Supermotos
2005KTM 525 SMR
36 fields on record
The 2005 KTM 525 SMR is a lightweight supermoto built for aggressive street and track riders seeking raw performance. Its potent 510cc single-cylinder engine delivers impressive torque for a nimble, flickable chassis, making it ideal for tight cornering and quick direction changes. Known for aggressive styling and lively handling, this machine suits experienced riders who demand thrilling acceleration and sharp responsiveness.
- Capacity
- 510.4 ccm
- Engine
- Single
- Gearbox
- 6-speed
- Dry weight
- 109.5 kg
- Seat height
- 855 mm
- Power
- 56.1 HP (41.3 kW)
What’s new for the 2005 KTM 525 SMR
vs the 2004| Spec | 2004 | 2005 |
|---|---|---|
| Torque | 43.0 Nm (4.4 kgf-m or 31.7 ft.lbs) | 42.5 Nm (4.3 kgf-m or 31.3 ft.lbs) |
| Dry weight | 107.5 kg (237.0 pounds) | 109.5 kg (241.4 pounds) |
| Front suspension | WP-USD 48/26 MA/PA | WP-USD 48 mm (1.89 inches) |
| Rear suspension | WP-PDS-DA shock absorber | WP-PDS shock absorber |
How it rides
Editorial estimate from the spec sheet - not lab tested- Best for
- Built as a supermoto weapon, it excels at tight, twisty tarmac, flick-flack direction changes, and aggressive cornering rather than any form of relaxed riding.
- Built for
- Raw, minimalist, and razor-sharp, it feels like a motocrosser wearing street tyres, with instant steering response and a hard-edged, mechanical personality.
- Not ideal for
- It is a poor choice for anyone wanting comfort, wind protection, luggage capacity, passenger accommodation, or long-distance touring.
Scores are derived from the spec sheet using the same model across every bike, so they compare like for like.
Will it fit you?
Worked out in your browser - nothing is sent to usEngine
- Capacity
- 510.4 ccm
- Power
- 56.1 HP (41.3 kW)
- Torque
- 42.5 Nm (4.3 kgf-m)
- Engine type
- Single
- Power/weight ratio
- 0.5123 HP/kg (dry)
- Bore x stroke
- 95.0 x 72.0 mm
- Compression
- 11.0:1
- Cooling system
- Liquid
- Fuel system
- Carburettor
- Starting
- Kick
- Ignition
- Kokusan digital 4K-3A
- Valves per cylinder
- 4
- Lubrication system
- Pressure lubrication with 2 Eaton pumps
Transmission
- Gearbox
- 6-speed
- Transmission type
- Manual
- Final drive
- Chain
- Clutch
- Wet multi-disc clutch, operated hydraulically
Dimensions & weight
- Wheelbase
- 1481 mm
- Overall width
- 525 mm
- Seat height
- 855 mm
- Dry weight
- 109.5 kg
- Fuel capacity
- 7.00 litres
- Ground clearance
- 310 mm
Chassis & suspension
- Frame
- Chromium molybdenum
- Front suspension
- WP-USD 48 mm (1.89 inches)
- Rear suspension
- WP-PDS shock absorber
- Rear wheel travel
- 335 mm
- Rake (fork angle)
- 26.5°
- Trail
- 90 mm
Brakes & wheels
- Front brakes
- Single disc
- Front brakes diameter
- 320 mm
- Rear brakes
- Single disc
- Rear brakes diameter
- 310 mm
- Front tyre
- 120/70-17
- Rear tyre
- 160/60-17
Compiled from manufacturer documentation and user contributions, corrected on an ongoing basis. Spotted something wrong? Tell us.
What changed, year to year
Differences highlighted| Specification | 2004 | 2005 |
|---|---|---|
| Capacity | 510 cc | 510 cc |
| Dry weight | 108 kg | 110 kg |
| Seat height | 855 mm | 855 mm |
| Fuel capacity | 7 L | 7 L |
Illustrative - generated automatically by diffing the year records already on file, not a manufacturer-published changelog.
Rider Reviews
Common questions
What is the engine size of the KTM 525 SMR?
The 2005 KTM 525 SMR has a Capacity of 510.4 ccm (31.15 cubic inches).
What engine power does the KTM 525 SMR have?
The 2005 KTM 525 SMR has a Power of 56.1 HP (41.3 kW).
How many gears does the KTM 525 SMR have?
The 2005 KTM 525 SMR has a Gearbox of 6-speed.
What is the torque of the KTM 525 SMR?
The 2005 KTM 525 SMR has a Torque of 42.5 Nm (4.3 kgf-m or 31.3 ft.lbs).
How much does the KTM 525 SMR weigh?
The 2005 KTM 525 SMR has a Dry weight of 109.5 kg (241.4 pounds).
