BMW R 1200 GS - 2004 Specifications and Reviews
The 2004 BMW R 1200 GS is a versatile adventure tourer that appeals to both experienced and novice riders seeking capability on and off-road. Its air and oil-cooled boxer engine delivers smooth, reliable power with excellent torque characteristics, making it ideal for long-distance touring and light trail exploration. Known for durability and balanced handling, this bike defines the modern adventure motorcycle category.
General information | |
| Category | Allround |
| Year | 2004 |
| Model | BMW R 1200 GS |
| | |
Engine and Transmission Specifications | |
| Transmission typefinal drive | Shaft drive (cardan) |
| Gearbox | 5-speed |
| Cooling system | Oil & air |
| Fuel control | SOHC |
| Valves per cylinder | 4 |
| Fuel system | Injection |
| Bore x stroke | 101.0 x 73.0 mm (4.0 x 2.9 inches) |
| Compression | 10.0:1 |
| Torque | 115.00 |
| Power | 98.00 |
| Stroke | 4 |
| Engine type | Two cylinder boxer |
| Capacity: | 1170.00 ccm (71.39 cubic inches) |
Physical measures and capacities | |
| Wheelbase | 1,641 mm (64.6 inches) |
| Overall width | 915 mm (36.0 inches) |
| Overall length | 2,210 mm (87.0 inches) |
| Overall height | 1,430 mm (56.3 inches) |
| Alternate seat height | 860 mm (33.9 inches) If adjustable, highest setting. |
| Seat height | 840 mm (33.1 inches) If adjustable, lowest setting. |
| Dry weight | 199.0 kg (438.7 pounds) |
| | |
BMW R 1200 GS dimensions and frame | |
| Rear brakes diameter | 265 mm (10.4 inches) |
| Rear brakes | Single disc |
| Front brakes diameter | 305 mm (12.0 inches) |
| Front brakes | Double disc |
| Rear tyre dimensions | 150/70-ZR17 |
| Front tyre dimensions | 110/80-ZR19 |
| Rear suspension travel | 200 mm (7.9 inches) |
| Rear suspension | Die-cast aluminium single-sided swinging arm with BMW Motorrad Paralever; WAD strut (travel-related damping), spring pre-load hydraulically adjustable to continuously variable levels by means of handwheel, rebound damping adjustable |
| Front suspension travel | 190 mm (7.5 inches) |
| Front suspension | BMW Motorrad Telelever;stanchion diameter 41 mm, central spring strut, spring pre-load 9-times mechanically adjustable |
| Frame type | Three-section composite frame consisting of front and rear section, load bearing engine. |
Speed and acceleration | |
| Power/weight ratio | 0.4925 HP/kg |
| Top speed | 200.0 km/h (124.3 mph) |
Other specs | |
| Fuel consumption pr. 10 km (6.2 miles) | 4.50 litres (1.19 gallons) |
| Reserve fuel capacity | 4.00 litres (1.06 gallons) |
| Fuel capacity | 20.00 litres (5.28 gallons) |
