Supermotos
2020SWM SM 500 R
40 fields on record
The SWM SM 500 R is a lightweight, agile supermoto designed for riders seeking nimble urban performance and off-road versatility. Its compact dimensions, manageable 133 kg weight, and 920 mm seat height make it accessible for smaller riders and beginners. Known for its spirited handling and capable dual-purpose character, it excels in mixed riding environments.
- Capacity
- 501.0 ccm
- Engine
- Single, four-stroke
- Gearbox
- 6-speed
- Dry weight
- 133.0 kg
- Seat height
- 920 mm
- Power
- 55.1 HP (40.5 kW)
What’s new for the 2020 SWM SM 500 R
vs the 2019| Spec | 2019 | 2020 |
|---|---|---|
| Dry weight | 147.0 kg (324.1 pounds) | 133.0 kg (293.2 pounds) |
| Seat height | 910 mm (35.8 inches) | 920 mm (36.2 inches) |
| Front brakes | Single disc. Floating disc type with radial caliper | Double disc |
| Rear brakes | Single disc. Floating disc type with hydraulic control and radial caliper | Single disc |
| Wheelbase | 1495 mm (58.9 inches) | 1480 mm (58.3 inches) |
How it rides
Editorial estimate from the spec sheet - not lab tested- Best for
- Built for supermoto-style thrills: flicking through tight corners, hooligan street riding, and the occasional trackday on tight, technical circuits.
- Built for
- A punchy, single-cylinder supermoto with sharp street tires, a rigid sporty stance, and razor-quick handling that rewards an aggressive, playful riding style.
- Not ideal for
- Not a good fit for riders seeking long-distance comfort, passenger touring, or serious off-road capability.
Scores are derived from the spec sheet using the same model across every bike, so they compare like for like.
Will it fit you?
Worked out in your browser - nothing is sent to usRange and running costs
Worked out in your browser - nothing is sent to usBased on the published US (EPA-style) fuel economy estimate and tank size. Real-world figures depend on how and where you ride, and the last litres of a tank are reserve. Prices shown greyed are examples - type your own.
Engine
- Capacity
- 501.0 ccm
- Power
- 55.1 HP (40.5 kW)
- CO2 Emissions
- 131 CO2 g/km
- EPA Est. Fuel Consumption
- 5.58 L/100km (42.2 US mpg)
- EPA CO Emissions
- 3.2 CO g/km
- Engine type
- Single, four-stroke
- Power/weight ratio
- 0.4143 HP/kg (dry)
- Bore x stroke
- 96.8 x 67.8 mm
- Compression
- 12.9:1
- Cooling system
- Liquid
- Fuel system
- Injection
- Starting
- Electric
- Ignition
- Digital
- Aspiration
- Naturally aspirated
- Valves per cylinder
- 4
- Lubrication system
- Dry sump
- Torque
- Not on record - add it
Transmission
- Gearbox
- 6-speed
- Transmission type
- Manual
- Final drive
- Chain
- Clutch
- Wet, multiplate type, hydraulic control
Dimensions & weight
- Wheelbase
- 1480 mm
- Overall length
- 2110 mm
- Overall width
- 820 mm
- Overall height
- 1250 mm
- Seat height
- 920 mm
- Dry weight
- 133.0 kg
- Fuel capacity
- 7.20 litres
- Ground clearance
- 295 mm
Chassis & suspension
- Frame
- Single beam double cradle main frame
- Front suspension
- Kayba Upside-Down fork with damping adjustment
- Rear suspension
- Kayba´Soft Damp´monoshock absorber with adjustment
Brakes & wheels
- Front brakes
- Double disc
- Front brakes diameter
- 320 mm
- Rear brakes
- Single disc
- Rear brakes diameter
- 240 mm
- Front tyre
- 120/70-17
- Rear tyre
- 150/60-17
Other
- Color options
- Black/Grey/Red
- Fuel Tank Material
- Plastic
Compiled from manufacturer documentation and user contributions, corrected on an ongoing basis. Spotted something wrong? Tell us.
What changed, year to year
Differences highlighted| Specification | 2016 | 2017 | 2018 | 2019 | 2020 |
|---|---|---|---|---|---|
| Capacity | 501 cc | 501 cc | 501 cc | 501 cc | 501 cc |
| Dry weight | 147 kg | 147 kg | 147 kg | 147 kg | 133 kg |
| Seat height | 910 mm | 910 mm | 910 mm | 910 mm | 920 mm |
| Fuel capacity | 7.2 L | 7.2 L | 7.2 L | 7.2 L | 7.2 L |
Illustrative - generated automatically by diffing the year records already on file, not a manufacturer-published changelog.
Rider Reviews
Common questions
What is the engine size of the SWM SM 500 R?
The 2020 SWM SM 500 R has a Capacity of 501.0 ccm (30.57 cubic inches).
What engine power does the SWM SM 500 R have?
The 2020 SWM SM 500 R has a Power of 55.1 HP (40.5 kW).
How many gears does the SWM SM 500 R have?
The 2020 SWM SM 500 R has a Gearbox of 6-speed.
How much does the SWM SM 500 R weigh?
The 2020 SWM SM 500 R has a Dry weight of 133.0 kg (293.2 pounds).
Shop this bike
Affiliate linksWe may earn a commission from qualifying eBay or Amazon purchases made through these links. As an Amazon Associate I earn from qualifying purchases.
The 2020 SWM SM 500 R is a powerful and stylish motorcycle that offers both performance and versatility. With its 501cc single-cylinder engine, this bike delivers plenty of power for a thrilling riding experience. The lightweight and agile design make it perfect for both city streets and off-road adventures. Additionally, the modern features and adjustable suspension make it a comfortable and easy ride for all types of riders.
Overall, the 2020 SWM SM 500 R is a great choice for motorcycle enthusiasts who are looking for a reliable and high-performance bike. The combination of power, agility, and modern features make it a top contender in its class. Whether you're cruising through the city or hitting the trails, this motorcycle is sure to provide an exciting and enjoyable ride. If you're in the market for a versatile and capable bike, the SWM SM 500 R is definitely worth considering.
