2018Triumph Tiger 800 XRX Low

★ 5.0
Click to vote

49 fields on record

The 2018 Triumph Tiger 800 XRX Low is an adventure motorcycle engineered for riders seeking accessible, capable off-road touring. Known for its manageable seat height, refined parallel-twin engine, and comprehensive electronic features including traction control and cruise control, it excels as an entry-level adventure bike balancing on-road comfort with genuine terrain capability. The model suits intermediate riders prioritizing ease of handling and practical long-distance touring.

Capacity
800.0 ccm
Engine
In-line three-cylinder, four-stroke
Gearbox
6-speed
Dry weight
200.0 kg
Seat height
760 mm
Power
95.0 HP (69.3 kW) @ 9300 RPM
⇄ Compare with another bike + Add to garage All model years

What’s new for the 2018 Triumph Tiger 800 XRX Low

vs the 2017
Spec20172018
Dry weight 191.0 kg (421.1 pounds) 200.0 kg (440.9 pounds)
Front suspension Showa 43mm upside down forks, WP 43 mm upside down forks, adjustable rebound and compression damping
Rear suspension Showa monoshock with hydraulically adjustable preload WP monoshock with remote oil reservoir, hydraulically adjustable preload, rebound damping adjustment
Front brakes Double disc. Floating discs, Nissin 2-piston sliding calipers, Switchable ABS. Double disc. Floating discs, Brembo 2-piston sliding calipers, Switchable ABS.
Other years 2016 2017 2018 2019 2020

How it rides

Editorial estimate from the spec sheet - not lab tested
Speed 60Agility 72Comfort 78Off-road 68Touring 82Road manners 75
Off-road & trail68%
Cornering72%
City riding68%
Daily riding78%
Touring85%
Two-up72%
Track40%
Best for
Designed as an adventure-touring all-rounder, equally happy commuting, covering long distances, or tackling light gravel and dirt roads.
Built for
A refined, torquey triple-powered adventure bike that balances road comfort, light off-road capability, and everyday usability.
Not ideal for
Not ideal for riders seeking outright sportbike performance or serious hardcore off-road technical terrain.

Scores are derived from the spec sheet using the same model across every bike, so they compare like for like.

Will it fit you?

Worked out in your browser - nothing is sent to us
At 760mm, a rider of 68.9" with a 31" (estimated) inseam will reach the ground with both feet flat on the 2018 Triumph Tiger 800 XRX Low, with a moderate knee angle of around 95 degrees and a slightly forward riding position.

Assumes about 30mm of suspension sag once seated. This is an approximation from category-typical geometry, not a measurement of this bike or of you - sit on one before you buy.

More bikes at 751-820 mm — Middle Ground →

Find bikes that fit your height →

Full specifications

Engine
Capacity
800.0 ccm
Power
95.0 HP (69.3 kW) @ 9300 RPM
Torque
79.0 Nm (8.1 kgf-m) @ 7850 RPM
Engine type
In-line three-cylinder, four-stroke
Power/weight ratio
0.4750 HP/kg (dry)
Bore x stroke
74.0 x 61.9 mm
Compression
11.3:1
Cooling system
Liquid
Fuel system
Injection
Starting
Electric
Valves per cylinder
4
Transmission
Gearbox
6-speed
Transmission type
Manual
Final drive
Chain
Clutch
Wet. multi-plate
Dimensions & weight
Wheelbase
1530 mm
Overall length
2200 mm
Overall width
795 mm
Overall height
1390 mm
Seat height
760 mm
Dry weight
200.0 kg
Wet weight
215.0 kg
Fuel capacity
19.00 litres
Ground clearance
Not on record - add it
Chassis & suspension
Frame
Tubular steel trellis. Twin-­sided, cast aluminium alloy swingarm.
Front suspension
WP 43 mm upside down forks, adjustable rebound and compression damping
Rear suspension
WP monoshock with remote oil reservoir, hydraulically adjustable preload, rebound damping adjustment
Front wheel travel
140 mm
Rear wheel travel
150 mm
Rake (fork angle)
23.8°
Trail
86 mm
Brakes & wheels
Front brakes
Double disc. Floating discs, Brembo 2-piston sliding calipers, Switchable ABS.
Front brakes diameter
308 mm
Rear brakes
Single disc. Nissin single piston sliding caliper, Switchable ABS.
Rear brakes diameter
255 mm
ABS
Yes
Front tyre
90/90-21
Rear tyre
150/70-R17
Maintenance
Tyre pressure (solo)
Front 250 kPa (36 psi), rear 290 kPa (42 psi)
Engine oil
Semi or fully synthetic 10W-40 or 10W-50, API SH or higher, JASO MA
Oil capacity
3.70 litres
Oil change
3.40 litres
Oil change with filter
3.60 litres
Spark plug
NGK CR9EK
Coolant
Triumph HD4X Hybrid OAT, premixed 50/50
Coolant capacity
2.69 litres
Other
Color options
White, black, blue, matte black
Warranty
24
Comments
Windscreen. Traction control. Cruise control.

