2025Honda CB500X
45 fields on record
The 2025 Honda CB500X is a mid-size adventure bike for A2 licence holders and riders who want an all-rounder. Its liquid-cooled 471cc parallel twin makes 47 hp and 43 Nm through a six-speed gearbox. ABS and a windscreen are standard, with an 833 mm seat and a 17.5-litre tank for long range. It weighs 199 kg.
- Capacity
- 471.0 ccm
- Engine
- Parallel Twin, four-stroke
- Gearbox
- 6-speed
- Dry weight
- 178.0 kg
- Seat height
- 833 mm
- Power
- 47.0 HP (34.3 kW) @ 8600 RPM
How it rides
Editorial estimate from the spec sheet - not lab tested- Best for
- Built for long road journeys with the ability to handle gravel and light trails along the way.
- Built for
- An adventure bike from Honda with a 471cc engine; its character is versatile and engaging, with 47 hp on tap.
- Not ideal for
- Not for riders who want a low, light city bike or serious competition off-road riding.
Scores are derived from the spec sheet using the same model across every bike, so they compare like for like.
Will it fit you?
Worked out in your browser - nothing is sent to usRange and running costs
Worked out in your browser - nothing is sent to usBased on the maker's published fuel consumption and tank size. Real-world figures depend on how and where you ride, and the last litres of a tank are reserve. Prices shown greyed are examples - type your own.
Engine
- Capacity
- 471.0 ccm
- Power
- 47.0 HP (34.3 kW) @ 8600 RPM
- Torque
- 43.0 Nm (4.4 kgf-m) @ 6500 RPM
- Engine type
- Parallel Twin, four-stroke
- Fuel consumption
- 3.60 litres/100 km (27.8 km/l)
- Power/weight ratio
- 0.2640 HP/kg (dry)
- Bore x stroke
- 67.0 x 66.8 mm
- Compression
- 10.7:1
- Cooling system
- Liquid
- Fuel system
- Injection
- Starting
- Electric
- Ignition
- Computer-controlled digital transistorized with electronic advance
- Valves per cylinder
- 4
Transmission
- Gearbox
- 6-speed
- Transmission type
- Manual
- Final drive
- Chain
- Clutch
- Wet multiplate
- Chain size
- 520
Dimensions & weight
- Wheelbase
- 1443 mm
- Overall length
- 2155 mm
- Overall width
- 826 mm
- Overall height
- 1358 mm
- Seat height
- 833 mm
- Dry weight
- 178.0 kg
- Wet weight
- 199.0 kg
- Fuel capacity
- 17.50 litres
- Ground clearance
- 180 mm
- Oil capacity
- 3.20 litres
Chassis & suspension
- Frame
- Diamond, steel.
- Front suspension
- 41mm telescopic fork
- Rear suspension
- Pro-Link® single shock with nine-position spring preload adjustability
- Front wheel travel
- 150 mm
- Rear wheel travel
- 135 mm
- Rake (fork angle)
- 27.5°
- Trail
- 108 mm
Brakes & wheels
- Front brakes
- Double disc. ABS. Wave disc. 4-piston calipers.
- Front brakes diameter
- 296 mm
- Rear brakes
- Single disc. ABS. Wave disc.
- Rear brakes diameter
- 240 mm
- ABS
- Yes
- Front tyre
- 110/80-19
- Rear tyre
- 160/60-17
Other
- Color options
- Pearl Organic Green
- Comments
- Model ID: CB500XA. Windscreen.
Specs last verified against published sources: .
Compiled from manufacturer documentation and user contributions, corrected on an ongoing basis. Spotted something wrong? Tell us.
What changed, year to year
Differences highlighted| Specification | 2013 | 2016 | 2020 | 2023 | 2025 | 2026 |
|---|---|---|---|---|---|---|
| Capacity | 471 cc | 471 cc | 471 cc | 471 cc | 471 cc | 471 cc |
| Dry weight | 178 kg | 178 kg | 178 kg | 178 kg | 178 kg | 178 kg |
| Seat height | 810 mm | 810 mm | 812 mm | 833 mm | 833 mm | 833 mm |
| Fuel capacity | 17.3 L | 17.3 L | 17.7 L | 17.5 L | 17.5 L | 17.5 L |
Illustrative - generated automatically by diffing the year records already on file, not a manufacturer-published changelog.
Rider Reviews
Common questions
What is the engine size of the Honda CB500X?
The 2025 Honda CB500X has a Capacity of 471.0 ccm (28.74 cubic inches).
What engine power does the Honda CB500X have?
The 2025 Honda CB500X has a Power of 47.0 HP (34.3 kW) @ 8600 RPM.
How many gears does the Honda CB500X have?
The 2025 Honda CB500X has a Gearbox of 6-speed.
What is the torque of the Honda CB500X?
The 2025 Honda CB500X has a Torque of 43.0 Nm (4.4 kgf-m or 31.7 ft.lbs) @ 6500 RPM.
How much does the Honda CB500X weigh?
The 2025 Honda CB500X has a Dry weight of 178.0 kg (392.4 pounds).
