Yamaha XJR 1300 - 2011 Specifications and Reviews
General information | |
| Category: | Naked bike |
| Year: | 2011 |
| Model: | Yamaha XJR 1300 |
Engine and Transmission Specifications | |
| Driveline: | Constant Mesh, 5-speed |
| Clutch: | Wet, multiple-disc coil spring |
| Transmission type,final drive: | Chain |
| Gearbox: | 5-speed |
| Cooling system: | Air |
| Lubrication system: | Wet sump |
| Ignition: | TCI |
| Fuel control: | DOHC |
| Fuel system: | Injection. EFI |
| Valves per cylinder: | 4 |
| Bore x stroke: | 79.0 x 63.8 mm (3.1 x 2.5 inches) |
| Compression: | 9.7:1 |
| Torque: | 108.40 Nm (11.1 kgf-m or 80.0 ft.lbs) @ 6000 |
| Power: | 98.00 |
| Engine type: | In-line four, four-stroke |
| Capacity: | 1251.00 ccm (76.34 cubic inches) |
Brakes, suspension, Frame and wheels | |
| Wheels: | Three-spoke alloy wheels |
| Rear brakes diameter: | 267 mm (10.5 inches) |
| Rear brakes: | Single disc |
| Front brakes diameter: | 298 mm (11.7 inches) |
| Front brakes: | Double disc |
| Rear tyre dimensions: | 180/55-ZR17 |
| Front tyre dimensions: | 120/70-ZR17 |
| Rear suspension travel: | 120 mm (4.7 inches) |
| Rear suspension: | Swingarm |
| Front suspension travel: | 130 mm (5.1 inches) |
| Front suspension: | Telescopic forks |
| Trail: | 100 mm (3.9 inches) |
| Frame type: | Steel double cradle |
Physical measures and capacities | |
| Oil capacity: | 4.20 litres (0.28 quarts) |
| Fuel capacity: | 21.00 litres (5.55 gallons) |
| Ground clearance: | 125 mm (4.9 inches) |
| Overall width: | 765 mm (30.1 inches) |
| Overall length: | 2,175 mm (85.6 inches) |
| Overall height: | 1,115 mm (43.9 inches) |
| Seat height: | 795 mm (31.3 inches) If adjustable, lowest setting. |
| Power/weight ratio: | 0.4414 HP/kg |
| Weight incl. oil, gas, etc: | 245.0 kg (540.1 pounds) |
| Dry weight: | 222.0 kg (489.4 pounds) |
Other specs | |
| Factory warranty: | 6 Month (Limited Factory Warranty) |
| Light: | None |
| Color options: | Team Yamaha Blue/White, White w/Graphics Kit |
| Rear tyre: | 18/9-Ma8 |
| Front tyre: | 18/7-Ma8 |
| Rear wheel travel: | 127 mm (5.0 inches) |
| Rear Suspension: | Swingarm |
| Front wheel travel: | 127 mm (5.0 inches) |
| Front Suspension: | Independent double wishbone |
| Valves per cylinder: | 2 |
| Bore x Stroke: | 47.0 x 51.0 mm (1.9 x 2.0 inches) |
| Compression: | 10.2:1 |
| Model: | Yamaha Raptor 90 |
| Starter: | Electric |
