Underbones
2013Giantco X
30 fields on record
The 2013 Giantco X is an underbone for commuters who want frugal, practical step-through transport. Its 107cc air-cooled single makes 7 hp and 6.9 Nm, with an 89 kg dry weight and a 4.5-litre tank.
- Capacity
- 107.0 ccm
- Engine
- Single, four-stroke
- Gearbox
- 4-speed
- Dry weight
- 89.0 kg
- Seat height
- Not on record
Know it? Add it → - Power
- 7.0 HP (5.1 kW)
How it rides
Editorial estimate from the spec sheet - not lab tested- Best for
- Built purely for short-hop urban commuting and running errands rather than any kind of spirited or long-distance riding.
- Built for
- A humble, no-frills Chinese-made commuter cub that prioritizes cheap, simple transportation over excitement or refinement.
- Not ideal for
- This is not the bike for riders wanting highway speed, long-distance touring comfort, a passenger-friendly ride, or any off-road capability.
Scores are derived from the spec sheet using the same model across every bike, so they compare like for like.
Engine
- Capacity
- 107.0 ccm
- Power
- 7.0 HP (5.1 kW)
- Torque
- 6.9 Nm (0.7 kgf-m) @ 6000 RPM
- Engine type
- Single, four-stroke
- Power/weight ratio
- 0.0787 HP/kg (dry)
- Bore x stroke
- 52.4 x 49.5 mm
- Compression
- 9.0:1
- Cooling system
- Air
- Fuel system
- Carburettor
- Starting
- Electric & kick
- Ignition
- CDI
Transmission
- Gearbox
- 4-speed
- Transmission type
- Manual
- Final drive
- Chain
Dimensions & weight
- Wheelbase
- 1220 mm
- Overall length
- 1870 mm
- Overall width
- 655 mm
- Overall height
- 1060 mm
- Dry weight
- 89.0 kg
- Fuel capacity
- 4.50 litres
- Oil capacity
- 0.90 litres
- Seat height
- Not on record - add it
Chassis & suspension
- Front suspension
- Oil damped telescopic fork
- Rear suspension
- Oil damped coil spring
Brakes & wheels
- Front brakes
- Single disc
- Rear brakes
- Expanding brake (drum brake)
- Front tyre
- 2.50-17
- Rear tyre
- 2.75-17
Other
- Color options
- Silver
- Comments
- Chinese made cub.
Compiled from manufacturer documentation and user contributions, corrected on an ongoing basis. Spotted something wrong? Tell us.
Rider Reviews
Common questions
What is the engine size of the Giantco X?
The 2013 Giantco X has a Capacity of 107.0 ccm (6.53 cubic inches).
What engine power does the Giantco X have?
The 2013 Giantco X has a Power of 7.0 HP (5.1 kW).
How many gears does the Giantco X have?
The 2013 Giantco X has a Gearbox of 4-speed.
What is the torque of the Giantco X?
The 2013 Giantco X has a Torque of 6.9 Nm (0.7 kgf-m or 5.1 ft.lbs) @ 6000 RPM.
How much does the Giantco X weigh?
The 2013 Giantco X has a Dry weight of 89.0 kg (196.2 pounds).
