Sportbikes
2016Bimota Tesi 3D
39 fields on record
The 2016 Bimota Tesi 3D is an exotic Italian sports bike with Bimota's unusual hub-centre steering. Its oil- and air-cooled 1078cc Ducati V-twin makes 98 hp at 7,500 rpm and 98 Nm through a six-speed gearbox and chain. An 800 mm seat, 170 kg dry weight and 18-litre tank make it light and rare.
- Capacity
- 1078.0 ccm
- Engine
- V-Twin, four-stroke
- Gearbox
- 6-speed
- Dry weight
- 170.0 kg
- Seat height
- 800 mm
- Power
- 98.0 HP (71.5 kW) @ 7500 RPM
How it rides
Editorial estimate from the spec sheet - not lab tested- Best for
- Built as a low-volume Italian exotic focused on razor-sharp cornering precision and engineering novelty rather than outright top-speed bragging rights.
- Built for
- A rare, boutique hyper-naked whose hub-center steering front end delivers uniquely stable, precise cornering feedback unlike any telescopic-fork competitor.
- Not ideal for
- Not suited to riders wanting long-distance comfort, pillion practicality, or a low-maintenance, easy-to-live-with daily commuter.
Scores are derived from the spec sheet using the same model across every bike, so they compare like for like.
Will it fit you?
Worked out in your browser - nothing is sent to usEngine
- Capacity
- 1078.0 ccm
- Power
- 98.0 HP (71.5 kW) @ 7500 RPM
- Torque
- 98.0 Nm (10.0 kgf-m) @ 6750 RPM
- Engine type
- V-Twin, four-stroke
- Power/weight ratio
- 0.5765 HP/kg (dry)
- Bore x stroke
- 98.0 x 71.5 mm
- Compression
- 10.5:1
- Cooling system
- Oil & air
- Fuel system
- Injection
- Starting
- Electric
- Valves per cylinder
- 2
- Lubrication system
- Wet Sump
Transmission
- Gearbox
- 6-speed
- Transmission type
- Manual
- Final drive
- Chain
- Clutch
- Dry Clutch, multi-disc
Dimensions & weight
- Wheelbase
- 1390 mm
- Overall length
- 2100 mm
- Overall width
- 700 mm
- Overall height
- 1120 mm
- Seat height
- 800 mm
- Dry weight
- 170.0 kg
- Fuel capacity
- 18.00 litres
- Reserve fuel capacity
- 5.00 litres
Chassis & suspension
- Frame
- Aluminium plates, front and rear swingarm NiCrmo4 steel.
- Front suspension
- Öhlins monoshock adjustable in preload, in compression and rebound damping on single speed.
- Rear suspension
- Öhlins monoshock adjustable in preload, compression and rebound damping on single speed.
- Front wheel travel
- 115 mm
- Rear wheel travel
- 120 mm
- Rake (fork angle)
- 23.0°
Brakes & wheels
- Front brakes
- Double disc. 4-piston
- Front brakes diameter
- 320 mm
- Rear brakes
- Single disc. 2-piston
- Rear brakes diameter
- 220 mm
- Front tyre
- 120/70-17
- Rear tyre
- 180/55-17
Other
- Color options
- White/red/grey
- Comments
- Italian brand.
Compiled from manufacturer documentation and user contributions, corrected on an ongoing basis. Spotted something wrong? Tell us.
What changed, year to year
Differences highlighted| Specification | 2007 | 2010 | 2012 | 2015 | 2016 | 2017 |
|---|---|---|---|---|---|---|
| Capacity | 1079 cc | 1079 cc | 1079 cc | 1078 cc | 1078 cc | 1078 cc |
| Dry weight | 168 kg | 168 kg | 168 kg | 170 kg | 170 kg | 167 kg |
| Seat height | 800 mm | 810 mm | 810 mm | 800 mm | 800 mm | 800 mm |
| Fuel capacity | 11 L | 16 L | 16 L | 18 L | 18 L | 16 L |
Illustrative - generated automatically by diffing the year records already on file, not a manufacturer-published changelog.
Rider Reviews
Common questions
What is the engine size of the Bimota Tesi 3D?
The 2016 Bimota Tesi 3D has a Capacity of 1078.0 ccm (65.78 cubic inches).
What engine power does the Bimota Tesi 3D have?
The 2016 Bimota Tesi 3D has a Power of 98.0 HP (71.5 kW) @ 7500 RPM.
How many gears does the Bimota Tesi 3D have?
The 2016 Bimota Tesi 3D has a Gearbox of 6-speed.
What is the torque of the Bimota Tesi 3D?
The 2016 Bimota Tesi 3D has a Torque of 98.0 Nm (10.0 kgf-m or 72.3 ft.lbs) @ 6750 RPM.
How much does the Bimota Tesi 3D weigh?
The 2016 Bimota Tesi 3D has a Dry weight of 170.0 kg (374.8 pounds).
