Category: | Naked bike |
Year: | 2011 |
Model: | Moto Morini 1200 Sport |
|
Engine and Transmission Specifications |
Exhaust system: | Sport Termignoni with double silencer, 3-way catalytic converter and oxygen sensor. |
Emission details: | Euro 3. |
Driveline: | Primar 55:31. Final 17/40. |
Clutch: | Multiple-plate clutch in oil bath |
Transmission type,final drive: | Chain |
Gearbox: | 6-speed |
Cooling system: | Liquid |
Fuel control: | DOHC |
Fuel system: | Injection. Magneti Marelli indirect injection. |
Valves per cylinder: | 4 |
Bore x stroke: | 107.0 x 66.0 mm (4.2 x 2.6 inches) |
Compression: | 12.5:1 |
Torque: | 102.00 Nm (10.4 kgf-m or 75.2 ft.lbs) @ 6700 |
Power: | 117.00 |
Engine details: | 87 degree V-twin |
Engine type: | V2, four-stroke |
Capacity: | 1187.00 ccm (72.43 cubic inches) |
|
Brakes, suspension, Frame and wheels |
Rear brakes diameter: | 220 mm (8.7 inches) |
Rear brakes: | Single disc. Bremo |
Front brakes diameter: | 320 mm (12.6 inches) |
Front brakes: | Double disc. Bremo, 4-piston |
Rear tyre dimensions: | 180/55-R17 |
Front tyre dimensions: | 120/70-R17 |
Rear suspension travel: | 150 mm (5.9 inches) |
Rear suspension: | Single lateralshock absorber |
Front suspension travel: | 150 mm (5.9 inches) |
Front suspension: | Marzocchi upside down fork |
Trail: | 100 mm (3.9 inches) |
Rake (fork angle): | 24.5° |
Frame type: | High-strength steel tube trellis frame |
Physical measures and capacities |
Reserve fuel capacity: | 4.50 litres (1.19 gallons) |
Fuel capacity: | 21.00 litres (5.55 gallons) |
Wheelbase: | 1,440 mm (56.7 inches) |
Overall width: | 865 mm (34.1 inches) |
Overall length: | 2,170 mm (85.4 inches) |
Seat height: | 800 mm (31.5 inches) If adjustable, lowest setting. |
Power/weight ratio: | 0.5909 HP/kg |
Dry weight: | 198.0 kg (436.5 pounds) |
Other specs |
Comments: | Chinese made bike. |
Wheelbase: | 1,200 mm (47.2 inches) |
Ground clearance: | 170 mm (6.7 inches) |
Overall height: | 850 mm (33.5 inches) |
Wheels: | 14 inch wheels |
Rear Suspension: | Aluminum, air-cell adjustable |
Front Suspension: | Aluminum, air-cell adjustable |
Bore x Stroke: | 70.0 x 64.8 mm (2.8 x 2.6 inches) |
Top speed: | 90.0 km/h (55.9 mph) |
Capacity: | 250.00 ccm (15.26 cubic inches) |
Color options: | Blue/white/black, British racing green/yellow/white, black/orange/white |
Factory warranty: | 3 year |
Instruments: | Digital/analogue |
Starter: | Electric |