Specs last verified against published sources: .

Compiled from manufacturer documentation and user contributions, corrected on an ongoing basis. Spotted something wrong? Tell us.

What changed, year to year

Differences highlighted
Specification 20162017201820192020
Capacity 800 cc 800 cc 800 cc 800 cc 800 cc
Dry weight 191 kg 191 kg 200 kg 199 kg 199 kg
Seat height 760 mm 760 mm 760 mm 760 mm 760 mm
Fuel capacity 19 L 19 L 19 L 19 L 19 L

Illustrative - generated automatically by diffing the year records already on file, not a manufacturer-published changelog.

Rider Reviews

5.0
★★★★★
Rider rating
MotorcycleDB

The 2018 Triumph Tiger 800 XRX Low is a fantastic choice for riders looking for a versatile and comfortable adventure bike. With its lower seat height and adjustable suspension, it caters to shorter riders or those who prefer a more confident and stable feel when they plant their feet on the ground. The 800cc inline three-cylinder engine provides plenty of power for highway cruising or off-road adventures, while the agile handling and smooth throttle response make it a joy to ride in any situation. The XRX Low also comes equipped with a range of electronic aids, including riding modes, traction control, and ABS, to provide added confidence and safety on the road. Overall, the Tiger 800 XRX Low is a well-rounded and capable adventure bike that is sure to impress riders of all skill levels.

In conclusion, the 2018 Triumph Tiger 800 XRX Low is a top-notch adventure bike that offers a lower seat height and adjustable suspension for a more comfortable and stable ride. Its powerful 800cc engine, agile handling, and range of electronic aids make it a great choice for riders who want a versatile and capable motorcycle for both on and off-road adventures. Whether you're a shorter rider or simply prefer the confidence of being able to touch the ground with ease, the XRX Low has you covered. With its combination of performance, comfort, and safety features, the Tiger 800 XRX Low is a solid option for anyone looking for a reliable and enjoyable adventure motorcycle.

Own one? Add it to My Garage and write an owner review with an Owner badge.

Common questions

What is the engine size of the Triumph Tiger 800 XRX Low?

The 2018 Triumph Tiger 800 XRX Low has a Capacity of 800.0 ccm (48.82 cubic inches).

What engine power does the Triumph Tiger 800 XRX Low have?

The 2018 Triumph Tiger 800 XRX Low has a Power of 95.0 HP (69.3 kW) @ 9300 RPM.

How many gears does the Triumph Tiger 800 XRX Low have?

The 2018 Triumph Tiger 800 XRX Low has a Gearbox of 6-speed.

What is the torque of the Triumph Tiger 800 XRX Low?

The 2018 Triumph Tiger 800 XRX Low has a Torque of 79.0 Nm (8.1 kgf-m or 58.3 ft.lbs) @ 7850 RPM.

How much does the Triumph Tiger 800 XRX Low weigh?

The 2018 Triumph Tiger 800 XRX Low has a Dry weight of 200.0 kg (440.9 pounds).
