Enduro Bikes
2017Yamaha TT-R125LWE
39 fields on record
The 2017 Yamaha TT-R125LWE is a large-wheel trail bike for young riders and beginners. Its air-cooled 124cc four-stroke single drives through a five-speed gearbox and chain. An 805 mm seat and 89.8 kg wet weight make it easy to learn on.
- Capacity
- 124.0 ccm
- Engine
- Single, four-stroke
- Gearbox
- 5-speed
- Dry weight
- 81.0 kg
- Seat height
- 805 mm
- Power
- Not on record
Know it? Add it →
What’s new for the 2017 Yamaha TT-R125LWE
vs the 2016| Spec | 2016 | 2017 |
|---|---|---|
| Power | 15.0 HP (11.0 kW) | not listed |
How it rides
Editorial estimate from the spec sheet - not lab tested- Best for
- It's designed as a lightweight, easygoing trail and learner bike for casual off-road exploration rather than serious performance riding.
- Built for
- Friendly, forgiving, and low-intimidation, this bike prioritizes confidence-building over excitement or outright capability.
- Not ideal for
- It's not the right choice for taller, heavier, or experienced riders seeking speed, long-distance touring comfort, or aggressive off-road performance.
Scores are derived from the spec sheet using the same model across every bike, so they compare like for like.
Will it fit you?
Worked out in your browser - nothing is sent to usEngine
Transmission
- Gearbox
- 5-speed
- Transmission type
- Manual
- Final drive
- Chain
- Clutch
- Multiplate wet clutch
Dimensions & weight
- Wheelbase
- 1270 mm
- Overall length
- 1885 mm
- Overall width
- 795 mm
- Overall height
- 1085 mm
- Seat height
- 805 mm
- Dry weight
- 81.0 kg
- Wet weight
- 89.8 kg
- Fuel capacity
- 6.10 litres
- Ground clearance
- 295 mm
- Oil capacity
- 1.20 litres
Chassis & suspension
- Front suspension
- Telescopic fork
- Rear suspension
- Single shock
- Front wheel travel
- 180 mm
- Rear wheel travel
- 167 mm
- Rake (fork angle)
- 28.0°
- Trail
- 107 mm
Brakes & wheels
- Front brakes
- Single disc
- Front brakes diameter
- 220 mm
- Rear brakes
- Expanding brake (drum brake)
- Rear brakes diameter
- 110 mm
- Front tyre
- 70/100-19
- Rear tyre
- 90/90-16
Other
- Color options
- Blue
- Comments
- Large wheel version of the bike.
Specs last verified against published sources: .
Compiled from manufacturer documentation and user contributions, corrected on an ongoing basis. Spotted something wrong? Tell us.
What changed, year to year
Differences highlighted| Specification | 2004 | 2012 | 2016 | 2017 | 2019 | 2021 |
|---|---|---|---|---|---|---|
| Capacity | 124 cc | 124 cc | 124 cc | 124 cc | 124 cc | 124 cc |
| Dry weight | 78 kg | 81 kg | 81 kg | 81 kg | 81 kg | 81 kg |
| Seat height | 805 mm | 805 mm | 805 mm | 805 mm | 805 mm | 805 mm |
| Fuel capacity | 6.1 L | 6.1 L | 6.1 L | 6.1 L | 6 L | 6 L |
Illustrative - generated automatically by diffing the year records already on file, not a manufacturer-published changelog.
Rider Reviews
Common questions
What is the engine size of the Yamaha TT-R125LWE?
The 2017 Yamaha TT-R125LWE has a Capacity of 124.0 ccm (7.57 cubic inches).
How many gears does the Yamaha TT-R125LWE have?
The 2017 Yamaha TT-R125LWE has a Gearbox of 5-speed.
How much does the Yamaha TT-R125LWE weigh?
The 2017 Yamaha TT-R125LWE has a Dry weight of 81.0 kg (178.6 pounds).
