical touring amenities, it appeals to experienced riders prioritizing comfort on extended journeys.

Capacity: 1700.0 ccm
Engine: V-Twin, four-stroke
Gearbox: 6-speed
Wet weight: 401.9 kg
Seat height: 729 mm
Power: 73.0 HP (53.7 kW)

⇄ Compare with another bike All model years ⚠ Recalls listed (1)

Other years 2009 2010 2011 2012 2013 2014 2015 2016 2017 2018 2019 2020 2021 2022 2023 2024

How it rides

Editorial estimate from the spec sheet - not lab tested

Off-road & trail5%

Cornering30%

City riding35%

Daily riding55%

Touring95%

Two-up90%

Track5%

Best for: Built for effortless long-distance highway touring with a passenger and full luggage rather than sporty riding.
Built for: Appeals to laid-back cruiser riders who value low-RPM torque, relaxed ergonomics, and a classic V-twin soundtrack over outright speed or agility.
Not ideal for: Not a good fit for riders seeking sharp cornering ability, off-road capability, or a lightweight, nimble city commuter.

Scores are derived from the spec sheet using the same model across every bike, so they compare like for like.

Will it fit you?

Worked out in your browser - nothing is sent to us

Your height

Inseam (optional)

Units

At 729mm, a rider of 175cm with a 79cm (estimated) inseam will reach the ground with both feet flat on the 2009 Kawasaki Vulcan 1700 Voyager, with a cramped knee angle of around 80 degrees and an upright riding position.

Assumes about 30mm of suspension sag once seated. This is an approximation from category-typical geometry, not a measurement of this bike or of you - sit on one before you buy.

More bikes at 750 mm or under — Short Kings →

Find bikes that fit your height →

Full specifications

Engine

Capacity: 1700.0 ccm
Power: 73.0 HP (53.7 kW)
EPA Certificate No.: 9KAXC1.70AAA-011
EPA CO Emissions: 6.0 CO g/km
Torque: 146.2 Nm (14.9 kgf-m)
Engine type: V-Twin, four-stroke
Power/weight ratio: 0.1816 HP/kg (wet)
Bore x stroke: 102.0 x 104.0 mm
Compression: 9.5:1
Cooling system: Liquid
Fuel system: Injection
Starting: Electric
Ignition: TCBI with Digital Advance
Aspiration: Naturally aspirated
Valves per cylinder: 4
Lubrication system: Forced lubrication, semi and #8209;dry sump

Transmission

Gearbox: 6-speed
Transmission type: Manual
Final drive: Belt

Dimensions & weight

Wheelbase: 1666 mm
Overall length: 2560 mm
Overall width: 996 mm
Overall height: 1549 mm
Seat height: 729 mm
Wet weight: 401.9 kg
Fuel capacity: 20.10 litres
Ground clearance: 135 mm
Dry weight: Not on record - add it

Chassis & suspension

Frame: Steel, double-cradle with box-section single-tube backbone
Front suspension: 43mm hydraulic fork
Rear suspension: Swingarm with twin air-assisted shocks, with 4-way rebound damping
Front wheel travel: 140 mm
Rear wheel travel: 79 mm
Rake (fork angle): 30.0°
Trail: 178 mm

Brakes & wheels

Front brakes: Double disc
Front brakes diameter: 300 mm
Rear brakes: Single disc
Rear brakes diameter: 300 mm
Front tyre: 130/90-16
Rear tyre: 170/70-16

Other

Color options: Candy Diamond Red, Two-tone: Candy Plasma Blue / Metallic Diablo Black , Two-tone: Metallic Titanium / Metallic Diablo Black
Fuel Tank Material: Metal

Compiled from manufacturer documentation and user contributions, corrected on an ongoing basis. Spotted something wrong? Tell us.

What changed, year to year

Differences highlighted

Specification	2009	2013	2017	2020	2024
Capacity	1700 cc	1700 cc	1700 cc	1700 cc	1700 cc
Seat height	729 mm	729 mm	729 mm	729 mm	729 mm
Fuel capacity	20.1 L	20.1 L	20.1 L	20.1 L	20.1 L

Illustrative - generated automatically by diffing the year records already on file, not a manufacturer-published changelog.

Safety Recalls

⚠ 1 recall may apply

SERVICE BRAKES, HYDRAULIC:PEDALS AND LINKAGESOct 2010 · 10V507000

KAWASAKI IS RECALLING CERTAIN MODEL YEAR 2009-2010 VULCAN MOTORCYCLES. THE ENGINE MAY STALL IF THE RIDER IS COASTING WITH THE CLUTCH PULLED IN DUE TO AN IMPROPER SETTING OF THE ENGINE CONTROL UNIT (ECU).

Risk: ENGINE STALLING COULD CREATE A POTENTIAL FOR A CRASH RESULTING IN INJURY OR DEATH.

Remedy: DEALERS WILL REPLACE THE ECU WITH ONE CONTAINING REVISED SETTINGS TO ADDRESS THE ENGINE STALLING. THE SAFETY RECALL BEGAN ON NOVEMBER 1, 2010. OWNERS MAY CONTACT KAWASAKI CONSUMER SERVICES DEPARTMENT AT 1-866-802-9381.

These recalls cover some 2009 bikes of this model. Whether one applies to a specific bike, and whether the repair has already been done, depends on its VIN — check your VIN with NHTSA or ask a dealer.

Source: NHTSA. View all Kawasaki recalls →
