Cruisers

2002Yamaha XVS 250 DragStar

33 fields on record

The 2002 Yamaha XVS 250 Drag Star is an entry-level cruiser designed for new and smaller-framed riders seeking an accessible, manageable motorcycle with classic styling. Its lightweight air-cooled V-twin engine delivers modest but adequate power for city riding and casual cruising, while the low 670mm seat height and 147kg dry weight make it approachable for beginners. Known for reliability and affordability, this model represents Yamaha's accessible take on traditional cruiser aesthetics.

Capacity: 249.0 ccm
Engine: V-Twin
Gearbox: 5-speed
Dry weight: 147.0 kg
Seat height: 670 mm
Power: 21.1 HP (15.5 kW) @ 8000 RPM

⇄ Compare with another bike ＋ Add to garage All model years

What’s new for the 2002 Yamaha XVS 250 DragStar

vs the 2001

Spec	2001	2002
Torque	21.0 Nm (2.1 kgf-m or 15.5 ft.lbs)	20.7 Nm (2.1 kgf-m or 15.3 ft.lbs)
Top speed	125.0 km/h (77.7 mph)	not listed

Other years 2001 2002 2003 2004 2005 2006

How it rides

Editorial estimate from the spec sheet - not lab tested

Off-road & trail10%

Cornering40%

City riding70%

Daily riding60%

Touring30%

Two-up25%

Track5%

Best for: Designed as an entry-level cruiser for relaxed street riding and building confidence rather than outright performance.
Built for: A friendly, laid-back small-displacement cruiser that prioritizes style and approachability over speed.
Not ideal for: Not a good fit for riders seeking highway touring comfort, high speed performance, or off-road capability.

Scores are derived from the spec sheet using the same model across every bike, so they compare like for like.

Will it fit you?

Worked out in your browser - nothing is sent to us

Your height

Inseam (optional)

Units

At 670mm, a rider of 68.9" with a 31" (estimated) inseam will reach the ground with both feet flat on the 2002 Yamaha XVS 250 DragStar, with a cramped knee angle of around 70 degrees and an upright riding position.

Assumes about 30mm of suspension sag once seated. This is an approximation from category-typical geometry, not a measurement of this bike or of you - sit on one before you buy.

More bikes at 750 mm or under — Short Kings →

Find bikes that fit your height →

Full specifications

Engine

Capacity: 249.0 ccm
Power: 21.1 HP (15.5 kW) @ 8000 RPM
Torque: 20.7 Nm (2.1 kgf-m)
Engine type: V-Twin
Power/weight ratio: 0.1435 HP/kg (dry)
Bore x stroke: 49.0 x 66.0 mm
Compression: 10.0:1
Cooling system: Air
Fuel system: Carburettor
Starting: Electric
Valves per cylinder: 2

Transmission

Gearbox: 5-speed
Transmission type: Manual
Final drive: Chain

Dimensions & weight

Wheelbase: 1530 mm
Overall length: 2320 mm
Overall width: 910 mm
Overall height: 1075 mm
Seat height: 670 mm
Dry weight: 147.0 kg
Fuel capacity: 11.00 litres
Ground clearance: 150 mm

Chassis & suspension

Front suspension: Hydraulic telescopic fork
Rear suspension: Swingarm with twin shocks
Front wheel travel: 140 mm
Rear wheel travel: 100 mm

Brakes & wheels

Front brakes: Single disc
Front brakes diameter: 282 mm
Rear brakes: Expanding brake
Rear brakes diameter: 130 mm
Front tyre: 80/100-18 47P
Rear tyre: 130/90-15 M/C 66P

Compiled from manufacturer documentation and user contributions, corrected on an ongoing basis. Spotted something wrong? Tell us.

What changed, year to year

Differences highlighted

Specification	2001	2002	2004	2005	2006
Capacity	249 cc	249 cc	249 cc	249 cc	248 cc
Dry weight	147 kg	147 kg	147 kg	147 kg	147 kg
Seat height	670 mm	670 mm	670 mm	670 mm	670 mm
Fuel capacity	11 L	11 L	11 L	11 L	11 L
