2006Macbor XC510 Racing
27 fields on record
The 2006 Macbor XC 510 Racing is a lightweight 50cc minibike designed for young riders and beginners exploring off-road riding. Its compact frame and low 700mm seat height make it accessible for smaller riders, while the single-cylinder liquid-cooled engine and manual clutch provide a straightforward introduction to motorcycle fundamentals. Best suited for trail riding and learning basic cross-country skills.
- Capacity
- 50.0 ccm
- Engine
- Single
- Gearbox
- 1-speed
- Dry weight
- 48.0 kg
- Seat height
- 700 mm
- Power
- 5.4 HP (4.0 kW)
What’s new for the 2006 Macbor XC510 Racing
vs the 2005| Spec | 2005 | 2006 |
|---|---|---|
| Fuel capacity | 3.90 litres (1.03 US gallons) | 3.30 litres (0.87 US gallons) |
How it rides
Editorial estimate from the spec sheet - not lab tested- Best for
- Built as a small-capacity cross/minibike for practicing dirt riding skills, casual backyard fun, or introductory motocross-style riding.
- Built for
- A playful, nimble little machine designed for tossing around dirt tracks at modest speeds while building confidence and technique.
- Not ideal for
- This bike is not suitable for highway travel, long-distance touring, carrying a passenger, or riders expecting real power and speed.
Scores are derived from the spec sheet using the same model across every bike, so they compare like for like.
Engine
- Capacity
- 50.0 ccm
- Power
- 5.4 HP (4.0 kW)
- Engine type
- Single
- Power/weight ratio
- 0.1125 HP/kg (dry)
- Bore x stroke
- 39.0 x 41.8 mm
- Cooling system
- Liquid
- Fuel system
- Carburettor
- Starting
- Kick
- Ignition
- Electronic
Transmission
- Gearbox
- 1-speed
- Transmission type
- Manual
- Final drive
- Chain
- Clutch
- Multidisk
Dimensions & weight
- Wheelbase
- 1035 mm
- Overall length
- 1430 mm
- Overall width
- 700 mm
- Overall height
- 780 mm
- Seat height
- 700 mm
- Dry weight
- 48.0 kg
- Fuel capacity
- 3.30 litres
Chassis & suspension
- Front suspension
- Hydraulic
- Rear suspension
- Gas monoshock absorber
- Front wheel travel
- 170 mm
- Rear wheel travel
- 200 mm
Brakes & wheels
- Front brakes
- Single disc
- Rear brakes
- Single disc
Compiled from manufacturer documentation and user contributions, corrected on an ongoing basis. Spotted something wrong? Tell us.
What changed, year to year
Differences highlighted| Specification | 2004 | 2005 | 2006 | 2007 | 2008 | 2009 |
|---|---|---|---|---|---|---|
| Capacity | 50 cc | 50 cc | 50 cc | 50 cc | 49 cc | 49 cc |
| Dry weight | 48 kg | 48 kg | 48 kg | — | 48 kg | — |
| Seat height | 700 mm | 700 mm | 700 mm | 700 mm | 700 mm | 700 mm |
| Fuel capacity | 3.9 L | 3.9 L | 3.3 L | 3.3 L | 3.3 L | 3.3 L |
Illustrative - generated automatically by diffing the year records already on file, not a manufacturer-published changelog.
Rider Reviews
Common questions
What is the engine size of the Macbor XC510 Racing?
The 2006 Macbor XC510 Racing has a Capacity of 50.0 ccm (3.05 cubic inches).
What engine power does the Macbor XC510 Racing have?
The 2006 Macbor XC510 Racing has a Power of 5.4 HP (4.0 kW).
How many gears does the Macbor XC510 Racing have?
The 2006 Macbor XC510 Racing has a Gearbox of 1-speed.
How much does the Macbor XC510 Racing weigh?
The 2006 Macbor XC510 Racing has a Dry weight of 48.0 kg (105.8 pounds).
