Triumph Bonneville Bobber Black - 2018 Specifications and Reviews
2018
General information | |
| Category: | Classic |
| Year: | 2018 |
| Model: | Triumph Bonneville Bobber Black |
Engine and Transmission Specifications | |
| Exhaust system: | Black steel 2 into 2 twin-skin exhaust system with brushed stainless silencers. |
| Greenhouse gases: | 104.4 CO2 g/km. (CO2 - Carbon dioxide emission) |
| Fuel consumption: | 4.50 litres/100 km (22.2 km/l or 52.27 mpg) |
| Driveline: | X ring chain. Primary drive: Gear. |
| Clutch: | Wet, multi-plate assist clutch |
| Transmission type,final drive: | Chain |
| Gearbox: | 6-speed |
| Cooling system: | Air |
| Ignition: | Digital-inductive type via engine management system |
| Fuel control: | Single Overhead Cams (SOHC) |
| Fuel system: | Injection. Multipoint sequential electronic fuel injection with SAI |
| Valves per cylinder: | 8 |
| Bore x Stroke: | 97.6 x 80.0 mm (3.8 x 3.1 inches) |
| Compression: | 10.0:1 |
| Torque: | 106.00 Nm (10.8 kgf-m or 78.2 ft.lbs) @ 4000 Revolutions">RPM |
| Power: | 77.00 Horsepower">HP (56.2 Kilowatt">kW)) @ 6550 Revolutions">RPM |
| Engine details: | 270° crank angle parallel twin, black |
| Engine type: | Twin, four-stroke |
Brakes, suspension, Frame and wheels | |
| Seat: | Solo seat |
| Wheels: | Wire 32-spoke |
| Rear brakes diameter: | 255 mm (10.0 inches) |
| Rear brakes: | Single disc. ABS. Nissin single piston floating caliper. |
| Front brakes diameter: | 310 mm (12.2 inches) |
| Front brakes: | Single disc. ABS. Nissin 2-piston floating caliper |
| Rear tyre: | 150/80-R16 |
| Front tyre: | 100/90-19 |
| Rear wheel travel: | 77 mm (3.0 inches) |
| Rear Suspension: | KYB monoshock with linkage |
| Front wheel travel: | 90 mm (3.5 inches) |
| Front Suspension: | KYB 41mm forks |
| Trail: | 88 mm (3.5 inches) |
| Rake (fork angle): | 25.8° |
| Frame type: | Tubular steel cradle. Twin-sided, tubular steel swing arm. |
Physical measures and capacities | |
| Oil capacity: | 4.50 litres (0.30 quarts) |
| Fuel capacity: | 10.60 litres (2.80 gallons) |
| Wheelbase: | 1,510 mm (59.4 inches) |
| Overall width: | 800 mm (31.5 inches) |
| Overall height: | 1,025 mm (40.4 inches) |
| Seat height: | 690 mm (27.2 inches) If adjustable, lowest setting. |
| Power/weight ratio: | 0.3377 HP/kg |
| Dry weight: | 228.0 kg (502.7 pounds) |
Other specs | |
| Factory warranty: | 24 months unlimited milage |
| Instruments: | LCD multi-functional instrument pack with analogue speedometer, odometer, gear position indicator, fuel gauge |
| Starter: | Electric |
| Color options: | Jet Black, Matte Jet Black |
