Moto Morini 1200 Sport - 2011 Specifications and Reviews
General information | |
| Category: | Naked bike |
| Year: | 2011 |
| Model: | Moto Morini 1200 Sport |
Engine and Transmission Specifications | |
| Exhaust system: | Sport Termignoni with double silencer, 3-way catalytic converter and oxygen sensor. |
| Emission details: | Euro 3. |
| Driveline: | Primar 55:31. Final 17/40. |
| Clutch: | Multiple-plate clutch in oil bath |
| Transmission type,final drive: | Chain |
| Gearbox: | 6-speed |
| Cooling system: | Liquid |
| Fuel control: | DOHC |
| Fuel system: | Injection. Magneti Marelli indirect injection. |
| Valves per cylinder: | 4 |
| Bore x stroke: | 107.0 x 66.0 mm (4.2 x 2.6 inches) |
| Compression: | 12.5:1 |
| Torque: | 102.00 Nm (10.4 kgf-m or 75.2 ft.lbs) @ 6700 |
| Power: | 117.00 |
| Engine details: | 87 degree V-twin |
| Engine type: | V2, four-stroke |
| Capacity: | 1187.00 ccm (72.43 cubic inches) |
Brakes, suspension, Frame and wheels | |
| Rear brakes diameter: | 220 mm (8.7 inches) |
| Rear brakes: | Single disc. Bremo |
| Front brakes diameter: | 320 mm (12.6 inches) |
| Front brakes: | Double disc. Bremo, 4-piston |
| Rear tyre dimensions: | 180/55-R17 |
| Front tyre dimensions: | 120/70-R17 |
| Rear suspension travel: | 150 mm (5.9 inches) |
| Rear suspension: | Single lateralshock absorber |
| Front suspension travel: | 150 mm (5.9 inches) |
| Front suspension: | Marzocchi upside down fork |
| Trail: | 100 mm (3.9 inches) |
| Rake (fork angle): | 24.5° |
| Frame type: | High-strength steel tube trellis frame |
Physical measures and capacities | |
| Reserve fuel capacity: | 4.50 litres (1.19 gallons) |
| Fuel capacity: | 21.00 litres (5.55 gallons) |
| Wheelbase: | 1,440 mm (56.7 inches) |
| Overall width: | 865 mm (34.1 inches) |
| Overall length: | 2,170 mm (85.4 inches) |
| Seat height: | 800 mm (31.5 inches) If adjustable, lowest setting. |
| Power/weight ratio: | 0.5909 HP/kg |
| Dry weight: | 198.0 kg (436.5 pounds) |
Other specs | |
| Comments: | Chinese made bike. |
| Wheelbase: | 1,200 mm (47.2 inches) |
| Ground clearance: | 170 mm (6.7 inches) |
| Overall height: | 850 mm (33.5 inches) |
| Wheels: | 14 inch wheels |
| Rear Suspension: | Aluminum, air-cell adjustable |
| Front Suspension: | Aluminum, air-cell adjustable |
| Bore x Stroke: | 70.0 x 64.8 mm (2.8 x 2.6 inches) |
| Top speed: | 90.0 km/h (55.9 mph) |
| Capacity: | 250.00 ccm (15.26 cubic inches) |
| Color options: | Blue/white/black, British racing green/yellow/white, black/orange/white |
| Factory warranty: | 3 year |
| Instruments: | Digital/analogue |
| Starter: | Electric |
