Motocross Bikes
2017KTM 250 XC
34 fields on record
The 2017 KTM 250 XC is a two-stroke cross-country racer for closed-course off-road competition. Its liquid-cooled 249cc single drives through a six-speed gearbox and chain. A 103.9 kg dry weight and 10-litre tank make it light and agile on rough terrain.
- Capacity
- 249.0 ccm
- Engine
- Single, two-stroke
- Gearbox
- 6-speed
- Dry weight
- 103.9 kg
- Seat height
- 992 mm
- Power
- 24.9 HP (18.3 kW)
How it rides
Editorial estimate from the spec sheet - not lab tested- Best for
- Built for cross-country and enduro-style off-road racing where light weight, agility, and a lively 2-stroke power delivery matter more than outright top speed or comfort.
- Built for
- A raw, high-strung, and playful machine that rewards active, aggressive riding with sharp handling and explosive 2-stroke acceleration out of corners.
- Not ideal for
- This bike is not suited to riders wanting a comfortable daily commuter, a passenger-friendly tourer, or a road-legal high-speed machine.
Scores are derived from the spec sheet using the same model across every bike, so they compare like for like.
Will it fit you?
Worked out in your browser - nothing is sent to usEngine
- Capacity
- 249.0 ccm
- Power
- 24.9 HP (18.3 kW)
- Engine type
- Single, two-stroke
- Power/weight ratio
- 0.2397 HP/kg (dry)
- Bore x stroke
- 66.4 x 72.0 mm
- Compression
- 13.2:1
- Cooling system
- Liquid
- Fuel system
- Injection
- Starting
- Electric & kick
- Ignition
- Contactless controlled fully electronic ignition with digital ignition adjustment, type Kokusan
- Lubrication system
- Forced oil lubrication with 2 Eaton pumps
Transmission
- Gearbox
- 6-speed
- Transmission type
- Manual
- Final drive
- Chain
- Clutch
- Multidisc clutch DDS in oil bath/hydraulically activated
Dimensions & weight
- Wheelbase
- 1495 mm
- Seat height
- 992 mm
- Dry weight
- 103.9 kg
- Fuel capacity
- 10.00 litres
- Ground clearance
- 395 mm
Chassis & suspension
- Frame
- Central tube frame made of chrome molybdenum steel tubing
- Front suspension
- WP Suspension Up Side Down 4860 MXMA CC
- Rear suspension
- WP Suspension 5018 BAVP DCC
- Front wheel travel
- 300 mm
- Rear wheel travel
- 317 mm
- Rake (fork angle)
- 26.5°
Brakes & wheels
- Front brakes
- Single disc. Galfer Wave discs
- Front brakes diameter
- 260 mm
- Rear brakes
- Single disc. Galfer Wave discs
- Rear brakes diameter
- 220 mm
- Front tyre
- 80/100-21
- Rear tyre
- 100/90-19
Other
- Color options
- Orange/black
Compiled from manufacturer documentation and user contributions, corrected on an ongoing basis. Spotted something wrong? Tell us.
What changed, year to year
Differences highlighted| Specification | 2012 | 2016 | 2017 | 2020 | 2023 | 2027 |
|---|---|---|---|---|---|---|
| Capacity | 249 cc | 249 cc | 249 cc | 249 cc | 249 cc | 249 cc |
| Dry weight | 104 kg | 104 kg | 104 kg | 104 kg | 100 kg | 102 kg |
| Seat height | 992 mm | 992 mm | 992 mm | 992 mm | 954 mm | 954 mm |
| Fuel capacity | 7.5 L | 10 L | 10 L | 10 L | 8.5 L | 9 L |
Illustrative - generated automatically by diffing the year records already on file, not a manufacturer-published changelog.
Rider Reviews
Common questions
What is the engine size of the KTM 250 XC?
The 2017 KTM 250 XC has a Capacity of 249.0 ccm (15.19 cubic inches).
What engine power does the KTM 250 XC have?
The 2017 KTM 250 XC has a Power of 24.9 HP (18.3 kW).
How many gears does the KTM 250 XC have?
The 2017 KTM 250 XC has a Gearbox of 6-speed.
How much does the KTM 250 XC weigh?
The 2017 KTM 250 XC has a Dry weight of 103.9 kg (229.1 pounds).
