Supermotos
2017Yamaha WR125X
42 fields on record
The 2017 Yamaha WR125X is a lightweight dual-sport designed for novice and budget-conscious riders seeking an accessible entry into adventure riding. Its compact 137 kg frame, decent ground clearance, and capable suspension make it ideal for mixed on-road and light off-road use. Known for reliability and fuel efficiency, it excels as a learner-friendly machine for commuting and weekend exploration.
- Capacity
- 124.7 ccm
- Engine
- Single, four-stroke
- Gearbox
- 6-speed
- Dry weight
- 127.0 kg
- Seat height
- 920 mm
- Power
- 15.0 HP (10.9 kW) @ 9000 RPM
How it rides
Editorial estimate from the spec sheet - not lab tested- Best for
- Built for zipping through city streets and playful cornering rather than outright speed or distance.
- Built for
- A nimble, flickable street-fighter styled machine that rewards playful, aggressive riding at low to moderate speeds.
- Not ideal for
- Not suited for highway touring, carrying a passenger long distances, or riders wanting strong outright acceleration.
Scores are derived from the spec sheet using the same model across every bike, so they compare like for like.
Will it fit you?
Worked out in your browser - nothing is sent to usEngine
- Capacity
- 124.7 ccm
- Power
- 15.0 HP (10.9 kW) @ 9000 RPM
- Torque
- 12.2 Nm (1.2 kgf-m) @ 8000 RPM
- Engine type
- Single, four-stroke
- Power/weight ratio
- 0.1181 HP/kg (dry)
- Bore x stroke
- 52.0 x 58.6 mm
- Compression
- 11.2:1
- Cooling system
- Liquid
- Fuel system
- Injection
- Starting
- Electric
- Ignition
- TCI
- Valves per cylinder
- 4
- Lubrication system
- Wet sump
Transmission
- Gearbox
- 6-speed
- Transmission type
- Manual
- Final drive
- Chain
- Clutch
- Wet, multipate
Dimensions & weight
- Wheelbase
- 1430 mm
- Overall length
- 2095 mm
- Overall width
- 835 mm
- Overall height
- 1165 mm
- Seat height
- 920 mm
- Dry weight
- 127.0 kg
- Wet weight
- 137.0 kg
- Fuel capacity
- 8.50 litres
- Ground clearance
- 255 mm
- Oil capacity
- 1.20 litres
Chassis & suspension
- Frame
- Steel double cradle
- Front suspension
- Telescopic forks
- Rear suspension
- Swingarm, link suspension, monoshock
- Front wheel travel
- 210 mm
- Rear wheel travel
- 230 mm
- Rake (fork angle)
- 25.5°
- Trail
- 76 mm
Brakes & wheels
- Front brakes
- Single disc
- Front brakes diameter
- 298 mm
- Rear brakes
- Single disc
- Rear brakes diameter
- 220 mm
- Front tyre
- 110/70-17
- Rear tyre
- 140/70-17
Other
- Color options
- Sports White, Yamaha Black
Compiled from manufacturer documentation and user contributions, corrected on an ongoing basis. Spotted something wrong? Tell us.
What changed, year to year
Differences highlighted| Specification | 2009 | 2011 | 2013 | 2015 | 2017 |
|---|---|---|---|---|---|
| Capacity | 125 cc | 125 cc | 125 cc | 125 cc | 125 cc |
| Dry weight | 127 kg | 127 kg | 127 kg | 127 kg | 127 kg |
| Seat height | 920 mm | 920 mm | 920 mm | 920 mm | 920 mm |
| Fuel capacity | 8.5 L | 8.5 L | 8.5 L | 8.5 L | 8.5 L |
Illustrative - generated automatically by diffing the year records already on file, not a manufacturer-published changelog.
Rider Reviews
Common questions
What is the engine size of the Yamaha WR125X?
The 2017 Yamaha WR125X has a Capacity of 124.7 ccm (7.61 cubic inches).
What engine power does the Yamaha WR125X have?
The 2017 Yamaha WR125X has a Power of 15.0 HP (10.9 kW) @ 9000 RPM.
How many gears does the Yamaha WR125X have?
The 2017 Yamaha WR125X has a Gearbox of 6-speed.
What is the torque of the Yamaha WR125X?
The 2017 Yamaha WR125X has a Torque of 12.2 Nm (1.2 kgf-m or 9.0 ft.lbs) @ 8000 RPM.
How much does the Yamaha WR125X weigh?
The 2017 Yamaha WR125X has a Dry weight of 127.0 kg (280.0 pounds).
Shop this bike
Affiliate linksWe may earn a commission from qualifying eBay or Amazon purchases made through these links. As an Amazon Associate I earn from qualifying purchases.
The 2017 Yamaha WR125X is a powerful and versatile motorcycle that offers exceptional performance and handling. With its lightweight aluminum frame and 125cc liquid-cooled engine, this bike is perfect for both city streets and off-road adventures. The sleek and modern design of the WR125X is sure to turn heads, and its comfortable seating position makes it a joy to ride for long hours. Whether you're a beginner rider or an experienced motorcyclist, the Yamaha WR125X is a great choice for anyone looking for a reliable and fun bike to ride.
In addition to its impressive performance, the 2017 Yamaha WR125X also features advanced technology and safety features that give riders peace of mind. The digital dashboard provides clear and easy-to-read information, while the front and rear disc brakes offer exceptional stopping power. With its nimble and responsive handling, the WR125X offers a smooth and enjoyable riding experience. Overall, the 2017 Yamaha WR125X is a top-notch motorcycle that delivers on both style and performance, making it a great option for riders of all skill levels.
