Victory Vision Tour - 2010 Specifications and Reviews

Not Rated stars Average rating: Not Rated from 0 votes
.

General information

Category:Touring
Year:2010
Model:Victory Vision Tour

Engine and Transmission Specifications

Transmission type,final drive:Belt
Gearbox:6-speed
Cooling system:Oil & air
Fuel control:SOHC
Fuel system:Injection. Dual 45mm throttle body
Valves per cylinder:4
Bore x stroke:101.0 x 108.0 mm (4.0 x 4.3 inches)
Compression:9.4:1
Power:97.00
Engine type:V2, four-stroke
Capacity:1731.00 ccm (105.63 cubic inches)

Brakes, suspension, Frame and wheels

Rear brakes diameter:300 mm (11.8 inches)
Rear brakes:Single disc. 2-piston caliper
Front brakes diameter:300 mm (11.8 inches)
Front brakes:Double disc. 3-piston caliper
Rear tyre dimensions:180/60-16
Front tyre dimensions:130/70-18
Rear suspension travel:100 mm (3.9 inches)
Rear suspension:Single, mono-tube gas,cast aluminum with rising rate linkage
Front suspension travel:130 mm (5.1 inches)
Front suspension:Conventional telescopic fork
Trail:137 mm (5.4 inches)
Rake (fork angle):29.0°


Physical measures and capacities

Oil capacity:4.70 litres (0.31 quarts)
Reserve fuel capacity:3.78 litres (1.00 gallons)
Fuel capacity:22.71 litres (6.00 gallons)
Wheelbase:1,669 mm (65.7 inches)
Ground clearance:148 mm (5.8 inches)
Overall length:2,664 mm (104.9 inches)
Seat height:673 mm (26.5 inches) If adjustable, lowest setting.
Power/weight ratio:0.2985 HP/kg
Dry weight:325.0 kg (716.5 pounds)


Other specs

Color options:Solid Black, Solid Pearl White, Two Tone Ocean Blue and Sandstone Metallic.
