Cruisers
2013Harley-Davidson Softail Fat Boy Special
35 fields on record
The 2013 Harley-Davidson Softail Fat Boy Special is a heavyweight custom cruiser built for riders seeking classic styling with modern performance. Its air-cooled 1690cc Twin Cam engine delivers substantial low-end torque ideal for laid-back cruising, while the iconic fat front tire and chrome detailing define its unmistakable aesthetic appeal.
- Capacity
- 1690.0 ccm
- Engine
- V-Twin, four-stroke
- Gearbox
- 6-speed
- Dry weight
- 313.0 kg
- Seat height
- 670 mm
- Power
- 103.0 HP (75.8 kW)
How it rides
Editorial estimate from the spec sheet - not lab tested- Best for
- It's built for boulevard cruising and making a bold visual statement rather than for outright speed or long-distance touring efficiency.
- Built for
- It delivers a big, torquey V-twin rumble with strong low-end grunt, favoring relaxed, deliberate cruising over aggressive cornering or high-rpm thrills.
- Not ideal for
- This is not the right bike for riders seeking agile canyon carving, off-road capability, or a lightweight, nimble daily commuter.
Scores are derived from the spec sheet using the same model across every bike, so they compare like for like.
Will it fit you?
Worked out in your browser - nothing is sent to usRange and running costs
Worked out in your browser - nothing is sent to usBased on the maker's published fuel consumption and tank size. Real-world figures depend on how and where you ride, and the last litres of a tank are reserve. Prices shown greyed are examples - type your own.
Engine
- Capacity
- 1690.0 ccm
- Power
- 103.0 HP (75.8 kW)
- CO2 Emissions
- 130 CO2 g/km
- Torque
- 134.0 Nm (13.7 kgf-m) @ 3000 RPM
- Engine type
- V-Twin, four-stroke
- Fuel consumption
- 5.60 litres/100 km (17.9 km/l)
- Power/weight ratio
- 0.3291 HP/kg (dry)
- Bore x stroke
- 98.4 x 111.1 mm
- Compression
- 9.6:1
- Cooling system
- Air
- Fuel system
- Injection
- Starting
- Electric
- Valves per cylinder
- 4
Transmission
- Gearbox
- 6-speed
- Transmission type
- Manual
- Final drive
- Belt
- Clutch
- Multi-plate with diaphragm spring in oil bath
Dimensions & weight
- Wheelbase
- 1630 mm
- Overall length
- 2385 mm
- Seat height
- 670 mm
- Dry weight
- 313.0 kg
- Wet weight
- 330.0 kg
- Fuel capacity
- 18.90 litres
- Ground clearance
- 125 mm
- Oil capacity
- 3.30 litres
Chassis & suspension
- Front suspension
- Telescopic fork
- Rear suspension
- Twin shocks
- Rake (fork angle)
- 31.6°
- Trail
- 147 mm
Brakes & wheels
- Front brakes
- Double disc. 4-piston
- Rear brakes
- Single disc. 2-piston
- Front tyre
- 140/75-R17
- Rear tyre
- 200/55-R17
Other
- Color options
- Anniversary Vintage Bronze/Anniversary Vintage Black, Candy Orange, Black Denim, Vivid Black
Compiled from manufacturer documentation and user contributions, corrected on an ongoing basis. Spotted something wrong? Tell us.
What changed, year to year
Differences highlighted| Specification | 2013 | 2014 | 2015 | 2016 |
|---|---|---|---|---|
| Capacity | 1690 cc | 1690 cc | 1690 cc | 1690 cc |
| Dry weight | 313 kg | 313 kg | 318 kg | 320 kg |
| Seat height | 670 mm | 670 mm | 670 mm | 670 mm |
| Fuel capacity | 18.9 L | 18.9 L | 18.9 L | 18.9 L |
Illustrative - generated automatically by diffing the year records already on file, not a manufacturer-published changelog.
Rider Reviews
Common questions
What is the engine size of the Harley-Davidson Softail Fat Boy Special?
The 2013 Harley-Davidson Softail Fat Boy Special has a Capacity of 1690.0 ccm (103.13 cubic inches).
What engine power does the Harley-Davidson Softail Fat Boy Special have?
The 2013 Harley-Davidson Softail Fat Boy Special has a Power of 103.0 HP (75.8 kW).
How many gears does the Harley-Davidson Softail Fat Boy Special have?
The 2013 Harley-Davidson Softail Fat Boy Special has a Gearbox of 6-speed.
What is the torque of the Harley-Davidson Softail Fat Boy Special?
The 2013 Harley-Davidson Softail Fat Boy Special has a Torque of 134.0 Nm (13.7 kgf-m or 98.8 ft.lbs) @ 3000 RPM.
How much does the Harley-Davidson Softail Fat Boy Special weigh?
The 2013 Harley-Davidson Softail Fat Boy Special has a Dry weight of 313.0 kg (690.0 pounds).
