Cruisers
2009Honda VTX1300R
34 fields on record
The 2009 Honda VTX1300R is a cruiser built for riders seeking classic styling with modern reliability. Its 1312cc V-twin engine delivers smooth, accessible power ideal for both experienced and newer cruiser enthusiasts. Known for its aggressive stance, comfortable ergonomics, and shaft-driven dependability, the VTX1300R excels as an affordable entry point into the cruiser category.
- Capacity
- 1312.0 ccm
- Engine
- V-Twin, four-stroke
- Gearbox
- 5-speed
- Dry weight
- 303.5 kg
- Seat height
- 695 mm
- Power
- 63.0 HP (46.3 kW)
What’s new for the 2009 Honda VTX1300R
vs the 2008| Spec | 2008 | 2009 |
|---|---|---|
| Rear suspension | Dual shocks with five-position spring-preload adjustability; 3.7-inch travel | Dual shocks with five-position spring-preload adjustability |
| Front brakes | Single disc. disc with twin-piston caliper | Single disc. Twin-piston caliper. |
| Rear brakes | Single disc. disc with single-piston caliper | Single disc |
How it rides
Editorial estimate from the spec sheet - not lab tested- Best for
- It's built for relaxed, torque-driven boulevard cruising and weekend rides rather than outright speed or sport handling.
- Built for
- A big-hearted, laid-back V-twin cruiser that rewards smooth, unhurried riding with strong low-end torque and classic shaft-drive simplicity.
- Not ideal for
- It's not for riders seeking sharp cornering agility, off-road capability, or lightweight nimbleness in city traffic.
Scores are derived from the spec sheet using the same model across every bike, so they compare like for like.
Will it fit you?
Worked out in your browser - nothing is sent to usEngine
- Capacity
- 1312.0 ccm
- Power
- 63.0 HP (46.3 kW)
- Engine type
- V-Twin, four-stroke
- Power/weight ratio
- 0.2076 HP/kg (dry)
- Bore x stroke
- 89.5 x 104.3 mm
- Compression
- 9.2:1
- Cooling system
- Liquid
- Fuel system
- Carburettor
- Starting
- Electric
- Ignition
- Digital with three-dimensional mapping, two spark plugs per cylinder
- Valves per cylinder
- 3
- Torque
- Not on record - add it
Transmission
- Gearbox
- 5-speed
- Transmission type
- Manual
- Final drive
- Shaft
Dimensions & weight
- Wheelbase
- 1669 mm
- Seat height
- 695 mm
- Dry weight
- 303.5 kg
- Wet weight
- 322.1 kg
- Fuel capacity
- 18.20 litres
Chassis & suspension
- Frame
- Aluminium
- Front suspension
- 41mm fork
- Rear suspension
- Dual shocks with five-position spring-preload adjustability
- Front wheel travel
- 130 mm
- Rear wheel travel
- 94 mm
- Rake (fork angle)
- 32.0°
- Trail
- 144 mm
Brakes & wheels
- Front brakes
- Single disc. Twin-piston caliper.
- Front brakes diameter
- 336 mm
- Rear brakes
- Single disc
- Rear brakes diameter
- 296 mm
- Front tyre
- 140/80-17
- Rear tyre
- 170/80-15
Other
- Color options
- Silver Metallic, Metallic Black and Bright Blue Metallic
Specs last verified against published sources: .
Compiled from manufacturer documentation and user contributions, corrected on an ongoing basis. Spotted something wrong? Tell us.
What changed, year to year
Differences highlighted| Specification | 2005 | 2007 | 2009 | 2010 | 2012 |
|---|---|---|---|---|---|
| Capacity | 1312 cc | 1312 cc | 1312 cc | 1312 cc | 1312 cc |
| Dry weight | 304 kg | 304 kg | 304 kg | 304 kg | 304 kg |
| Seat height | 695 mm | 695 mm | 695 mm | 695 mm | 696 mm |
| Fuel capacity | 18.2 L | 18.2 L | 18.2 L | 18.2 L | 18.2 L |
Illustrative - generated automatically by diffing the year records already on file, not a manufacturer-published changelog.
Rider Reviews
Common questions
What is the engine size of the Honda VTX1300R?
The 2009 Honda VTX1300R has a Capacity of 1312.0 ccm (80.06 cubic inches).
What engine power does the Honda VTX1300R have?
The 2009 Honda VTX1300R has a Power of 63.0 HP (46.3 kW).
How many gears does the Honda VTX1300R have?
The 2009 Honda VTX1300R has a Gearbox of 5-speed.
How much does the Honda VTX1300R weigh?
The 2009 Honda VTX1300R has a Dry weight of 303.5 kg (669.1 pounds).
