Sportbikes
2004Honda CBR125R
40 fields on record
The 2004 Honda CBR 125 R is an entry-level sport bike designed for new riders and commuters seeking an affordable, reliable machine. Its lightweight 125cc single-cylinder engine delivers manageable power while maintaining excellent fuel efficiency. Known for its user-friendly handling and practical 6-speed gearbox, it excels as a learner bike and daily urban transport.
- Capacity
- 125.0 ccm
- Engine
- Single, four-stroke
- Gearbox
- 6-speed
- Dry weight
- 115.0 kg
- Seat height
- 776 mm
- Power
- 15.0 HP (11.0 kW)
How it rides
Editorial estimate from the spec sheet - not lab tested- Best for
- Built primarily for city commuting, learning to ride, and light sport-styled fun rather than outright performance.
- Built for
- A nimble, approachable small-displacement sportbike that rewards smooth riding over aggressive throttle use.
- Not ideal for
- Not suited for riders wanting highway touring, high-speed performance, or off-road capability.
Scores are derived from the spec sheet using the same model across every bike, so they compare like for like.
Will it fit you?
Worked out in your browser - nothing is sent to usEngine
- Capacity
- 125.0 ccm
- Power
- 15.0 HP (11.0 kW)
- Engine type
- Single, four-stroke
- Power/weight ratio
- 0.1304 HP/kg (dry)
- Bore x stroke
- 58.0 x 47.2 mm
- Compression
- 11.0:1
- Cooling system
- Liquid
- Fuel system
- Carburettor
- Starting
- Electric
- Ignition
- Capacitor Discharge (CDI)
- Valves per cylinder
- 2
- Lubrication system
- Forced pressure and wet sump
- Torque
- Not on record - add it
Transmission
- Gearbox
- 6-speed
- Transmission type
- Manual
- Final drive
- Chain
- Clutch
- Wet, multiplate with coil springs
Dimensions & weight
- Wheelbase
- 1294 mm
- Overall length
- 1920 mm
- Overall width
- 675 mm
- Overall height
- 1070 mm
- Seat height
- 776 mm
- Dry weight
- 115.0 kg
- Wet weight
- 137.0 kg
- Fuel capacity
- 10.00 litres
- Ground clearance
- 172 mm
- Oil capacity
- 1.00 litres
Chassis & suspension
- Frame
- Diamond, steel twin-spar
- Front suspension
- 31mm telescopic fork
- Rear suspension
- Monoshock damper
- Front wheel travel
- 109 mm
- Rear wheel travel
- 120 mm
- Rake (fork angle)
- 25.0°
- Trail
- 88 mm
Brakes & wheels
- Front brakes
- Single disc
- Front brakes diameter
- 276 mm
- Rear brakes
- Single disc
- Rear brakes diameter
- 220 mm
- Front tyre
- 80/90-17
- Rear tyre
- 110/80-17
Compiled from manufacturer documentation and user contributions, corrected on an ongoing basis. Spotted something wrong? Tell us.
What changed, year to year
Differences highlighted| Specification | 2004 | 2008 | 2012 | 2015 | 2019 |
|---|---|---|---|---|---|
| Capacity | 125 cc | 125 cc | 125 cc | 125 cc | 125 cc |
| Dry weight | 115 kg | 127 kg | 137 kg | — | — |
| Seat height | 776 mm | 776 mm | 793 mm | 795 mm | 795 mm |
| Fuel capacity | 10 L | 10 L | 13 L | 13 L | 13 L |
Illustrative - generated automatically by diffing the year records already on file, not a manufacturer-published changelog.
Rider Reviews
Common questions
What is the engine size of the Honda CBR125R?
The 2004 Honda CBR125R has a Capacity of 125.0 ccm (7.63 cubic inches).
What engine power does the Honda CBR125R have?
The 2004 Honda CBR125R has a Power of 15.0 HP (11.0 kW).
How many gears does the Honda CBR125R have?
The 2004 Honda CBR125R has a Gearbox of 6-speed.
How much does the Honda CBR125R weigh?
The 2004 Honda CBR125R has a Dry weight of 115.0 kg (253.5 pounds).
