2009Hyosung RX125D-E
28 fields on record
The 2009 Hyosung RX 125D-E is a lightweight trial motorcycle designed for novice and amateur riders seeking an affordable entry into off-road competition. Its 124cc four-stroke engine delivers modest power suitable for learning fundamental trial skills on technical terrain. Known for its responsive handling and nimble chassis, this bike excels in tight, challenging environments where precision and maneuverability matter most.
- Capacity
- 124.0 ccm
- Engine
- Single, four-stroke
- Gearbox
- 5-speed
- Dry weight
- 120.0 kg
- Seat height
- 850 mm
- Power
- 13.0 HP (9.6 kW)
What’s new for the 2009 Hyosung RX125D-E
vs the 2008| Spec | 2008 | 2009 |
|---|---|---|
| Power | 15.0 HP (11.0 kW) | 13.0 HP (9.6 kW) |
How it rides
Editorial estimate from the spec sheet - not lab tested- Best for
- This is a lightweight trials-style machine built for technical low-speed off-road obstacle riding rather than distance or speed.
- Built for
- A playful, momentum-light companion for picking through rocks, trails, and tight terrain, valuing balance and control over power delivery.
- Not ideal for
- Not for riders wanting highway speed, passenger comfort, or long-distance touring capability.
Scores are derived from the spec sheet using the same model across every bike, so they compare like for like.
Engine
- Capacity
- 124.0 ccm
- Power
- 13.0 HP (9.6 kW)
- Engine type
- Single, four-stroke
- Power/weight ratio
- 0.1083 HP/kg (dry)
- Cooling system
- Oil & air
- Fuel system
- Carburettor
- Starting
- Electric
- Ignition
- CDI
- Valves per cylinder
- 4
Transmission
- Gearbox
- 5-speed
- Transmission type
- Manual
- Final drive
- Chain
Dimensions & weight
- Wheelbase
- 1425 mm
- Overall length
- 2190 mm
- Overall width
- 800 mm
- Overall height
- 1160 mm
- Seat height
- 850 mm
- Dry weight
- 120.0 kg
- Fuel capacity
- 8.00 litres
- Ground clearance
- 295 mm
Chassis & suspension
- Front suspension
- Upside-down forks
- Rear suspension
- Monoshock
Brakes & wheels
- Front brakes
- Single disc
- Rear brakes
- Expanding brake (drum brake)
- Front tyre
- 2.75-21
- Rear tyre
- 4.10-18
Other
- Color options
- Black, orange
Compiled from manufacturer documentation and user contributions, corrected on an ongoing basis. Spotted something wrong? Tell us.
What changed, year to year
Differences highlighted| Specification | 2008 | 2009 | 2010 | 2011 |
|---|---|---|---|---|
| Capacity | 124 cc | 124 cc | 124 cc | 124 cc |
| Dry weight | 120 kg | 120 kg | 120 kg | 120 kg |
| Seat height | 850 mm | 850 mm | 850 mm | 850 mm |
| Fuel capacity | 8 L | 8 L | 8 L | 8 L |
Illustrative - generated automatically by diffing the year records already on file, not a manufacturer-published changelog.
Rider Reviews
Common questions
What is the engine size of the Hyosung RX125D-E?
The 2009 Hyosung RX125D-E has a Capacity of 124.0 ccm (7.57 cubic inches).
What engine power does the Hyosung RX125D-E have?
The 2009 Hyosung RX125D-E has a Power of 13.0 HP (9.6 kW).
How many gears does the Hyosung RX125D-E have?
The 2009 Hyosung RX125D-E has a Gearbox of 5-speed.
How much does the Hyosung RX125D-E weigh?
The 2009 Hyosung RX125D-E has a Dry weight of 120.0 kg (264.6 pounds).
