2009KTM 1190 RC8 R

Rate this bike

37 fields on record

The 2009 KTM 1190 RC8 R is a high-performance sport bike designed for experienced riders seeking raw aggression and cutting-edge technology. Its 1195cc V-twin engine delivers 167 horsepower and 123 Nm of torque through innovative dry-sump lubrication, making it renowned for sharp handling and distinctive Austrian engineering that challenges Japanese sport bike conventions.

Capacity: 1195.0 ccm
Engine: V-Twin, four-stroke
Gearbox: 6-speed
Dry weight: 182.0 kg
Seat height: 805 mm
Power: 167.6 HP (123.3 kW) @ 10250 RPM

⇄ Compare with another bike ＋ Add to garage All model years

Other years 2009 2010 2011 2012 2013 2014 2015

How it rides

Editorial estimate from the spec sheet - not lab tested

Off-road & trail5%

Cornering94%

City riding25%

Daily riding20%

Touring20%

Two-up15%

Track96%

Best for: Built primarily for track days and high-performance canyon carving rather than everyday transportation.
Built for: A hardcore, race-bred V-twin superbike that rewards precision and aggression with explosive acceleration and razor-sharp cornering ability.
Not ideal for: This is not a good choice for beginners, commuters, tall touring riders, or anyone prioritizing comfort and passenger accommodation.

Scores are derived from the spec sheet using the same model across every bike, so they compare like for like.

Will it fit you?

Worked out in your browser - nothing is sent to us

Your height

Inseam (optional)

Units

At 805mm, a rider of 68.9" with a 31" (estimated) inseam will reach the ground with both feet flat on the 2009 KTM 1190 RC8 R, with a cramped knee angle of around 70 degrees and a forward-leaning riding position.

Assumes about 30mm of suspension sag once seated. This is an approximation from category-typical geometry, not a measurement of this bike or of you - sit on one before you buy.

More bikes at 751-820 mm — Middle Ground →

Find bikes that fit your height →

Full specifications

Engine

Capacity: 1195.0 ccm
Power: 167.6 HP (123.3 kW) @ 10250 RPM
Torque: 123.0 Nm (12.5 kgf-m)
Engine type: V-Twin, four-stroke
Power/weight ratio: 0.9209 HP/kg (dry)
Bore x stroke: 105.0 x 69.0 mm
Compression: 13.5:1
Cooling system: Liquid
Fuel system: Injection
Starting: Electric
Ignition: Contactless, controlled, fully electronic ignition system with digital ignition timing adjustment
Valves per cylinder: 4
Lubrication system: Dry sump, pressure lubrication with 3 Eaton pumps

Transmission

Gearbox: 6-speed
Transmission type: Manual
Final drive: Chain
Clutch: Wet mDouble disk clutch, operated hydraulically

Dimensions & weight

Wheelbase: 1430 mm
Seat height: 805 mm
Dry weight: 182.0 kg
Fuel capacity: 16.50 litres
Ground clearance: 110 mm

Chassis & suspension

Frame: Chromium-Molybdenum trellis frame, powder-coated. Aluminium subframe.
Front suspension: WP-USD, 43 mm
Rear suspension: WP-Monoshock
Front wheel travel: 120 mm
Rear wheel travel: 120 mm
Rake (fork angle): 23.3°
Trail: 97 mm

Brakes & wheels

Front brakes: Double disc. Brem
Front brakes diameter: 320 mm
Rear brakes: Single disc
Rear brakes diameter: 220 mm
Front tyre: 120/70-ZR17
Rear tyre: 190/55-ZR17

Other

Color options: Black/orange

Compiled from manufacturer documentation and user contributions, corrected on an ongoing basis. Spotted something wrong? Tell us.

What changed, year to year

Differences highlighted

Specification	2009	2011	2012	2014	2015
Capacity	1195 cc	1195 cc	1195 cc	1195 cc	1195 cc
Dry weight	182 kg	182 kg	186 kg	184 kg	184 kg
Seat height	805 mm	805 mm	805 mm	805 mm	805 mm
Fuel capacity	16.5 L	16.5 L	16.5 L	16.5 L	16.5 L
