Naked Motorcycles
2014Honda CB223S
38 fields on record
The 2014 Honda CB223S is an approachable middleweight suited for novice and commuter riders seeking reliable everyday transportation. Powered by a modest 223cc single-cylinder four-stroke engine producing 16 horsepower, it prioritizes fuel efficiency and low maintenance over performance. Known for its straightforward design and user-friendly handling, this allrounder excels in urban riding and casual cruising.
- Capacity
- 223.0 ccm
- Engine
- Single, four-stroke
- Gearbox
- 6-speed
- Wet weight
- 135.0 kg
- Seat height
- 780 mm
- Power
- 16.0 HP (11.7 kW) @ 7000 RPM
How it rides
Editorial estimate from the spec sheet - not lab tested- Best for
- It's designed as a lightweight, economical commuter for easy city riding and short trips rather than outright performance.
- Built for
- The single-cylinder air-cooled engine gives a simple, low-stress riding experience with modest but adequate power for everyday use.
- Not ideal for
- This bike is not for riders seeking highway speed, long-distance touring comfort, or serious off-road capability.
Scores are derived from the spec sheet using the same model across every bike, so they compare like for like.
Will it fit you?
Worked out in your browser - nothing is sent to usRange and running costs
Worked out in your browser - nothing is sent to usBased on the maker's published fuel consumption and tank size. Real-world figures depend on how and where you ride, and the last litres of a tank are reserve. Prices shown greyed are examples - type your own.
Engine
- Capacity
- 223.0 ccm
- Power
- 16.0 HP (11.7 kW) @ 7000 RPM
- CO2 Emissions
- 57 CO2 g/km
- Torque
- 18.0 Nm (1.8 kgf-m) @ 5500 RPM
- Engine type
- Single, four-stroke
- Fuel consumption
- 2.40 litres/100 km (41.7 km/l)
- Power/weight ratio
- 0.1185 HP/kg (wet)
- Bore x stroke
- 65.5 x 66.2 mm
- Compression
- 9.0:1
- Cooling system
- Air
- Fuel system
- Carburettor
- Starting
- Electric
- Ignition
- CDI
- Lubrication system
- Pump
Transmission
- Gearbox
- 6-speed
- Transmission type
- Manual
- Final drive
- Chain
- Clutch
- Multi-plate coil spring wet
Dimensions & weight
- Wheelbase
- 1395 mm
- Overall length
- 2100 mm
- Overall width
- 780 mm
- Overall height
- 1110 mm
- Seat height
- 780 mm
- Wet weight
- 135.0 kg
- Fuel capacity
- 11.00 litres
- Ground clearance
- 135 mm
- Dry weight
- Not on record - add it
Chassis & suspension
- Frame
- Semi-double cradle
- Front suspension
- Telescopic fork
- Rear suspension
- Swing arm
- Rake (fork angle)
- 25.5°
- Trail
- 84 mm
Brakes & wheels
- Front brakes
- Single disc. Hydraulic
- Rear brakes
- Expanding brake (drum brake)
- Front tyre
- 110/90-18
- Rear tyre
- 130/80-18
Other
- Color options
- Graphite Black, Candy Graceful Red, Cortine White
- Comments
- Sold in Japan.
Compiled from manufacturer documentation and user contributions, corrected on an ongoing basis. Spotted something wrong? Tell us.
What changed, year to year
Differences highlighted| Specification | 2011 | 2012 | 2014 | 2015 | 2016 |
|---|---|---|---|---|---|
| Capacity | 223 cc | 223 cc | 223 cc | 223 cc | 223 cc |
| Seat height | 780 mm | 780 mm | 780 mm | 780 mm | 780 mm |
| Fuel capacity | 11 L | 11 L | 11 L | 11 L | 11 L |
Illustrative - generated automatically by diffing the year records already on file, not a manufacturer-published changelog.
Rider Reviews
Common questions
What is the engine size of the Honda CB223S?
The 2014 Honda CB223S has a Capacity of 223.0 ccm (13.61 cubic inches).
What engine power does the Honda CB223S have?
The 2014 Honda CB223S has a Power of 16.0 HP (11.7 kW) @ 7000 RPM.
How many gears does the Honda CB223S have?
The 2014 Honda CB223S has a Gearbox of 6-speed.
What is the torque of the Honda CB223S?
The 2014 Honda CB223S has a Torque of 18.0 Nm (1.8 kgf-m or 13.3 ft.lbs) @ 5500 RPM.
How much does the Honda CB223S weigh?
The 2014 Honda CB223S has a Wet weight of 135.0 kg (297.6 pounds).
Shop this bike
Affiliate linksWe may earn a commission from qualifying eBay or Amazon purchases made through these links. As an Amazon Associate I earn from qualifying purchases.
The 2014 Honda CB223S is a reliable and versatile motorcycle that offers great performance and classic styling. With its 223cc single-cylinder engine, the CB223S delivers smooth power delivery and excellent fuel efficiency. The bike's lightweight and nimble handling make it perfect for both urban commuting and weekend adventures. The comfortable riding position and responsive brakes further enhance the overall riding experience. Whether you're a new rider or a seasoned veteran, the Honda CB223S is a fantastic choice for anyone looking for a fun and practical motorcycle.
Overall, the 2014 Honda CB223S is a fantastic motorcycle that offers a great balance of performance, reliability, and style. Its smooth power delivery and nimble handling make it ideal for both city streets and long stretches of open road. Whether you're a beginner or an experienced rider, the CB223S is sure to impress with its versatility and enjoyable riding experience. If you're in the market for a practical and enjoyable motorcycle, the 2014 Honda CB223S is definitely worth considering.
