1996Yamaha XTZ 660 Tenere
28 fields on record
The 1996 Yamaha XTZ 660 Tenere is a versatile single-cylinder enduro designed for adventure riders seeking balanced on-road and off-road capability. Its torquey 659cc engine, manageable weight, and accessible seat height make it ideal for both experienced and intermediate riders tackling varied terrain. Known for reliability and practical performance, it remains a respected choice for touring and light trail exploration.
- Capacity
- 659.0 ccm
- Engine
- Single, four-stroke
- Gearbox
- 5-speed
- Dry weight
- 171.0 kg
- Seat height
- 865 mm
- Power
- 48.0 HP (35.3 kW)
How it rides
Editorial estimate from the spec sheet - not lab tested- Best for
- Built primarily for long-distance off-road adventure and dual-sport travel rather than outright speed or cornering performance.
- Built for
- A rugged, torquey single-cylinder workhorse that rewards patient, momentum-based riding over aggressive throttle inputs.
- Not ideal for
- Not a good fit for riders seeking sharp sport-bike acceleration, low seat height, or nimble city commuting.
Scores are derived from the spec sheet using the same model across every bike, so they compare like for like.
Will it fit you?
Worked out in your browser - nothing is sent to usEngine
- Capacity
- 659.0 ccm
- Power
- 48.0 HP (35.3 kW)
- Torque
- 57.0 Nm (5.8 kgf-m) @ 5250 RPM
- Engine type
- Single, four-stroke
- Power/weight ratio
- 0.2807 HP/kg (dry)
- Bore x stroke
- 100.0 x 84.0 mm
- Compression
- 9.2:1
- Cooling system
- Liquid
- Starting
- Electric
- Valves per cylinder
- 5
Transmission
- Gearbox
- 5-speed
- Transmission type
- Manual
- Final drive
- Chain
Performance
- Top speed
- 159.0 km/h (98.8 mph)
Dimensions & weight
- Wheelbase
- 1495 mm
- Seat height
- 865 mm
- Dry weight
- 171.0 kg
- Wet weight
- 201.5 kg
- Fuel capacity
- 20.00 litres
- Ground clearance
- Not on record - add it
Chassis & suspension
- Front wheel travel
- 220 mm
- Rear wheel travel
- 220 mm
Brakes & wheels
- Front brakes
- Single disc
- Front brakes diameter
- 282 mm
- Rear brakes
- Single disc
- Rear brakes diameter
- 220 mm
- Front tyre
- 90/90-S21
- Rear tyre
- 120/90-S17
Compiled from manufacturer documentation and user contributions, corrected on an ongoing basis. Spotted something wrong? Tell us.
What changed, year to year
Differences highlighted| Specification | 1991 | 1993 | 1995 | 1996 | 1997 | 1999 |
|---|---|---|---|---|---|---|
| Capacity | 659 cc | 659 cc | 659 cc | 659 cc | 659 cc | 660 cc |
| Dry weight | 188 kg | 188 kg | 171 kg | 171 kg | 171 kg | 171 kg |
| Seat height | 860 mm | 860 mm | 865 mm | 865 mm | 865 mm | 865 mm |
| Fuel capacity | 20 L | 20 L | 20 L | 20 L | 20 L | 20 L |
Illustrative - generated automatically by diffing the year records already on file, not a manufacturer-published changelog.
Rider Reviews
Common questions
What is the engine size of the Yamaha XTZ 660 Tenere?
The 1996 Yamaha XTZ 660 Tenere has a Capacity of 659.0 ccm (40.21 cubic inches).
What engine power does the Yamaha XTZ 660 Tenere have?
The 1996 Yamaha XTZ 660 Tenere has a Power of 48.0 HP (35.3 kW).
How many gears does the Yamaha XTZ 660 Tenere have?
The 1996 Yamaha XTZ 660 Tenere has a Gearbox of 5-speed.
What is the torque of the Yamaha XTZ 660 Tenere?
The 1996 Yamaha XTZ 660 Tenere has a Torque of 57.0 Nm (5.8 kgf-m or 42.0 ft.lbs) @ 5250 RPM.
How much does the Yamaha XTZ 660 Tenere weigh?
The 1996 Yamaha XTZ 660 Tenere has a Dry weight of 171.0 kg (377.0 pounds).
