Sport Tourers
2020BMW S 1000 XR
50 fields on record
The 2020 BMW S 1000 XR is a sport-tourer designed for riders seeking versatility and performance. It excels at long-distance touring while delivering sharp handling and responsive acceleration, making it ideal for adventure-focused enthusiasts who demand both comfort and sportiness on varied terrain and highways.
- Capacity
- 999.0 ccm
- Engine
- In-line four, four-stroke
- Gearbox
- 6-speed
- Dry weight
- 205.0 kg
- Seat height
- 840 mm
- Power
- 162.3 HP (121.0 kW) @ 11000 RPM
What’s new for the 2020 BMW S 1000 XR
vs the 2019| Spec | 2019 | 2020 |
|---|---|---|
| Power | 165.0 HP (120.4 kW) @ 11000 RPM | 162.3 HP (121.0 kW) @ 11000 RPM |
| Dry weight | 178.0 kg (392.4 pounds) | 205.0 kg (451.9 pounds) |
| Compression | 12.0:1 | 12.5:1 |
How it rides
Editorial estimate from the spec sheet - not lab tested- Best for
- Designed as a sport-touring machine that blends supersport-derived engine performance with an upright, adventure-style riding position for fast road riding and long-distance travel.
- Built for
- A thrilling, engaged riding companion for someone who wants supersport-level acceleration and precision cornering without sacrificing all-day comfort and versatility.
- Not ideal for
- Not a good fit for off-road adventure riders, absolute beginners, or those seeking a lightweight, low-seat commuter bike.
Scores are derived from the spec sheet using the same model across every bike, so they compare like for like.
Will it fit you?
Worked out in your browser - nothing is sent to usRange and running costs
Worked out in your browser - nothing is sent to usBased on the maker's published fuel consumption and tank size. Real-world figures depend on how and where you ride, and the last litres of a tank are reserve. Prices shown greyed are examples - type your own.
Engine
- Capacity
- 999.0 ccm
- Power
- 162.3 HP (121.0 kW) @ 11000 RPM
- CO2 Emissions
- 159 CO2 g/km
- EPA Certificate No.
- LBMXC01.0K69-010
- EPA Est. Fuel Consumption
- 6.76 L/100km (34.8 US mpg)
- EPA CO Emissions
- 0.1 CO g/km
- Torque
- 114.0 Nm (11.6 kgf-m) @ 9250 RPM
- Engine type
- In-line four, four-stroke
- Fuel consumption
- 6.20 litres/100 km (16.1 km/l)
- Power/weight ratio
- 0.7917 HP/kg (dry)
- Bore x stroke
- 80.0 x 49.7 mm
- Compression
- 12.5:1
- Cooling system
- Liquid
- Fuel system
- Injection
- Starting
- Electric
- Aspiration
- Naturally aspirated
- Valves per cylinder
- 4
Transmission
- Gearbox
- 6-speed
- Transmission type
- Manual
- Final drive
- Chain
- Clutch
- Multiplate clutch in oil bath, slipper clutch, self-reinforcing
Performance
- Top speed
- 200.0 km/h (124.3 mph)
Dimensions & weight
- Wheelbase
- 1548 mm
- Overall length
- 2333 mm
- Overall width
- 917 mm
- Overall height
- 1411 mm
- Seat height
- 840 mm
- Dry weight
- 205.0 kg
- Wet weight
- 226.0 kg
- Fuel capacity
- 20.00 litres
- Oil capacity
- 3.50 litres
- Reserve fuel capacity
- 4.00 litres
- Carrying capacity
- Storage compartment underneath seat
Chassis & suspension
- Frame
- Aluminium composite bridge frame, partially self-supporting engine
- Front suspension
- Upside-down telescopic fork 46 mm, compression and rebound stage adjustable
- Rear suspension
- Aluminium 2-sided swing arm, rebound damping adjustable
- Front wheel travel
- 150 mm
- Rear wheel travel
- 150 mm
- Rake (fork angle)
- 25.5°
- Trail
- 117 mm
Brakes & wheels
- Front brakes
- Double disc. ABS. Floating discs. Four-piston calipers.
- Front brakes diameter
- 320 mm
- Rear brakes
- Single disc. ABS. Floating disc.
- Rear brakes diameter
- 265 mm
- ABS
- Yes
- Front tyre
- 120/70-ZR17
- Rear tyre
- 190/55-ZR17
Other
- Color options
- Racing Red uni/White Aluminium metallic matt, Ice Grey uni
- Fuel Tank Material
- Plastic
Compiled from manufacturer documentation and user contributions, corrected on an ongoing basis. Spotted something wrong? Tell us.
