2009Piaggio Liberty 125
33 fields on record
The 2009 Piaggio Liberty 125 is a large-wheeled city scooter known for easy handling and comfort. Its air-cooled 125cc four-stroke single drives through an automatic belt drive. A 790 mm seat, 113 kg wet weight and 6-litre tank make it a practical daily commuter.
- Capacity
- 125.0 ccm
- Engine
- Single, four-stroke
- Gearbox
- Not on record
Know it? Add it → - Dry weight
- 106.0 kg
- Seat height
- 790 mm
- Power
- 15.0 HP (11.0 kW)
How it rides
Editorial estimate from the spec sheet - not lab tested- Best for
- Built purely for short urban hops, errands, and easy daily commuting rather than performance or distance riding.
- Built for
- A practical, economical little scooter that prioritizes ease of use, fuel efficiency, and nimble city maneuvering over excitement.
- Not ideal for
- Not suitable for highway travel, long-distance touring, carrying a passenger comfortably, or riders seeking any real performance.
Scores are derived from the spec sheet using the same model across every bike, so they compare like for like.
Will it fit you?
Worked out in your browser - nothing is sent to usEngine
- Capacity
- 125.0 ccm
- Power
- 15.0 HP (11.0 kW)
- Engine type
- Single, four-stroke
- Power/weight ratio
- 0.1415 HP/kg (dry)
- Bore x stroke
- 52.0 x 58.6 mm
- Cooling system
- Air
- Fuel system
- Carburettor
- Starting
- Electric
- Valves per cylinder
- 2
- Lubrication system
- Wet sump
Transmission
- Transmission type
- Automatic
- Final drive
- Belt
- Clutch
- Automatic centrifugal, dry
Dimensions & weight
- Wheelbase
- 1340 mm
- Overall length
- 1945 mm
- Overall width
- 690 mm
- Seat height
- 790 mm
- Dry weight
- 106.0 kg
- Wet weight
- 113.0 kg
- Fuel capacity
- 6.00 litres
Chassis & suspension
- Frame
- High strength reinforced tubular steel
- Front suspension
- Telescopic fork with hydraulic damping
- Rear suspension
- Single spring with pre-load hydraulic damper
- Front wheel travel
- 76 mm
- Rear wheel travel
- 74 mm
Brakes & wheels
- Front brakes
- Single disc
- Front brakes diameter
- 220 mm
- Rear brakes
- Single disc
- Rear brakes diameter
- 140 mm
- Front tyre
- 90/90-15
- Rear tyre
- 110/80-14
Other
- Color options
- Excalibur Silver, Black Graphite
Compiled from manufacturer documentation and user contributions, corrected on an ongoing basis. Spotted something wrong? Tell us.
What changed, year to year
Differences highlighted| Specification | 2008 | 2009 | 2012 | 2016 | 2020 | 2024 |
|---|---|---|---|---|---|---|
| Capacity | 125 cc | 125 cc | 125 cc | 125 cc | 125 cc | 124 cc |
| Dry weight | 106 kg | 106 kg | 106 kg | 106 kg | 106 kg | 106 kg |
| Seat height | 790 mm | 790 mm | 790 mm | 790 mm | 790 mm | 790 mm |
| Fuel capacity | 6 L | 6 L | 6 L | 6 L | 6 L | 6 L |
Illustrative - generated automatically by diffing the year records already on file, not a manufacturer-published changelog.
Rider Reviews
Common questions
What is the engine size of the Piaggio Liberty 125?
The 2009 Piaggio Liberty 125 has a Capacity of 125.0 ccm (7.63 cubic inches).
What engine power does the Piaggio Liberty 125 have?
The 2009 Piaggio Liberty 125 has a Power of 15.0 HP (11.0 kW).
How much does the Piaggio Liberty 125 weigh?
The 2009 Piaggio Liberty 125 has a Dry weight of 106.0 kg (233.7 pounds).
