2016Yamaha WR250F

Rate this bike

41 fields on record

The 2016 Yamaha WR250F is a lightweight, nimble off-road machine designed for recreational riders seeking an accessible entry point into trail and enduro riding. Known for its responsive handling, electric starter convenience, and proven reliability, this liquid-cooled four-stroke excels in mixed terrain with its playful character and manageable power delivery.

Capacity: 250.0 ccm
Engine: Single, four-stroke
Gearbox: 6-speed
Dry weight: 106.1 kg
Seat height: 965 mm
Power: 38.0 HP (27.9 kW)

⇄ Compare with another bike ＋ Add to garage All model years

What’s new for the 2016 Yamaha WR250F

vs the 2015

Spec	2015	2016
Fuel capacity	7.60 litres (2.01 US gallons)	7.50 litres (1.98 US gallons)
Front suspension	KYB Speed-Sensitive System	Telescopic forks
Rear suspension	KYB Fully adjustable single shock	Swingarm, (link suspension)
Front brakes	Single disc. Hydraulic.	Single disc
Rear brakes	Single disc. Hydraulic.	Single disc

Other years 2002 2003 2004 2005 2006 2007 2008 2009 2010 2011 2012 2013 2014 2015 2016 2017 2018 2019 2020 2021 2022 2023 2024 2025 2026 2027

How it rides

Editorial estimate from the spec sheet - not lab tested

Off-road & trail96%

Cornering55%

City riding15%

Daily riding20%

Touring25%

Two-up5%

Track20%

Best for: Built for competitive enduro and technical trail riding rather than commuting or highway travel.
Built for: A sharp, responsive dirt-focused machine with a peaky high-strung engine character typical of a fuel-injected 250cc off-road four-stroke.
Not ideal for: Not a good fit for riders wanting a comfortable street commuter, a passenger-friendly bike, or long-distance paved touring.

Scores are derived from the spec sheet using the same model across every bike, so they compare like for like.

Will it fit you?

Worked out in your browser - nothing is sent to us

Your height

Inseam (optional)

Units

At 965mm, a rider of 175cm with a 79cm (estimated) inseam will not reach the ground comfortably on the 2016 Yamaha WR250F, with a cramped knee angle of around 85 degrees and an upright riding position.

Assumes about 30mm of suspension sag once seated. This is an approximation from category-typical geometry, not a measurement of this bike or of you - sit on one before you buy.

More bikes at over 900 mm — Sky High →

Find bikes that fit your height →

Full specifications

Engine

Capacity: 250.0 ccm
Power: 38.0 HP (27.9 kW)
Engine type: Single, four-stroke
Power/weight ratio: 0.3582 HP/kg (dry)
Bore x stroke: 77.0 x 53.6 mm
Compression: 13.5:1
Cooling system: Liquid
Fuel system: Injection
Starting: Electric
Ignition: CDI
Valves per cylinder: 4
Lubrication system: Wet sump
Torque: Not on record - add it

Transmission

Gearbox: 6-speed
Transmission type: Manual
Final drive: Chain
Clutch: Multiplate wet clutch

Dimensions & weight

Wheelbase: 1466 mm
Overall length: 2165 mm
Overall width: 826 mm
Overall height: 1280 mm
Seat height: 965 mm
Dry weight: 106.1 kg
Wet weight: 118.0 kg
Fuel capacity: 7.50 litres
Ground clearance: 325 mm
Oil capacity: 1.10 litres

Chassis & suspension

Frame: Aluminium, semi double cradle
Front suspension: Telescopic forks
Rear suspension: Swingarm, (link suspension)
Front wheel travel: 310 mm
Rear wheel travel: 315 mm
Rake (fork angle): 27.0°
Trail: 115 mm

Brakes & wheels

Front brakes: Single disc
Front brakes diameter: 250 mm
Rear brakes: Single disc
Rear brakes diameter: 245 mm
Front tyre: 90/90-21
Rear tyre: 130/90-18

Other

Color options: Team Yamaha Blue/White

Compiled from manufacturer documentation and user contributions, corrected on an ongoing basis. Spotted something wrong? Tell us.

What changed, year to year

Differences highlighted

Specification	2002	2008	2015	2016	2021	2027
Capacity	249 cc	250 cc	250 cc	250 cc	250 cc	250 cc
Dry weight	106 kg	106 kg	106 kg	106 kg	106 kg	—
Seat height	998 mm	980 mm	965 mm	965 mm	955 mm	955 mm
Fuel capacity	9.8 L	7.9 L	7.6 L	7.5 L	8.3 L	7.6 L
