2022Arch 1S

37 fields on record

The 2022 Arch 1S is a hand-built American performance cruiser from Arch Motorcycle in Los Angeles. Its 2,032cc V-twin makes 120 hp and 163 Nm through a six-speed gearbox, with ABS standard. An 800 mm seat, 244.9 kg dry weight and 17-litre tank complete this exclusive machine.

Capacity: 2032.0 ccm
Engine: V-Twin, four-stroke
Gearbox: 6-speed
Dry weight: 244.9 kg
Seat height: 800 mm
Power: 120.0 HP (87.6 kW)

⇄ Compare with another bike ＋ Add to garage All model years

Other years 2018 2019 2020 2021 2022 2023

How it rides

Editorial estimate from the spec sheet - not lab tested

Off-road & trail10%

Cornering60%

City riding45%

Daily riding55%

Touring65%

Two-up55%

Track45%

Best for: It's built as a premium power-cruiser that blends muscular straight-line performance with boutique, hand-built craftsmanship rather than outright track ability.
Built for: Expect a bold, exclusive machine with a thumping V-twin character, premium Ohlins suspension, and top-shelf componentry that rewards a relaxed but assertive riding style.
Not ideal for: This is not the right choice for new riders, off-road adventurers, or anyone seeking a lightweight, nimble commuter.

Scores are derived from the spec sheet using the same model across every bike, so they compare like for like.

Will it fit you?

Worked out in your browser - nothing is sent to us

Your height

Inseam (optional)

Units

At 800mm, a rider of 68.9" with a 31" (estimated) inseam will reach the ground with both feet flat on the 2022 Arch 1S, with a moderate knee angle of around 90 degrees and an upright riding position.

Assumes about 30mm of suspension sag once seated. This is an approximation from category-typical geometry, not a measurement of this bike or of you - sit on one before you buy.

More bikes at 751-820 mm — Middle Ground →

Find bikes that fit your height →

Range and running costs

Worked out in your browser - nothing is sent to us

Units

Currency

Fuel per litre

Riding a year

Based on the published US (EPA-style) fuel economy estimate and tank size. Real-world figures depend on how and where you ride, and the last litres of a tank are reserve. Prices shown greyed are examples - type your own.

Full specifications

Engine

Capacity: 2032.0 ccm
Power: 120.0 HP (87.6 kW)
CO2 Emissions: 188 CO2 g/km
EPA Est. Fuel Consumption: 8.01 L/100km (29.4 US mpg)
EPA CO Emissions: 5.0 CO g/km
Torque: 163.0 Nm (16.6 kgf-m)
Engine type: V-Twin, four-stroke
Power/weight ratio: 0.4900 HP/kg (dry)
Bore x stroke: 104.8 x 117.5 mm
Compression: 10.8:1
Cooling system: Liquid
Fuel system: Injection
Starting: Electric
Aspiration: Naturally aspirated
Valves per cylinder: 2

Transmission

Gearbox: 6-speed
Transmission type: Manual
Final drive: Chain
Clutch: Dry

Dimensions & weight

Wheelbase: 1661 mm
Seat height: 800 mm
Dry weight: 244.9 kg
Fuel capacity: 17.00 litres

Chassis & suspension

Frame: Billet and tubular steel frame with CNC machined aluminum backbone and sub-chassis
Front suspension: Ohlins / Arch proprietary FGRT series fork, fully adjustable
Rear suspension: Ohlins / Arch proprietary rear shock with reservoir, hydraulic pre-load adjustment, fully adjustable
Rake (fork angle): 26.0°
Trail: 112 mm

Brakes & wheels

Front brakes: Double disc. ABS. 6 piston monobloc radial mount calipers
Front brakes diameter: 320 mm
Rear brakes: Single disc. ABS. Four-piston monobloc radial mount caliper
ABS: Yes
Front tyre: 3.50-17
Rear tyre: 8.50-17

Other

Color options: White/grey/red/black
Comments: ARCH Motorcycles are made i Los Angeles.

Compiled from manufacturer documentation and user contributions, corrected on an ongoing basis. Spotted something wrong? Tell us.

What changed, year to year

Differences highlighted

Specification	2018	2019	2021	2022	2023
Capacity	2032 cc	2032 cc	2032 cc	2032 cc	2032 cc
Dry weight	245 kg	245 kg	245 kg	245 kg	255 kg
Seat height	800 mm	800 mm	800 mm	800 mm	800 mm
Fuel capacity	17 L	17 L	17 L	17 L	17 L
