Motocross Bikes
2006TM Racing MX 530F
31 fields on record
The 2006 TM Racing MX 530 F is a high-performance motocross machine designed for competitive riders seeking raw power and precision handling. Powered by a liquid-cooled 527cc single-cylinder engine with aggressive 15.5:1 compression, this bike delivers explosive acceleration ideal for racing environments. Known for its lightweight construction and responsive DOHC engine management, it excels in technical terrain where rider skill and bike feel are paramount.
- Capacity
- 527.7 ccm
- Engine
- Single, four-stroke
- Gearbox
- 5-speed
- Dry weight
- Not on record
Know it? Add it → - Seat height
- 918 mm
- Power
- 58.0 HP (42.7 kW)
What’s new for the 2006 TM Racing MX 530F
vs the 2005| Spec | 2005 | 2006 |
|---|---|---|
| Front suspension | Kayba/Paioli | not listed |
| Rear suspension | Ohlins | not listed |
How it rides
Editorial estimate from the spec sheet - not lab tested- Best for
- Built purely for motocross racing and serious off-road competition, not as a general-purpose or road-going motorcycle.
- Built for
- A raw, high-performance boutique Italian racer with premium components like Marzocchi forks and Nissin brakes, rewarding aggressive, committed riding over relaxed cruising.
- Not ideal for
- This is not a bike for commuting, touring, carrying a passenger, or riders seeking comfort and low-maintenance road usability.
Scores are derived from the spec sheet using the same model across every bike, so they compare like for like.
Will it fit you?
Worked out in your browser - nothing is sent to usEngine
- Capacity
- 527.7 ccm
- Power
- 58.0 HP (42.7 kW)
- Engine type
- Single, four-stroke
- Bore x stroke
- 98.0 x 70.0 mm
- Compression
- 15.5:1
- Cooling system
- Liquid
- Fuel system
- Carburettor
- Starting
- Kick
- Ignition
- Kokusan CDI Electronic with variable advance
- Valves per cylinder
- 4
- Lubrication system
- Dry sump with double rotor pump
Transmission
- Gearbox
- 5-speed
- Transmission type
- Manual
- Final drive
- Chain
- Clutch
- Multiuple-disk in oil-bath with hydaulic control
Dimensions & weight
- Wheelbase
- 1280 mm
- Overall length
- 2030 mm
- Overall width
- 1250 mm
- Overall height
- 1300 mm
- Seat height
- 918 mm
- Fuel capacity
- 8.00 litres
- Ground clearance
- 305 mm
- Dry weight
- Not on record - add it
Chassis & suspension
- Frame
- Cr-Mo steel Perimetral oval section
Brakes & wheels
- Front brakes
- Single disc
- Front brakes diameter
- 270 mm
- Rear brakes
- Single disc
- Rear brakes diameter
- 245 mm
- Front tyre
- 90/90-X21
- Rear tyre
- 110/90-X19
Other
- Color options
- Blue
Specs last verified against published sources: .
Compiled from manufacturer documentation and user contributions, corrected on an ongoing basis. Spotted something wrong? Tell us.
What changed, year to year
Differences highlighted| Specification | 2005 | 2006 | 2007 | 2009 | 2011 | 2016 |
|---|---|---|---|---|---|---|
| Capacity | 528 cc | 528 cc | 528 cc | 528 cc | 528 cc | 528 cc |
| Seat height | 918 mm | 918 mm | 918 mm | 918 mm | 918 mm | — |
| Fuel capacity | 8 L | 8 L | 8 L | 8.2 L | 8.2 L | 8.2 L |
Illustrative - generated automatically by diffing the year records already on file, not a manufacturer-published changelog.
Rider Reviews
Common questions
What is the engine size of the TM Racing MX 530F?
The 2006 TM Racing MX 530F has a Capacity of 527.7 ccm (32.20 cubic inches).
What engine power does the TM Racing MX 530F have?
The 2006 TM Racing MX 530F has a Power of 58.0 HP (42.7 kW).
How many gears does the TM Racing MX 530F have?
The 2006 TM Racing MX 530F has a Gearbox of 5-speed.
