2003Yamaha XJR1300

Rate this bike

39 fields on record

The 2003 Yamaha XJR 1300 is a classic naked bike that appeals to riders seeking a versatile, accessible middleweight with genuine performance. Its 1251cc inline-four engine delivers 106 hp with strong midrange torque, making it equally comfortable for commuting and spirited riding. Known for reliability and straightforward handling, the XJR suits experienced riders who value practical power over aggressive sport bike dynamics.

Capacity: 1251.0 ccm
Engine: In-line four, four-stroke
Gearbox: 5-speed
Dry weight: 224.0 kg
Seat height: 775 mm
Power: 106.0 HP (78.0 kW) @ 8000 RPM

⇄ Compare with another bike ＋ Add to garage All model years

What’s new for the 2003 Yamaha XJR1300

vs the 2002

Spec	2002	2003
Seat height	820 mm (32.3 inches)	775 mm (30.5 inches)
Front brakes	Dual disc	not listed

Other years 1999 2000 2001 2002 2003 2004 2005 2006 2007 2008 2009 2010 2011 2012 2013 2014 2015 2016 2017 2018

How it rides

Editorial estimate from the spec sheet - not lab tested

Off-road & trail5%

Cornering65%

City riding55%

Daily riding65%

Touring50%

Two-up55%

Track45%

Best for: Built for muscular, retro-styled street riding and spirited backroad blasts rather than track lap times or long-distance touring.
Built for: Delivers a raw, big-bore four-cylinder growl with strong midrange torque and a classic UJM feel that rewards deliberate, muscular riding inputs.
Not ideal for: Not a good fit for new riders, off-road use, or anyone wanting a lightweight, nimble commuter or a plush long-haul tourer.

Scores are derived from the spec sheet using the same model across every bike, so they compare like for like.

Will it fit you?

Worked out in your browser - nothing is sent to us

Your height

Inseam (optional)

Units

At 775mm, a rider of 68.9" with a 31" (estimated) inseam will reach the ground with both feet flat on the 2003 Yamaha XJR1300, with a relaxed knee angle of around 120 degrees and a forward-leaning riding position.

Assumes about 30mm of suspension sag once seated. This is an approximation from category-typical geometry, not a measurement of this bike or of you - sit on one before you buy.

More bikes at 751-820 mm — Middle Ground →

Find bikes that fit your height →

Full specifications

Engine

Capacity: 1251.0 ccm
Power: 106.0 HP (78.0 kW) @ 8000 RPM
Torque: 104.8 Nm (10.7 kgf-m) @ 6000 RPM
Engine type: In-line four, four-stroke
Power/weight ratio: 0.4732 HP/kg (dry)
Bore x stroke: 79.0 x 63.8 mm
Compression: 9.7:1
Cooling system: Air
Fuel system: Carburettor
Starting: Electric
Ignition: TCI
Valves per cylinder: 4
Lubrication system: Wet sump

Transmission

Gearbox: 5-speed
Transmission type: Manual
Final drive: Chain
Clutch: Wet, multiple-disc coil spring

Dimensions & weight

Wheelbase: 1510 mm
Overall length: 2175 mm
Overall width: 775 mm
Overall height: 1115 mm
Seat height: 775 mm
Dry weight: 224.0 kg
Wet weight: 249.5 kg
Fuel capacity: 21.00 litres
Ground clearance: 120 mm
Oil capacity: 4.20 litres

Chassis & suspension

Frame: Steel double cradle
Front suspension: Telescopic fork
Rear suspension: Swingarm
Front wheel travel: 130 mm
Rear wheel travel: 120 mm
Rake (fork angle): 25.0°
Trail: 100 mm

Brakes & wheels

Front brakes diameter: 298 mm
Rear brakes: Single disc
Rear brakes diameter: 267 mm

Other

Color options: Yellow, Blue, Black

Compiled from manufacturer documentation and user contributions, corrected on an ongoing basis. Spotted something wrong? Tell us.

What changed, year to year

Differences highlighted

Specification	1999	2003	2004	2009	2013	2018
Capacity	1251 cc	1251 cc	1251 cc	1251 cc	1251 cc	1251 cc
Dry weight	230 kg	224 kg	224 kg	222 kg	222 kg	222 kg
Seat height	780 mm	775 mm	790 mm	795 mm	795 mm	795 mm
Fuel capacity	21 L	21 L	21 L	21 L	21 L	21 L
