KTM 1290 Super Adventure - 2015 Specifications and Reviews

2015
Not Rated stars Average rating: Not Rated from 0 votes
.

General information

Category:Allround
Year:2015
Model:KTM 1290 Super Adventure

Engine and Transmission Specifications

Driveline:5/8 x 5/16 X Ring. Primary drive: 40:76.
Clutch:PASC anti-hopping clutch/ hydraulically operated
Transmission type,final drive:Chain
Gearbox:6-speed
Cooling system:Liquid
Lubrication system:Forced oil lubrication with 3 rotor pumps
Ignition:Contactless, controlled, fully electronic ignition system with digital ignition timing adjustment
Fuel system:Injection
Bore x Stroke:108.0 x 75.0 mm (4.3 x 3.0 inches)
Power:160.00 Horsepower">HP (116.8 Kilowatt">kW))
Engine details:75° V arrangement
Engine type:V2, four-stroke


Brakes, suspension, Frame and wheels

Rear brakes diameter:267 mm (10.5 inches)
Rear brakes:Single disc. ABS. Two-piston calipers.
Front brakes diameter:320 mm (12.6 inches)
Front brakes:Double disc. ABS. Four-piston calipers. Radially mounted.
Rear wheel travel:200 mm (7.9 inches)
Rear Suspension:WP Semi-active Suspension PDS Monoshock
Front wheel travel:200 mm (7.9 inches)
Front Suspension:WP Semi-active Suspension USD 48 mm
Rake (fork angle):26.0°
Frame type:Tubular space frame made from chrome molybdenum steel, powder-coated


Physical measures and capacities

Fuel capacity:30.00 litres (7.93 gallons)
Wheelbase:1,560 mm (61.4 inches)
Ground clearance:220 mm (8.7 inches)
Alternate seat height:875 mm (34.4 inches) If adjustable, highest setting.
Seat height:860 mm (33.9 inches) If adjustable, lowest setting.
Power/weight ratio:0.6987 HP/kg
Dry weight:229.0 kg (504.9 pounds)

Other specs

Comments:Small windscreen. Ride-by-wire system.
Starter:Electric
Color options:White
