2001Cagiva Raptor 1000
39 fields on record
The 2001 Cagiva Raptor 1000 is an Italian naked bike powered by the Suzuki TL1000 V-twin. Its liquid-cooled 996cc V-twin makes 106 hp at 8,500 rpm and 90 Nm through a six-speed gearbox and chain, for a top speed of about 220 km/h. A low 770 mm seat, 192 kg dry weight and 18-litre tank complete it.
- Capacity
- 996.0 ccm
- Engine
- V-Twin, four-stroke
- Gearbox
- 6-speed
- Dry weight
- 192.0 kg
- Seat height
- 770 mm
- Power
- 106.0 HP (78.0 kW) @ 8500 RPM
How it rides
Editorial estimate from the spec sheet - not lab tested- Best for
- Built as a sharp-handling naked streetfighter, it excels at spirited road riding and carving through twisty back roads rather than long-distance cruising.
- Built for
- The Raptor 1000 blends Italian streetfighter aggression with agile handling, delivering a raw, engaging ride full of character rather than refined comfort.
- Not ideal for
- It is not well suited to riders seeking a plush, wind-protected long-haul tourer or a machine for serious off-road adventures.
Scores are derived from the spec sheet using the same model across every bike, so they compare like for like.
Will it fit you?
Worked out in your browser - nothing is sent to usEngine
- Capacity
- 996.0 ccm
- Power
- 106.0 HP (78.0 kW) @ 8500 RPM
- Torque
- 90.0 Nm (9.2 kgf-m) @ 7000 RPM
- Engine type
- V-Twin, four-stroke
- Power/weight ratio
- 0.5521 HP/kg (dry)
- Bore x stroke
- 98.0 x 66.0 mm
- Compression
- 11.3:1
- Cooling system
- Liquid
- Fuel system
- Injection
- Starting
- Electric
- Ignition
- Electronic
- Valves per cylinder
- 4
Transmission
- Gearbox
- 6-speed
- Transmission type
- Manual
- Final drive
- Chain
Performance
- Top speed
- 220.0 km/h (136.7 mph)
Dimensions & weight
- Wheelbase
- 1440 mm
- Overall length
- 2104 mm
- Overall width
- 800 mm
- Overall height
- 1090 mm
- Seat height
- 770 mm
- Dry weight
- 192.0 kg
- Fuel capacity
- 18.00 litres
- Ground clearance
- 140 mm
Chassis & suspension
- Frame
- High strength steel tubular frame
- Front suspension
- Upside Down telescopic hydraulic fork
- Rear suspension
- Progressive, single shock absorber with adjustable spring preload
- Front wheel travel
- 120 mm
- Rear wheel travel
- 138 mm
- Trail
- 102 mm
Brakes & wheels
- Front brakes
- Dual disc
- Front brakes diameter
- 298 mm
- Rear brakes
- Single disc
- Rear brakes diameter
- 220 mm
- Front tyre
- 120/70-17
- Rear tyre
- 180/50-17
Other
- Color options
- Red, silver
- Modifications compared to previous model
- The Raptor's engine is retrieved from the Suzuki TL 1000 R.
Compiled from manufacturer documentation and user contributions, corrected on an ongoing basis. Spotted something wrong? Tell us.
What changed, year to year
Differences highlighted| Specification | 2000 | 2001 | 2002 | 2003 | 2005 | 2006 |
|---|---|---|---|---|---|---|
| Capacity | 996 cc | 996 cc | 996 cc | 996 cc | 995 cc | 996 cc |
| Dry weight | 192 kg | 192 kg | 192 kg | 192 kg | 192 kg | 197 kg |
| Seat height | 770 mm | 770 mm | 775 mm | 775 mm | 805 mm | 805 mm |
| Fuel capacity | 18 L | 18 L | 15.2 L | 15.2 L | 15.2 L | 15.2 L |
Illustrative - generated automatically by diffing the year records already on file, not a manufacturer-published changelog.
Rider Reviews
Common questions
What is the engine size of the Cagiva Raptor 1000?
The 2001 Cagiva Raptor 1000 has a Capacity of 996.0 ccm (60.78 cubic inches).
What engine power does the Cagiva Raptor 1000 have?
The 2001 Cagiva Raptor 1000 has a Power of 106.0 HP (78.0 kW) @ 8500 RPM.
How many gears does the Cagiva Raptor 1000 have?
The 2001 Cagiva Raptor 1000 has a Gearbox of 6-speed.
What is the torque of the Cagiva Raptor 1000?
The 2001 Cagiva Raptor 1000 has a Torque of 90.0 Nm (9.2 kgf-m or 66.4 ft.lbs) @ 7000 RPM.
How much does the Cagiva Raptor 1000 weigh?
The 2001 Cagiva Raptor 1000 has a Dry weight of 192.0 kg (423.3 pounds).
