Cruisers

1990Harley-Davidson XLH Sportster 883 Standard

22 fields on record

The 1990 Harley-Davidson XLH Sportster 883 Standard suits riders seeking an accessible, classic American cruiser experience. Known for its nimble handling and approachable 883cc V-twin engine, this entry-level Harley delivers authentic character with manageable power and weight, making it ideal for beginning enthusiasts and city riders alike.

Capacity: 883.0 ccm
Engine: V-Twin, four-stroke
Gearbox: 4-speed
Dry weight: 222.0 kg
Seat height: 711 mm
Power: 48.0 HP (35.3 kW) @ 6000 RPM

⇄ Compare with another bike ＋ Add to garage All model years

Other years 1988 1989 1990 1991 1992 1993 1994 1995 1996 1997 1998 1999 2000

How it rides

Editorial estimate from the spec sheet - not lab tested

Off-road & trail5%

Cornering35%

City riding60%

Daily riding60%

Touring40%

Two-up40%

Track10%

Best for: Built for relaxed cruising and boulevard riding rather than outright speed or sport performance.
Built for: A classic, air-cooled American cruiser with laid-back torque, thumping V-twin character, and understated cool rather than aggressive performance.
Not ideal for: Not the right choice for riders seeking high-speed touring capability, sharp cornering agility, or any off-road ambition.

Scores are derived from the spec sheet using the same model across every bike, so they compare like for like.

Will it fit you?

Worked out in your browser - nothing is sent to us

Your height

Inseam (optional)

Units

At 711mm, a rider of 68.9" with a 31" (estimated) inseam will reach the ground with both feet flat on the 1990 Harley-Davidson XLH Sportster 883 Standard, with a cramped knee angle of around 75 degrees and an upright riding position.

Assumes about 30mm of suspension sag once seated. This is an approximation from category-typical geometry, not a measurement of this bike or of you - sit on one before you buy.

More bikes at 750 mm or under — Short Kings →

Find bikes that fit your height →

Full specifications

Engine

Capacity: 883.0 ccm
Power: 48.0 HP (35.3 kW) @ 6000 RPM
Engine type: V-Twin, four-stroke
Power/weight ratio: 0.2162 HP/kg (dry)
Bore x stroke: 76.2 x 96.8 mm
Compression: 9.0:1
Cooling system: Air
Valves per cylinder: 2
Torque: Not on record - add it

Transmission

Gearbox: 4-speed
Transmission type: Manual
Final drive: Chain

Performance

Top speed: 149.0 km/h (92.6 mph)

Dimensions & weight

Wheelbase: 1510 mm
Seat height: 711 mm
Dry weight: 222.0 kg
Wet weight: 235.0 kg
Fuel capacity: 8.50 litres

Brakes & wheels

Front brakes: Single disc
Rear brakes: Single disc
Front tyre: MJ 90-19
Rear tyre: MT 90-16

Specs last verified against published sources: October 2026.

Compiled from manufacturer documentation and user contributions, corrected on an ongoing basis. Spotted something wrong? Tell us.

What changed, year to year

Differences highlighted

Specification	1988	1990	1991	1994	1997	2000
Capacity	883 cc	883 cc	883 cc	883 cc	883 cc	883 cc
Dry weight	222 kg	222 kg	222 kg	222 kg	222 kg	222 kg
Seat height	711 mm	711 mm	711 mm	711 mm	711 mm	711 mm
Fuel capacity	8.5 L	8.5 L	8.5 L	8.5 L	8.5 L	12.5 L
