2010Moto Morini Granpasso 1200
40 fields on record
The 2010 Moto Morini Granpasso 1200 is an Italian adventure tourer built around Morini's own V-twin engine. Its liquid-cooled 1,187cc V-twin makes 118 hp at 8,500 rpm and 103.6 Nm through a six-speed gearbox and chain. An 875 mm seat and 210 kg dry weight make it a rare, capable road bike.
- Capacity
- 1187.0 ccm
- Engine
- V-Twin, four-stroke
- Gearbox
- 6-speed
- Dry weight
- 210.0 kg
- Seat height
- 875 mm
- Power
- 118.0 HP (86.8 kW) @ 8500 RPM
How it rides
Editorial estimate from the spec sheet - not lab tested- Best for
- It's built as a sporty allround adventure-tourer, equally at home carving twisty roads and covering long distances with occasional light off-road use.
- Built for
- The Bialbero V-twin and premium Marzocchi and Ohlins suspension give it a spirited, high-quality feel with strong low-to-mid range torque and sharp handling for its class.
- Not ideal for
- It's not the right choice for a rider seeking a plush, low-slung cruiser or a hardcore dirt-focused off-road machine.
Scores are derived from the spec sheet using the same model across every bike, so they compare like for like.
Will it fit you?
Worked out in your browser - nothing is sent to usEngine
- Capacity
- 1187.0 ccm
- Power
- 118.0 HP (86.8 kW) @ 8500 RPM
- Torque
- 103.6 Nm (10.6 kgf-m)
- Engine type
- V-Twin, four-stroke
- Power/weight ratio
- 0.5619 HP/kg (dry)
- Bore x stroke
- 107.0 x 66.0 mm
- Compression
- 12.5:1
- Cooling system
- Liquid
- Fuel system
- Injection
- Starting
- Electric
- Ignition
- I.A.W. electronics
- Valves per cylinder
- 4
- Lubrication system
- Forced by oil pump
Transmission
- Gearbox
- 6-speed
- Transmission type
- Manual
- Final drive
- Chain
- Clutch
- Multiple-plate clutch in oil bath with antiskipping system and radial master-cylinder
Dimensions & weight
- Wheelbase
- 1505 mm
- Overall length
- 2170 mm
- Overall width
- 850 mm
- Seat height
- 875 mm
- Dry weight
- 210.0 kg
- Fuel capacity
- 27.00 litres
- Ground clearance
- 200 mm
- Reserve fuel capacity
- 5.50 litres
Chassis & suspension
- Frame
- High-strength steel tube trellis frame
- Front suspension
- Marzocchi upside down
- Rear suspension
- Ohlins shock absorber
- Front wheel travel
- 190 mm
- Rear wheel travel
- 200 mm
- Rake (fork angle)
- 26.5°
- Trail
- 135 mm
Brakes & wheels
- Front brakes
- Double disc. Bremo
- Front brakes diameter
- 298 mm
- Rear brakes
- Single disc. Bremo
- Rear brakes diameter
- 255 mm
- Front tyre
- 110/80-R19
- Rear tyre
- 150/70-R17
Other
- Color options
- Black/grey, red/gray, white/black
Specs last verified against published sources: .
Compiled from manufacturer documentation and user contributions, corrected on an ongoing basis. Spotted something wrong? Tell us.
What changed, year to year
Differences highlighted| Specification | 2009 | 2010 | 2011 | 2012 |
|---|---|---|---|---|
| Capacity | 1187 cc | 1187 cc | 1187 cc | 1187 cc |
| Dry weight | 210 kg | 210 kg | 210 kg | 210 kg |
| Seat height | 875 mm | 875 mm | 875 mm | 875 mm |
| Fuel capacity | 27 L | 27 L | 27 L | 27 L |
Illustrative - generated automatically by diffing the year records already on file, not a manufacturer-published changelog.
Rider Reviews
Common questions
What is the engine size of the Moto Morini Granpasso 1200?
The 2010 Moto Morini Granpasso 1200 has a Capacity of 1187.0 ccm (72.44 cubic inches).
What engine power does the Moto Morini Granpasso 1200 have?
The 2010 Moto Morini Granpasso 1200 has a Power of 118.0 HP (86.8 kW) @ 8500 RPM.
How many gears does the Moto Morini Granpasso 1200 have?
The 2010 Moto Morini Granpasso 1200 has a Gearbox of 6-speed.
What is the torque of the Moto Morini Granpasso 1200?
The 2010 Moto Morini Granpasso 1200 has a Torque of 103.6 Nm (10.6 kgf-m or 76.4 ft.lbs).
How much does the Moto Morini Granpasso 1200 weigh?
The 2010 Moto Morini Granpasso 1200 has a Dry weight of 210.0 kg (463.0 pounds).
