Kawasaki Vulcan 1700 Voyager - 2009 Specifications and Reviews
The 2009 Kawasaki Vulcan 1700 Voyager is a cruiser-touring machine designed for riders seeking comfortable long-distance travel. Powered by a 1700cc V-twin engine producing substantial low-end torque, it excels at highway cruising with its relaxed riding position and generous cargo capacity. Known for blending cruiser styling with practical touring amenities, it appeals to experienced riders prioritizing comfort on extended journeys.
General information | |
| Category | Touring |
| Year | 2009 |
| Model | Kawasaki Vulcan 1700 Voyager |
| | |
Engine and Transmission Specifications | |
| Gearbox | 6-speed |
| Cooling system | Liquid |
| Starter | Electric |
| Fuel control | SOHC |
| Valves per cylinder | 4 |
| Fuel system | Injection |
| Bore x stroke | 102.0 x 104.0 mm (4.0 x 4.1 inches) |
| Compression | 9.5:1 |
| Torque | 146.17 |
| Stroke | 4 |
| Engine type | V2 |
| Capacity: | 1700.00 ccm (103.73 cubic inches) |
Physical measures and capacities | |
| Rear brakes diameter | 300 mm (11.8 inches) |
| Rear brakes | Single disc |
| Front brakes diameter | 300 mm (11.8 inches) |
| Front brakes | Double disc |
| Rear tyre dimensions | 170/70-16 |
| Front tyre dimensions | 130/90-16 |
| Rear suspension travel | 79 mm (3.1 inches) |
| Rear suspension | Swingarm with twin air-assisted shocks, with 4-way rebound damping |
| Front suspension travel | 140 mm (5.5 inches) |
| Front suspension | 43mm hydraulic fork |
| Rake (fork angle) | 30.0° |
| Frame type | Steel, double-cradle with box-section single-tube backbone |
| | |
Speed and acceleration | |
| Color options | Candy Diamond Red, Two-tone: Candy Plasma Blue / Metallic Diablo Black , Two-tone: Metallic Titanium / Metallic Diablo Black |
| Fuel capacity | 20.06 litres (5.30 gallons) |
Rider Reviews
Add a Comment
Related Motorcycle Specifications
More Kawasaki Motorcycles
⚠ Safety Recalls (1)
KAWASAKI IS RECALLING CERTAIN MODEL YEAR 2009-2010 VULCAN MOTORCYCLES. THE ENGINE MAY STALL IF THE RIDER IS COASTING WITH THE CLUTCH PULLED IN DUE TO AN IMPROPER SETTING OF THE ENGINE CONTROL UNIT (ECU).
Risk: ENGINE STALLING COULD CREATE A POTENTIAL FOR A CRASH RESULTING IN INJURY OR DEATH.
Remedy: DEALERS WILL REPLACE THE ECU WITH ONE CONTAINING REVISED SETTINGS TO ADDRESS THE ENGINE STALLING. THE SAFETY RECALL BEGAN ON NOVEMBER 1, 2010. OWNERS MAY CONTACT KAWASAKI CONSUMER SERVICES DEPARTMENT AT 1-866-802-9381.
Source: NHTSA. View all Kawasaki recalls →
