2009Johnny Pag Spyder
29 fields on record
The 2009 Johnny Pag Spyder is a lightweight custom cruiser powered by a 300cc boxer twin engine, ideal for novice and casual riders seeking an affordable, manageable ride. Its compact dimensions and modest 23.8 horsepower make it perfect for city commuting and weekend cruising. Known for its retro styling and reliability, the Spyder appeals to budget-conscious enthusiasts looking for classic cruiser aesthetics.
- Capacity
- 300.0 ccm
- Engine
- Boxer, four-stroke
- Gearbox
- 5-speed
- Wet weight
- 163.3 kg
- Seat height
- 508 mm
- Power
- 23.8 HP (17.5 kW) @ 6500 RPM
How it rides
Editorial estimate from the spec sheet - not lab tested- Best for
- It's built as a light custom-style cruiser for casual boulevard riding rather than speed or long-distance touring.
- Built for
- It has a laid-back, chopper-inspired cruiser personality with modest performance and relaxed, stretched-out ergonomics.
- Not ideal for
- It's not a good fit for riders seeking highway-passing power, aggressive cornering ability, or serious long-haul touring comfort.
Scores are derived from the spec sheet using the same model across every bike, so they compare like for like.
Will it fit you?
Worked out in your browser - nothing is sent to usEngine
- Capacity
- 300.0 ccm
- Power
- 23.8 HP (17.5 kW) @ 6500 RPM
- Torque
- 18.5 Nm (1.9 kgf-m)
- Engine type
- Boxer, four-stroke
- Power/weight ratio
- 0.1457 HP/kg (wet)
- Bore x stroke
- 57.0 x 53.0 mm
- Cooling system
- Liquid
- Fuel system
- Carburettor
- Starting
- Electric
- Ignition
- CDI
- Valves per cylinder
- 2
- Lubrication system
- Forced Lubrication
Transmission
- Gearbox
- 5-speed
- Transmission type
- Manual
- Final drive
- Chain
- Clutch
- Multiplate oil bath
Dimensions & weight
- Wheelbase
- 1854 mm
- Seat height
- 508 mm
- Wet weight
- 163.3 kg
- Ground clearance
- 152 mm
- Dry weight
- Not on record - add it
Chassis & suspension
- Front suspension
- 39 mm forks
- Rear suspension
- Dual shocks (fully-adjustable)
- Rake (fork angle)
- 42.0°
Brakes & wheels
- Front brakes
- Double disc. Twin-piston calipers
- Rear brakes
- Single disc. Twin-piston calipers
- Front tyre
- 80/90-21
- Rear tyre
- 160/90-18
Other
- Color options
- Solid Black, Black w/silver flames, Red w/silver flames, Blue w/silver flames, Silver w/silver flames
Compiled from manufacturer documentation and user contributions, corrected on an ongoing basis. Spotted something wrong? Tell us.
What changed, year to year
Differences highlighted| Specification | 2009 | 2010 |
|---|---|---|
| Capacity | 300 cc | 300 cc |
| Seat height | 508 mm | 508 mm |
Illustrative - generated automatically by diffing the year records already on file, not a manufacturer-published changelog.
Rider Reviews
Common questions
What is the engine size of the Johnny Pag Spyder?
The 2009 Johnny Pag Spyder has a Capacity of 300.0 ccm (18.31 cubic inches).
What engine power does the Johnny Pag Spyder have?
The 2009 Johnny Pag Spyder has a Power of 23.8 HP (17.5 kW) @ 6500 RPM.
How many gears does the Johnny Pag Spyder have?
The 2009 Johnny Pag Spyder has a Gearbox of 5-speed.
What is the torque of the Johnny Pag Spyder?
The 2009 Johnny Pag Spyder has a Torque of 18.5 Nm (1.9 kgf-m or 13.6 ft.lbs).
How much does the Johnny Pag Spyder weigh?
The 2009 Johnny Pag Spyder has a Wet weight of 163.3 kg (360.0 pounds).
