Triumph Speedmaster - 2010 Specifications and Reviews

Not Rated stars Average rating: Not Rated from 0 votes
.

General information

CategoryCustom / cruiser
Year2010
ModelTriumph Speedmaster



Engine and Transmission Specifications

ClutchWet. multi-plate
Transmission type,final driveChain
Gearbox5-speed
Cooling systemAir
Fuel controlDOHC
Fuel systemInjection. Multipoint sequential electonic fuel injection with SAI
Bore x stroke90.0 x 68.0 mm (3.5 x 2.7 inches)
Compression9.2:1
Torque74.00 Nm (7.5 kgf-m or 54.6 ft.lbs) @ 3300
Power61.68
Engine typeTwin, four-stroke
Capacity:865.00 ccm (52.78 cubic inches)



Brakes, suspension, Frame and wheels

Rear brakes diameter285 mm (11.2 inches)
Rear brakesSingle disc
Front brakes diameter310 mm (12.2 inches)
Front brakesDouble disc
Rear tyre dimensions170/80-B15
Front tyre dimensions110/80-R18
Rear suspension travel96 mm (3.8 inches)
Rear suspensionKayaba chromed spring twin shocks with adjustable preload
Front suspension travel130 mm (5.1 inches)
Front suspensionKayaba 41mm forks with polished stainless steel shrouds and polished lowers
Trail153 mm (6.0 inches)
Rake (fork angle)33.3°
Frame typeTubular steel cradle. Twin-sided, tubular steel swingarm.

Physical measures and capacities

Fuel capacity19.30 litres (5.10 gallons)
Wheelbase1,655 mm (65.2 inches)
Overall width830 mm (32.7 inches)
Overall length2,420 mm (95.3 inches)
Overall height1,160 mm (45.7 inches)
Seat height720 mm (28.3 inches) If adjustable, lowest setting.
Power/weight ratio0.2693 HP/kg
Weight incl. oil, gas, etc250.0 kg (551.2 pounds)
Dry weight229.0 kg (504.9 pounds)

Other specs

Color optionsPhantom Black, Phantom Black/New England White
StarterElectric
