Moto Morini Corsaro Avio - 2010 Specifications and Reviews
General information | |
| Category: | Naked bike |
| Year: | 2010 |
| Model: | Moto Morini Corsaro Avio |
Engine and Transmission Specifications | |
| Exhaust system: | Double silencer, 3-way catalytic converter and oxygen sensor. Euro 3. |
| Clutch: | Wet, multiple-plate |
| Transmission type,final drive: | Chain |
| Gearbox: | 6-speed |
| Cooling system: | Liquid |
| Ignition: | I.A.W. |
| Fuel control: | DOHC |
| Fuel system: | Injection. Magneti Marelli |
| Bore x stroke: | 107.0 x 66.0 mm (4.2 x 2.6 inches) |
| Compression: | 12.5:1 |
| Torque: | 102.00 Nm (10.4 kgf-m or 75.2 ft.lbs) @ 6700 |
| Power: | 120.00 |
| Engine type: | V2, four-stroke |
| Capacity: | 1187.00 ccm (72.43 cubic inches) |
Brakes, suspension, Frame and wheels | |
| Rear brakes diameter: | 220 mm (8.7 inches) |
| Rear brakes: | Single disc. Bremo |
| Front brakes diameter: | 320 mm (12.6 inches) |
| Front brakes: | Double disc. Bremo, 4-piston |
| Rear tyre dimensions: | 180/55-ZR17 |
| Front tyre dimensions: | 120/70-ZR17 |
| Rear suspension travel: | 130 mm (5.1 inches) |
| Rear suspension: | With progressive motion and single Sachs shock absorber adjustable in extension, compression and spring pre-charge |
| Front suspension travel: | 129 mm (5.1 inches) |
| Front suspension: | Marzocchi upside-down fully adjustable fork with 50 mm legs |
| Trail: | 103 mm (4.1 inches) |
| Rake (fork angle): | 24.5° |
| Frame type: | Verlicchi high-strength steel tube trellis |
Physical measures and capacities | |
| Reserve fuel capacity: | 4.00 litres (1.06 gallons) |
| Fuel capacity: | 18.00 litres (4.76 gallons) |
| Ground clearance: | 140 mm (5.5 inches) |
| Overall width: | 810 mm (31.9 inches) |
| Overall length: | 2,070 mm (81.5 inches) |
| Seat height: | 830 mm (32.7 inches) If adjustable, lowest setting. |
| Power/weight ratio: | 0.6061 HP/kg |
| Dry weight: | 198.0 kg (436.5 pounds) |
Other specs | |
| Color options: | Silver/blue, black/red |
