2013KTM 200 XC-W
33 fields on record
The 2013 KTM 200 XC-W is a light two-stroke enduro bike, popular for tight woods riding. Its liquid-cooled 193cc single drives through a six-speed gearbox and chain. A 960 mm seat, 95 kg dry weight and 9.5-litre tank make it very agile.
- Capacity
- 193.0 ccm
- Engine
- Single, two-stroke
- Gearbox
- 6-speed
- Dry weight
- 95.0 kg
- Seat height
- 960 mm
- Power
- 19.3 HP (14.2 kW)
How it rides
Editorial estimate from the spec sheet - not lab tested- Best for
- Built purely for tight, technical enduro and trail riding rather than speed or road use.
- Built for
- A nimble, high-revving two-stroke that feels playful and responsive, thriving on quick direction changes and rough, technical trails.
- Not ideal for
- Not suitable for riders wanting highway comfort, passenger carrying, or a low-maintenance daily commuter.
Scores are derived from the spec sheet using the same model across every bike, so they compare like for like.
Will it fit you?
Worked out in your browser - nothing is sent to usEngine
- Capacity
- 193.0 ccm
- Power
- 19.3 HP (14.2 kW)
- Engine type
- Single, two-stroke
- Power/weight ratio
- 0.2032 HP/kg (dry)
- Bore x stroke
- 64.0 x 60.0 mm
- Cooling system
- Liquid
- Fuel system
- Carburettor
- Starting
- Kick
- Ignition
- Contactless controlled fully electronic ignition with digital ignition adjustment, type Kokusan
- Lubrication system
- Mixture oil lubrication 1:60
- Torque
- Not on record - add it
Transmission
- Gearbox
- 6-speed
- Transmission type
- Manual
- Final drive
- Chain
- Clutch
- Multidisc clutch in oil bath/hydraulically activated
Dimensions & weight
- Wheelbase
- 1471 mm
- Seat height
- 960 mm
- Dry weight
- 95.0 kg
- Fuel capacity
- 9.50 litres
- Ground clearance
- 355 mm
Chassis & suspension
- Frame
- Central tube frame made of chrome molybdenum steel tubing
- Front suspension
- WPSuspension Up Side Down 4860 MXMA PA
- Rear suspension
- WPSuspension PDS 5018 DCC
- Front wheel travel
- 300 mm
- Rear wheel travel
- 335 mm
- Rake (fork angle)
- 26.5°
Brakes & wheels
- Front brakes
- Single disc. Brake calipers on floating bearings
- Front brakes diameter
- 260 mm
- Rear brakes
- Single disc. Brake calipers on floating bearings
- Rear brakes diameter
- 220 mm
- Front tyre
- 90/90-21
- Rear tyre
- 120/90-18
Other
- Color options
- Orange/white/black
Compiled from manufacturer documentation and user contributions, corrected on an ongoing basis. Spotted something wrong? Tell us.
What changed, year to year
Differences highlighted| Specification | 2012 | 2013 | 2014 |
|---|---|---|---|
| Capacity | 193 cc | 193 cc | 193 cc |
| Dry weight | 95 kg | 95 kg | 100 kg |
| Seat height | 960 mm | 960 mm | 960 mm |
| Fuel capacity | 9.5 L | 9.5 L | 10 L |
Illustrative - generated automatically by diffing the year records already on file, not a manufacturer-published changelog.
Rider Reviews
Common questions
What is the engine size of the KTM 200 XC-W?
The 2013 KTM 200 XC-W has a Capacity of 193.0 ccm (11.78 cubic inches).
What engine power does the KTM 200 XC-W have?
The 2013 KTM 200 XC-W has a Power of 19.3 HP (14.2 kW).
How many gears does the KTM 200 XC-W have?
The 2013 KTM 200 XC-W has a Gearbox of 6-speed.
How much does the KTM 200 XC-W weigh?
The 2013 KTM 200 XC-W has a Dry weight of 95.0 kg (209.4 pounds).
