Motocross Bikes

2012KTM 50 SX

35 fields on record

The 2012 KTM 50 SX is an entry-level minibike designed for young riders learning to ride off-road. Powered by a liquid-cooled two-stroke engine with automatic clutch transmission, it delivers manageable power with responsive handling. Known for its rugged construction and reliability, the 50 SX is best suited for beginner motocross and trail riding.

Capacity: 49.0 ccm
Engine: Single, two-stroke
Gearbox: 1-speed
Dry weight: 41.5 kg
Seat height: 684 mm
Power: 5.4 HP (4.0 kW)

⇄ Compare with another bike ＋ Add to garage All model years

What’s new for the 2012 KTM 50 SX

vs the 2011

Spec	2011	2012
Dry weight	39.8 kg (87.7 pounds)	41.5 kg (91.5 pounds)
Front suspension	Marzocchi 32 mm (1.26 in)	WP Suspension USD 35
Rear suspension	WP mono shock	WP Suspension 3614 BAEM
Front brakes	Single disc	Single disc. Four-pot brake caliper
Rear brakes	Single disc	Single disc. Two-pot brake caliper

Other years 2006 2007 2008 2009 2010 2011 2012 2013 2014 2015 2016 2017 2018 2019 2020 2021 2022 2023 2024 2025 2026 2027

How it rides

Editorial estimate from the spec sheet - not lab tested

Off-road & trail80%

Cornering60%

City riding5%

Daily riding5%

Touring5%

Two-up0%

Track55%

Best for: It exists purely to teach a child the fundamentals of balance, throttle control, and off-road riding in a safe, low-powered package.
Built for: It behaves like a purpose-built miniature dirt bike, docile and forgiving with an automatic single-speed gearbox that removes clutch and shifting complexity so a child can focus on riding.
Not ideal for: It is not suitable for adults, taller teens, road use, touring, or anyone seeking real speed or highway capability.

Scores are derived from the spec sheet using the same model across every bike, so they compare like for like.

Will it fit you?

Worked out in your browser - nothing is sent to us

Your height

Inseam (optional)

Units

At 684mm, a rider of 68.9" with a 31" (estimated) inseam will reach the ground with both feet flat on the 2012 KTM 50 SX, with a cramped knee angle of around 55 degrees and an upright riding position.

Assumes about 30mm of suspension sag once seated. This is an approximation from category-typical geometry, not a measurement of this bike or of you - sit on one before you buy.

More bikes at 750 mm or under — Short Kings →

Find bikes that fit your height →

Full specifications

Engine

Capacity: 49.0 ccm
Power: 5.4 HP (4.0 kW)
Engine type: Single, two-stroke
Power/weight ratio: 0.1301 HP/kg (dry)
Bore x stroke: 39.5 x 40.0 mm
Compression: 12.5:1
Cooling system: Liquid
Fuel system: Carburettor
Starting: Kick
Ignition: Seletra 2p D36
Lubrication system: Mixture oil lubrication 1:60

Transmission

Gearbox: 1-speed
Transmission type: Automatic
Final drive: Chain
Clutch: 3-lining automatic clutch on the main shaft / centrifugal force

Dimensions & weight

Wheelbase: 1032 mm
Seat height: 684 mm
Dry weight: 41.5 kg
Fuel capacity: 2.30 litres
Ground clearance: 252 mm

Chassis & suspension

Frame: Central tube frame of chrome molybdenum steel tubing, powder-coated
Front suspension: WP Suspension USD 35
Rear suspension: WP Suspension 3614 BAEM
Front wheel travel: 205 mm
Rear wheel travel: 185 mm
Rake (fork angle): 24.0°
Trail: 90 mm

Brakes & wheels

Front brakes: Single disc. Four-pot brake caliper
Front brakes diameter: 160 mm
Rear brakes: Single disc. Two-pot brake caliper
Rear brakes diameter: 140 mm
Front tyre: 60/100-12
Rear tyre: 2.75-10

Other

Color options: Orange, black, white

Specs last verified against published sources: October 2026.

Compiled from manufacturer documentation and user contributions, corrected on an ongoing basis. Spotted something wrong? Tell us.

What changed, year to year

Differences highlighted

Specification	2006	2011	2012	2017	2022	2027
Capacity	49 cc	49 cc	49 cc	49 cc	49 cc	50 cc
Dry weight	39 kg	40 kg	42 kg	42 kg	42 kg	44 kg
Seat height	650 mm	684 mm	684 mm	684 mm	665 mm	653 mm
Fuel capacity	1.8 L	2.3 L	2.3 L	2.3 L	2.3 L	2.3 L
