Enduro Bikes
2014KTM 150 XC
32 fields on record
The 2014 KTM 150 XC is a lightweight, two-stroke motocross machine designed for younger riders and smaller-framed competitors seeking competitive cross-country performance. Its liquid-cooled 143cc single-cylinder engine delivers responsive power with the simplicity and reliability two-stroke engines are known for. The 150 XC excels in tight terrain and technical sections where its nimble handling and manageable power delivery shine.
- Capacity
- 143.6 ccm
- Engine
- Single, two-stroke
- Gearbox
- 6-speed
- Dry weight
- 94.1 kg
- Seat height
- 992 mm
- Power
- 11.5 HP (8.5 kW)
What’s new for the 2014 KTM 150 XC
vs the 2013| Spec | 2013 | 2014 |
|---|---|---|
| Fuel capacity | 11.50 litres (3.04 US gallons) | not listed |
| Front suspension | WP Suspension Up Side Down 4860 MXMA CC | WP Suspension Up Side Down 4860 4CS |
| Rear suspension | WPSuspension 5018 BAVP DCC | WP Suspension 5018 BAVP DCC |
| Front brakes | Single disc | Single disc. Brake calipers on floating bearings |
| Rear brakes | Single disc | Single disc. Brake calipers on floating bearings |
How it rides
Editorial estimate from the spec sheet - not lab tested- Best for
- Built specifically for cross-country and motocross-style off-road racing, not for street riding or commuting.
- Built for
- A light, punchy, high-revving two-stroke that rewards aggressive, active riding with sharp agility and explosive but narrow power delivery typical of small-bore XC bikes.
- Not ideal for
- This is not the right bike for beginners, passengers, daily street use, or anyone seeking comfort, range, or a smooth, forgiving ride.
Scores are derived from the spec sheet using the same model across every bike, so they compare like for like.
Will it fit you?
Worked out in your browser - nothing is sent to usEngine
- Capacity
- 143.6 ccm
- Power
- 11.5 HP (8.5 kW)
- Engine type
- Single, two-stroke
- Power/weight ratio
- 0.1222 HP/kg (dry)
- Bore x stroke
- 56.0 x 58.4 mm
- Cooling system
- Liquid
- Fuel system
- Carburettor
- Starting
- Kick
- Ignition
- Contactless controlled fully electronic ignition with digital ignition adjustment, type Kokusan
- Lubrication system
- Mixture oil lubrication 1:40
- Torque
- Not on record - add it
Transmission
- Gearbox
- 6-speed
- Transmission type
- Manual
- Final drive
- Chain
- Clutch
- Multidisc clutch in oil bath/hydraulically activated
Dimensions & weight
- Wheelbase
- 1480 mm
- Seat height
- 992 mm
- Dry weight
- 94.1 kg
- Ground clearance
- 395 mm
Chassis & suspension
- Frame
- Central tube frame made of chrome molybdenum steel tubing
- Front suspension
- WP Suspension Up Side Down 4860 4CS
- Rear suspension
- WP Suspension 5018 BAVP DCC
- Front wheel travel
- 300 mm
- Rear wheel travel
- 317 mm
- Rake (fork angle)
- 26.5°
Brakes & wheels
- Front brakes
- Single disc. Brake calipers on floating bearings
- Front brakes diameter
- 260 mm
- Rear brakes
- Single disc. Brake calipers on floating bearings
- Rear brakes diameter
- 220 mm
- Front tyre
- 80/100-21
- Rear tyre
- 100/90-19
Other
- Color options
- Orange/black
Specs last verified against published sources: .
Compiled from manufacturer documentation and user contributions, corrected on an ongoing basis. Spotted something wrong? Tell us.
What changed, year to year
Differences highlighted| Specification | 2012 | 2013 | 2014 |
|---|---|---|---|
| Capacity | 144 cc | 144 cc | 144 cc |
| Dry weight | 94 kg | 94 kg | 94 kg |
| Seat height | 992 mm | 992 mm | 992 mm |
| Fuel capacity | 11.5 L | 11.5 L | — |
Illustrative - generated automatically by diffing the year records already on file, not a manufacturer-published changelog.
Rider Reviews
Common questions
What is the engine size of the KTM 150 XC?
The 2014 KTM 150 XC has a Capacity of 143.6 ccm (8.76 cubic inches).
What engine power does the KTM 150 XC have?
The 2014 KTM 150 XC has a Power of 11.5 HP (8.5 kW).
How many gears does the KTM 150 XC have?
The 2014 KTM 150 XC has a Gearbox of 6-speed.
How much does the KTM 150 XC weigh?
The 2014 KTM 150 XC has a Dry weight of 94.1 kg (207.5 pounds).