What changed, year to year
Differences highlighted| Specification | 2015 | 2018 | 2020 | 2021 | 2024 | 2027 |
|---|---|---|---|---|---|---|
| Capacity | 999 cc | 999 cc | 999 cc | 999 cc | 999 cc | 999 cc |
| Dry weight | 178 kg | 178 kg | 205 kg | 205 kg | 205 kg | 205 kg |
| Seat height | 840 mm | 840 mm | 840 mm | 790 mm | 851 mm | 851 mm |
| Fuel capacity | 20 L | 20 L | 20 L | 20 L | 19.7 L | 19.7 L |
Illustrative - generated automatically by diffing the year records already on file, not a manufacturer-published changelog.
Safety Recalls
⚠ 2 recalls may applyELECTRICAL SYSTEM:SOFTWAREFeb 2023 · 23V051000
BMW of North America, LLC (BMW) is recalling certain 2022-2023 S 1000R and 2020-2023 S 1000XR motorcycles. During a software update performed at a dealership, the "Dynamic Pro" riding mode feature "front wheel lift-off assistant" may have been inadvertently deactivated without alerting the rider.
Risk: Riding a motorcycle without knowing that the "front wheel lift-off assistant" has been deactivated can result in unexpected handling and control, increasing the risk of a crash.
Remedy: BMW will instruct owners to check the configuration settings in the "Dynamic Pro" riding mode and adjust the settings as needed. Dealers will also inspect the motorcycles, free of charge. Owner notification letters were mailed April 4, 2023. Owners may contact BMW customer service at 1-800-525-7417.
SERVICE BRAKES, HYDRAULIC:FOUNDATION COMPONENTS:DISC:CALIPERAug 2020 · 20V476000
BMW of North America, LLC (BMW) is recalling certain 2019-2020 R 1250 GS, GS Adventure and R 1250 RT, 2020 S 1000 RR and S 1000 XR motorcycles. The front brake calipers may leak brake fluid when parked. As such, these motorcycles fail to comply with the requirements of the Federal Motor Vehicle Safety Standard number 122, "Motorcycle Brake Systems."
Risk: Overtime, a leaking front brake caliper can reduce the amount of brake fluid in the reservoir. Low volume could affect brake performance, increasing the risk of crash.
Remedy: BMW will notify owners, and dealers will inspect and if necessary, replace the front brake calipers with an improved version, free of charge. BMW issued owners an interim notification on October 12, 2020. As of January 19, 2021, a remedy was still not available. The recall began March 8, 2021. Owners may contact BMW customer service at 1-800-525-7417.
These recalls cover some 2020 bikes of this model. Whether one applies to a specific bike, and whether the repair has already been done, depends on its VIN — check your VIN with NHTSA or ask a dealer.
Source: NHTSA. View all BMW recalls →
Rider Reviews
Common questions
What is the engine size of the BMW S 1000 XR?
The 2020 BMW S 1000 XR has a Capacity of 999.0 ccm (60.96 cubic inches).
What engine power does the BMW S 1000 XR have?
The 2020 BMW S 1000 XR has a Power of 162.3 HP (121.0 kW) @ 11000 RPM.
How many gears does the BMW S 1000 XR have?
The 2020 BMW S 1000 XR has a Gearbox of 6-speed.
What is the torque of the BMW S 1000 XR?
The 2020 BMW S 1000 XR has a Torque of 114.0 Nm (11.6 kgf-m or 84.1 ft.lbs) @ 9250 RPM.
How much does the BMW S 1000 XR weigh?
The 2020 BMW S 1000 XR has a Dry weight of 205.0 kg (451.9 pounds).
Shop this bike
Affiliate linksWe may earn a commission from qualifying eBay or Amazon purchases made through these links. As an Amazon Associate I earn from qualifying purchases.
The 2020 BMW S 1000 XR is a top-of-the-line adventure touring motorcycle that offers a perfect blend of performance and comfort. Equipped with a powerful 999cc engine, this bike delivers a thrilling riding experience with its smooth power delivery and excellent handling. The innovative electronic aids such as ABS, traction control, and dynamic damping control ensure a safe and controlled ride in all conditions. The S 1000 XR also comes packed with advanced features such as a multi-function instrument panel, LED headlights, and keyless ignition, making it a highly desirable option for riders looking for a high-performance touring motorcycle.
Overall, the 2020 BMW S 1000 XR is a fantastic choice for riders who want a versatile and capable motorcycle that excels in both performance and comfort. With its advanced technology and impressive power delivery, this bike offers a thrilling riding experience that is sure to impress even the most discerning riders. Whether you're hitting the open highway or tackling twisty mountain roads, the S 1000 XR delivers a truly exceptional riding experience that is hard to match.
