2004 Harley-Davidson FXSTI Softail Standard

+ Add a photo

Cruisers

2004Harley-Davidson FXSTI Softail Standard

Rate this bike

30 fields on record

The 2004 Harley-Davidson FXSTI Softail Standard is a classic cruiser ideal for riders seeking authentic V-twin performance and timeless styling. Known for its air-cooled 1449cc engine delivering strong low-end torque, it combines traditional Harley character with modern fuel injection reliability. Perfect for both highway cruising and weekend rides, this softail offers comfortable ergonomics and the iconic rigid-look frame that defines the brand.

Capacity: 1449.0 ccm
Engine: V-Twin
Gearbox: 5-speed
Dry weight: 292.0 kg
Seat height: 663 mm
Power: 87.0 HP (64.0 kW)

⇄ Compare with another bike ＋ Add to garage All model years ⚠ Recalls listed (1)

Other years 2004 2005 2006

How it rides

Editorial estimate from the spec sheet - not lab tested

Off-road & trail5%

Cornering30%

City riding45%

Daily riding55%

Touring60%

Two-up55%

Track10%

Best for: Built for relaxed boulevard cruising and stylish presence rather than outright speed or sport performance.
Built for: A classic American V-twin cruiser with a big torquey engine, laid-back ergonomics, and old-school custom styling that rewards a relaxed, unhurried riding pace.
Not ideal for: Not a good fit for riders seeking sharp cornering ability, high-speed touring comfort, or any kind of off-road capability.

Scores are derived from the spec sheet using the same model across every bike, so they compare like for like.

Will it fit you?

Worked out in your browser - nothing is sent to us

Your height

Inseam (optional)

Units

At 663mm, a rider of 68.9" with a 31" (estimated) inseam will reach the ground with both feet flat on the 2004 Harley-Davidson FXSTI Softail Standard, with a cramped knee angle of around 75 degrees and an upright riding position.

Assumes about 30mm of suspension sag once seated. This is an approximation from category-typical geometry, not a measurement of this bike or of you - sit on one before you buy.

More bikes at 750 mm or under — Short Kings →

Find bikes that fit your height →

Full specifications

Engine

Capacity: 1449.0 ccm
Power: 87.0 HP (64.0 kW)
Torque: 102.0 Nm (10.4 kgf-m)
Engine type: V-Twin
Power/weight ratio: 0.2979 HP/kg (dry)
Bore x stroke: 95.3 x 101.6 mm
Compression: 8.8:1
Cooling system: Air
Fuel system: Injection
Valves per cylinder: 2

Transmission

Gearbox: 5-speed
Transmission type: Manual
Final drive: Belt
Clutch: Multi-plate clutch with diaphragm spring in oil bath

Dimensions & weight

Wheelbase: 1695 mm
Overall length: 2412 mm
Seat height: 663 mm
Dry weight: 292.0 kg
Fuel capacity: 18.90 litres
Ground clearance: 142 mm

Chassis & suspension

Rake (fork angle): 32.0°
Trail: 130 mm

Brakes & wheels

Front brakes: Single disc
Front brakes diameter: 292 mm
Rear brakes: Single disc
Rear brakes diameter: 292 mm
Front tyre: 90/90-21
Rear tyre: 150/80-16

Other

Color options: Vivid black, brilliant silver, sierra red, impact blue

Compiled from manufacturer documentation and user contributions, corrected on an ongoing basis. Spotted something wrong? Tell us.

What changed, year to year

Differences highlighted

Specification	2004	2005	2006
Capacity	1449 cc	1449 cc	1442 cc
Dry weight	292 kg	292 kg	295 kg
Seat height	663 mm	663 mm	663 mm
Fuel capacity	18.9 L	18.9 L	18.9 L

Illustrative - generated automatically by diffing the year records already on file, not a manufacturer-published changelog.

Safety Recalls

⚠ 1 recall may apply

FUEL SYSTEM, GASOLINE:STORAGE:TANK ASSEMBLYSep 2004 · 04V465000

ON CERTAIN MOTORCYCLES, A CONDITION OCCURS THAT COULD ALLOW PRESSURE TO BUILD UP IN THE FUEL TANK. ON FUEL INJECTED VEHICLES, THIS CONDITION COULD CAUSE FUEL TO SPRAY OUT UNEXPECTEDLY WHEN THE FUEL CAP IS REMOVED. ON CARBURETED VEHICLES, EXCESSIVE FUEL COULD BE TRANSFERRED TO THE CARBURETOR, WHICH WOULD EVENTUALLY ALLOW FUEL TO DRIP FROM THE AIR CLEANER.

Risk: THESE SITUATIONS COULD CAUSE SERIOUS PERSONAL INJURY OR CREATE A FIRE HAZARD FOR PERSONS OR PROPERTY ON OR NEAR THE MOTORCYCLE.

Remedy: DEALERS WILL TEST EACH CANISTER FOR BLOCKAGE, THEN REPLACE AS NECESSARY. THE RECALL BEGAN NOVEMBER 4, 2004. OWNERS SHOULD CONTACT HARLEY-DAVIDSON AT 1-414-343-4056.

These recalls cover some 2004 bikes of this model. Whether one applies to a specific bike, and whether the repair has already been done, depends on its VIN — check your VIN with NHTSA or ask a dealer.

Source: NHTSA. View all Harley-Davidson recalls →
