Concept
2012Bimota HB4
24 fields on record
The 2012 Bimota HB4 is an innovative prototype powered by a liquid-cooled 600cc inline-four engine, designed to showcase advanced engineering and lightweight construction principles. Best suited for experienced riders seeking cutting-edge technology, the HB4 combines premium Paioli and Ohlins suspension with injection-fed performance for nimble, responsive handling on both road and track.
- Capacity
- 600.0 ccm
- Engine
- In-line four, four-stroke
- Gearbox
- 5-speed
- Dry weight
- 135.0 kg
- Seat height
- Not on record
Know it? Add it → - Power
- 66.0 HP (48.5 kW)
How it rides
Editorial estimate from the spec sheet - not lab tested- Best for
- Designed primarily for spirited backroad carving and track-day precision rather than outright top speed or practicality.
- Built for
- A rare, handcrafted Italian special that pairs a proven Japanese inline-four with premium suspension and a trellis chassis for razor-sharp, featherweight handling.
- Not ideal for
- Not a good fit for riders seeking upright comfort, pillion capability, luggage capacity, or long-distance touring ease.
Scores are derived from the spec sheet using the same model across every bike, so they compare like for like.
Engine
- Capacity
- 600.0 ccm
- Power
- 66.0 HP (48.5 kW)
- Engine type
- In-line four, four-stroke
- Power/weight ratio
- 0.4889 HP/kg (dry)
- Bore x stroke
- 67.0 x 42.5 mm
- Cooling system
- Liquid
- Fuel system
- Injection
- Starting
- Electric
- Valves per cylinder
- 4
Transmission
- Gearbox
- 5-speed
- Transmission type
- Manual
- Final drive
- Chain
Dimensions & weight
- Dry weight
- 135.0 kg
- Fuel capacity
- 21.00 litres
Chassis & suspension
- Frame
- Steel and cast magnesium trellis frame
- Front suspension
- Paioli da 43 mm
- Rear suspension
- Ohlins TTX
Brakes & wheels
- Front brakes
- Double disc. bremo
- Front brakes diameter
- 300 mm
- Rear brakes
- Single disc. Bremo
- Front tyre
- 125/80-17
- Rear tyre
- 195/65-17
Other
- Color options
- Red/white
Compiled from manufacturer documentation and user contributions, corrected on an ongoing basis. Spotted something wrong? Tell us.
What changed, year to year
Differences highlighted| Specification | 2012 | 2013 |
|---|---|---|
| Capacity | 600 cc | 600 cc |
| Dry weight | 135 kg | 135 kg |
| Fuel capacity | 21 L | 21 L |
Illustrative - generated automatically by diffing the year records already on file, not a manufacturer-published changelog.
Rider Reviews
Common questions
What is the engine size of the Bimota HB4?
The 2012 Bimota HB4 has a Capacity of 600.0 ccm (36.61 cubic inches).
What engine power does the Bimota HB4 have?
The 2012 Bimota HB4 has a Power of 66.0 HP (48.5 kW).
How many gears does the Bimota HB4 have?
The 2012 Bimota HB4 has a Gearbox of 5-speed.
How much does the Bimota HB4 weigh?
The 2012 Bimota HB4 has a Dry weight of 135.0 kg (297.6 pounds).
