Naked Motorcycles
2009Confederate B120 Wraith
25 fields on record
The 2009 Confederate B120 Wraith is a heavyweight naked bike designed for experienced riders seeking raw power and distinctive American craftsmanship. Powered by a massive 1966cc V-twin engine producing 125 horsepower and 176 Nm of torque, it delivers aggressive performance with a commanding presence. Best known for its handcrafted construction and unconventional styling, the Wraith appeals to collectors and serious enthusiasts prioritizing character over conventional design.
- Capacity
- 1966.6 ccm
- Engine
- V-Twin, four-stroke
- Gearbox
- 6-speed
- Dry weight
- 176.9 kg
- Seat height
- 775 mm
- Power
- 125.0 HP (91.9 kW)
How it rides
Editorial estimate from the spec sheet - not lab tested- Best for
- Built as a boutique, high-performance naked bike that blends muscular torque with aerospace-grade engineering for spirited, statement-making riding.
- Built for
- A rare, sculptural piece of rolling art that pairs American V-twin muscle with carbon-fiber aircraft-inspired engineering for a visceral, individualistic riding experience.
- Not ideal for
- This is not the bike for new riders, off-road adventurers, or anyone seeking plush comfort and practical everyday or long-distance touring capability.
Scores are derived from the spec sheet using the same model across every bike, so they compare like for like.
Will it fit you?
Worked out in your browser - nothing is sent to usEngine
- Capacity
- 1966.6 ccm
- Power
- 125.0 HP (91.9 kW)
- Torque
- 176.3 Nm (18.0 kgf-m)
- Engine type
- V-Twin, four-stroke
- Power/weight ratio
- 0.7066 HP/kg (dry)
- Bore x stroke
- 104.8 x 114.3 mm
- Fuel system
- Injection
- Starting
- Electric
Transmission
- Gearbox
- 6-speed
- Transmission type
- Manual
- Final drive
- Belt
Dimensions & weight
- Seat height
- 775 mm
- Dry weight
- 176.9 kg
Chassis & suspension
- Frame
- Confederate design triple load path carbon fiber monocoque. Aircraft grade CNC billet bulkhead, fuselage. Oil in frame.
- Front suspension
- Penske coil over shock, fully adjustable
- Rear suspension
- Penske coil over shock with cooling reservoir; multi adjustable
- Rake (fork angle)
- 27.0°
Brakes & wheels
- Front brakes
- Double disc. Bremo, 4-piston
- Front brakes diameter
- 300 mm
- Rear brakes
- Single disc. Bremo, 2-piston
- Rear brakes diameter
- 280 mm
- Front tyre
- 120/60-17
- Rear tyre
- 280/55-17
Other
- Color options
- Black/grey
Compiled from manufacturer documentation and user contributions, corrected on an ongoing basis. Spotted something wrong? Tell us.
What changed, year to year
Differences highlighted| Specification | 2009 | 2010 | 2011 |
|---|---|---|---|
| Capacity | 1967 cc | 1967 cc | 1966 cc |
| Dry weight | 177 kg | 177 kg | 177 kg |
| Seat height | 775 mm | 775 mm | 775 mm |
Illustrative - generated automatically by diffing the year records already on file, not a manufacturer-published changelog.
Rider Reviews
Common questions
What is the engine size of the Confederate B120 Wraith?
The 2009 Confederate B120 Wraith has a Capacity of 1966.6 ccm (120.01 cubic inches).
What engine power does the Confederate B120 Wraith have?
The 2009 Confederate B120 Wraith has a Power of 125.0 HP (91.9 kW).
How many gears does the Confederate B120 Wraith have?
The 2009 Confederate B120 Wraith has a Gearbox of 6-speed.
What is the torque of the Confederate B120 Wraith?
The 2009 Confederate B120 Wraith has a Torque of 176.3 Nm (18.0 kgf-m or 130.0 ft.lbs).
How much does the Confederate B120 Wraith weigh?
The 2009 Confederate B120 Wraith has a Dry weight of 176.9 kg (390.0 pounds).
