2024KTM 85 SX 19-16
31 fields on record
The 2024 KTM 85 SX 19-16 is a liquid-cooled two-stroke motocross bike designed for young intermediate riders aged 12-16 years old. Known for its lightweight agility and responsive handling, this 84.9cc machine delivers strong power delivery through a six-speed transmission, making it ideal for both training and competitive racing on closed courses.
- Capacity
- 84.9 ccm
- Engine
- Single, two-stroke
- Gearbox
- 6-speed
- Dry weight
- 69.0 kg
- Seat height
- 875 mm
- Power
- Not on record
Know it? Add it →
What’s new for the 2024 KTM 85 SX 19-16
vs the 2023| Spec | 2023 | 2024 |
|---|---|---|
| Dry weight | 68.0 kg (149.9 pounds) | 69.0 kg (152.1 pounds) |
Other years
2005
2007
2008
2009
2010
2011
2012
2013
2014
2015
2016
2017
2018
2019
2020
2021
2022
2023
2024
2025
2026
2027
How it rides
Editorial estimate from the spec sheet - not lab tested- Best for
- Built purely for motocross racing and track training, with a peaky 2-stroke powerband and race-tuned suspension rather than any road or leisure use.
- Built for
- Sharp, lightweight, and eager to change direction, the 85 SX rewards aggressive throttle control and active riding with explosive acceleration typical of a small-bore 2-stroke.
- Not ideal for
- It is not suitable for adult riders, commuting, passengers, or anyone wanting a comfortable, road-legal, long-distance machine.
Scores are derived from the spec sheet using the same model across every bike, so they compare like for like.
Will it fit you?
Worked out in your browser - nothing is sent to usEngine
- Capacity
- 84.9 ccm
- Engine type
- Single, two-stroke
- Compression
- 12.5:1
- Cooling system
- Liquid
- Fuel system
- Carburettor
- Starting
- Kick
- Ignition
- MEDJ digital EMS
- Lubrication system
- Mixture oil lubrication
- Power
- Not on record - add it
Transmission
- Gearbox
- 6-speed
- Transmission type
- Manual
- Final drive
- Chain
- Clutch
- Wet, multi-disc clutch, Formula hydraulics
Dimensions & weight
- Wheelbase
- 1290 mm
- Seat height
- 875 mm
- Dry weight
- 69.0 kg
- Fuel capacity
- 5.20 litres
- Ground clearance
- 362 mm
Chassis & suspension
- Frame
- Central double-cradle-type 25CrMo4 steel
- Front suspension
- XACT 43 WP Upside-Down fork, Ø 43 mm
- Rear suspension
- XACT WP PDS mono shock
- Front wheel travel
- 278 mm
- Rear wheel travel
- 305 mm
- Rake (fork angle)
- 24.0°
Brakes & wheels
- Front brakes
- Single disc. Four-piston calipers.
- Front brakes diameter
- 240 mm
- Rear brakes
- Single disc. Two-piston calipers.
- Rear brakes diameter
- 210 mm
- Front tyre
- 70/100-19
- Rear tyre
- 90/100-16
Other
- Color options
- Orange/white/grey
Specs last verified against published sources: .
Compiled from manufacturer documentation and user contributions, corrected on an ongoing basis. Spotted something wrong? Tell us.
What changed, year to year
Differences highlighted| Specification | 2005 | 2011 | 2017 | 2022 | 2024 | 2027 |
|---|---|---|---|---|---|---|
| Capacity | 85 cc | 85 cc | 85 cc | 85 cc | 85 cc | 85 cc |
| Dry weight | 68 kg | 68 kg | 69 kg | 68 kg | 69 kg | 69 kg |
| Seat height | 900 mm | 875 mm | 890 mm | 890 mm | 875 mm | 871 mm |
| Fuel capacity | 5 L | 5 L | 5 L | 5.2 L | 5.2 L | 5.4 L |
Illustrative - generated automatically by diffing the year records already on file, not a manufacturer-published changelog.
Rider Reviews
Common questions
What is the engine size of the KTM 85 SX 19-16?
The 2024 KTM 85 SX 19-16 has a Capacity of 84.9 ccm (5.18 cubic inches).
How many gears does the KTM 85 SX 19-16 have?
The 2024 KTM 85 SX 19-16 has a Gearbox of 6-speed.
How much does the KTM 85 SX 19-16 weigh?
The 2024 KTM 85 SX 19-16 has a Dry weight of 69.0 kg (152.1 pounds).
