Cruisers

2012Harley-Davidson Dyna Low Rider

38 fields on record

The 2012 Harley-Davidson Dyna Low Rider is a classic, low-slung cruiser from Harley's Dyna family. Its air-cooled 1,690cc Twin Cam V-twin makes 75 hp and 136 Nm through a six-speed gearbox and belt drive. A very low 640 mm seat makes it easy to manage.

Capacity: 1690.0 ccm
Engine: V-Twin, four-stroke
Gearbox: 6-speed
Dry weight: 292.1 kg
Seat height: 640 mm
Power: 75.0 HP (55.2 kW)

⇄ Compare with another bike ＋ Add to garage All model years

What’s new for the 2012 Harley-Davidson Dyna Low Rider

vs the 2011

Spec	2011	2012
Engine capacity	1584.0 ccm (96.66 cubic inches)	1690.0 ccm (103.13 cubic inches)
Power	68.0 HP (50.0 kW)	75.0 HP (55.2 kW)
Torque	126.0 Nm (12.8 kgf-m or 92.9 ft.lbs) @ 3500 RPM	136.0 Nm (13.9 kgf-m or 100.3 ft.lbs) @ 3500 RPM
Dry weight	—	292.1 kg (644.0 pounds)
Front suspension	—	Telescopic fork
Rear suspension	—	Twin shocks
Compression	9.2:1	9.6:1

Other years 1996 1997 1998 1999 2001 2002 2003 2004 2005 2006 2007 2008 2009 2010 2011 2012 2013 2014 2015 2016 2017

How it rides

Editorial estimate from the spec sheet - not lab tested

Off-road & trail10%

Cornering40%

City riding55%

Daily riding60%

Touring52%

Two-up45%

Track15%

Best for: Built for relaxed boulevard cruising and weekend rides where style, sound, and low-end torque matter more than cornering speed or long-distance touring comfort.
Built for: A classic American cruiser with a punchy air-cooled Twin Cam 103 engine, laid-back ergonomics, and traditional custom styling.
Not ideal for: Not the right choice for riders seeking sport-bike agility, off-road capability, or a dedicated long-haul touring machine with wind protection and cargo capacity.

Scores are derived from the spec sheet using the same model across every bike, so they compare like for like.

Will it fit you?

Worked out in your browser - nothing is sent to us

Your height

Inseam (optional)

Units

At 640mm, a rider of 68.9" with a 31" (estimated) inseam will reach the ground with both feet flat on the 2012 Harley-Davidson Dyna Low Rider, with a cramped knee angle of around 70 degrees and an upright riding position.

Assumes about 30mm of suspension sag once seated. This is an approximation from category-typical geometry, not a measurement of this bike or of you - sit on one before you buy.

More bikes at 750 mm or under — Short Kings →

Find bikes that fit your height →

Full specifications

Engine

Capacity: 1690.0 ccm
Power: 75.0 HP (55.2 kW)
Torque: 136.0 Nm (13.9 kgf-m) @ 3500 RPM
Engine type: V-Twin, four-stroke
Power/weight ratio: 0.2568 HP/kg (dry)
Bore x stroke: 98.4 x 111.1 mm
Compression: 9.6:1
Cooling system: Air
Fuel system: Injection
Starting: Electric
Valves per cylinder: 2
Lubrication system: Dry sump

Transmission

Gearbox: 6-speed
Transmission type: Manual
Final drive: Belt
Clutch: Multi-plate with diaphragm spring in oil bath

Performance

Top speed: 170.0 km/h (105.6 mph)

Dimensions & weight

Wheelbase: 1662 mm
Overall length: 2357 mm
Seat height: 640 mm
Dry weight: 292.1 kg
Wet weight: 300.0 kg
Fuel capacity: 18.60 litres
Ground clearance: 125 mm
Oil capacity: 2.80 litres

Chassis & suspension

Front suspension: Telescopic fork
Rear suspension: Twin shocks
Front wheel travel: 155 mm
Rear wheel travel: 84 mm
Rake (fork angle): 30.5°
Trail: 130 mm

Brakes & wheels

Front brakes: Dual disc
Front brakes diameter: 292 mm
Rear brakes: Single disc
Rear brakes diameter: 292 mm
Front tyre: 100/90-H19
Rear tyre: 160/70-V17

Compiled from manufacturer documentation and user contributions, corrected on an ongoing basis. Spotted something wrong? Tell us.

What changed, year to year

Differences highlighted

Specification	1996	2002	2007	2012	2017
Capacity	1338 cc	1449 cc	1584 cc	1690 cc	1690 cc
Dry weight	272 kg	279 kg	—	292 kg	298 kg
Seat height	754 mm	640 mm	640 mm	640 mm	680 mm
Fuel capacity	—	18.6 L	18.6 L	18.6 L	17.8 L
