Scooters
2017Honda X-ADV
39 fields on record
The 2017 Honda X-Adv is a crossover scooter designed for riders seeking adventure-focused practicality and comfort on varied terrain. Known for its innovative blend of scooter convenience and adventure bike capability, it features a spacious 13.1-liter fuel tank, comfortable 820mm seat height, and advanced Prolink suspension for handling both urban commuting and light off-road exploration.
- Capacity
- 745.0 ccm
- Engine
- Parallel Twin, four-stroke
- Gearbox
- 6-speed
- Wet weight
- 238.0 kg
- Seat height
- 820 mm
- Power
- 54.0 HP (40.3 kW) @ 6250 RPM
How it rides
Editorial estimate from the spec sheet - not lab tested- Best for
- A crossover urban explorer: built for daily commuting, city errands and light-adventure back roads, with underseat storage and touring potential for weekend escapes.
- Built for
- Quirky and clever - part maxi-scooter, part adventure bike. Torquey 745cc twin, smart-key convenience and go-anywhere-in-the-city attitude give it real personality.
- Not ideal for
- Not for track-day chasers, serious off-road riders needing knobby-tire capability, or those wanting outright sportbike speed and razor-sharp handling.
Scores are derived from the spec sheet using the same model across every bike, so they compare like for like.
Will it fit you?
Worked out in your browser - nothing is sent to usEngine
- Capacity
- 745.0 ccm
- Power
- 54.0 HP (40.3 kW) @ 6250 RPM
- Torque
- 68.0 Nm (6.9 kgf-m) @ 4750 RPM
- Engine type
- Parallel Twin, four-stroke
- Power/weight ratio
- 0.2269 HP/kg (wet)
- Bore x stroke
- 77.0 x 80.0 mm
- Compression
- 10.7:1
- Cooling system
- Liquid
- Fuel system
- Injection
- Starting
- Electric
- Valves per cylinder
- 4
Transmission
- Gearbox
- 6-speed
- Transmission type
- Automatic
- Final drive
- Chain
- Clutch
- Wet multiplate Hydraulic Dual clutch (DCT)
Dimensions & weight
- Wheelbase
- 1590 mm
- Overall length
- 2245 mm
- Overall width
- 910 mm
- Overall height
- 1375 mm
- Seat height
- 820 mm
- Wet weight
- 238.0 kg
- Fuel capacity
- 13.10 litres
- Ground clearance
- 162 mm
- Oil capacity
- 4.10 litres
- Dry weight
- Not on record - add it
Chassis & suspension
- Frame
- Steel diamond
- Front suspension
- Telescopic fork
- Rear suspension
- Prolink with Rear Shock Preload adjustment
- Front wheel travel
- 154 mm
- Rear wheel travel
- 150 mm
- Rake (fork angle)
- 27.0°
- Trail
- 104 mm
Brakes & wheels
- Front brakes
- Double disc. ABS
- Front brakes diameter
- 296 mm
- Rear brakes
- Single disc. ABS
- ABS
- Yes
- Front tyre
- 120/70-R17
- Rear tyre
- 160/60-R15
Other
- Color options
- Silver, white, red
Specs last verified against published sources: .
Compiled from manufacturer documentation and user contributions, corrected on an ongoing basis. Spotted something wrong? Tell us.
What changed, year to year
Differences highlighted| Specification | 2017 | 2020 | 2022 | 2025 | 2027 |
|---|---|---|---|---|---|
| Capacity | 745 cc | 745 cc | 745 cc | 745 cc | 745 cc |
| Seat height | 820 mm | 820 mm | 820 mm | 820 mm | 820 mm |
| Fuel capacity | 13.1 L | 13 L | 13.2 L | 13.2 L | 13.2 L |
Illustrative - generated automatically by diffing the year records already on file, not a manufacturer-published changelog.
Rider Reviews
Common questions
What is the engine size of the Honda X-ADV?
The 2017 Honda X-ADV has a Capacity of 745.0 ccm (45.46 cubic inches).
What engine power does the Honda X-ADV have?
The 2017 Honda X-ADV has a Power of 54.0 HP (40.3 kW) @ 6250 RPM.
How many gears does the Honda X-ADV have?
The 2017 Honda X-ADV has a Gearbox of 6-speed.
What is the torque of the Honda X-ADV?
The 2017 Honda X-ADV has a Torque of 68.0 Nm (6.9 kgf-m or 50.2 ft.lbs) @ 4750 RPM.
How much does the Honda X-ADV weigh?
The 2017 Honda X-ADV has a Wet weight of 238.0 kg (524.7 pounds).
