2012CCM C-Xr230
35 fields on record
The 2012 CCM C-XR230 is a lightweight enduro bike ideal for trail riders and beginners seeking versatility and easy handling. Its air-cooled single-cylinder four-stroke engine delivers manageable power with excellent fuel efficiency. Known for its nimble chassis and accessible performance, it excels in off-road exploration and mixed terrain riding.
- Capacity
- 230.0 ccm
- Engine
- Single, four-stroke
- Gearbox
- 4-speed
- Dry weight
- 118.0 kg
- Seat height
- 940 mm
- Power
- 18.0 HP (13.2 kW)
How it rides
Editorial estimate from the spec sheet - not lab tested- Best for
- Designed primarily for trail riding and light enduro use rather than speed or long-distance travel.
- Built for
- A nimble, uncomplicated single-cylinder trail bike that rewards momentum-based, playful riding over raw power.
- Not ideal for
- Not a good fit for riders seeking highway speed, passenger comfort, or long paved touring distances.
Scores are derived from the spec sheet using the same model across every bike, so they compare like for like.
Will it fit you?
Worked out in your browser - nothing is sent to usEngine
- Capacity
- 230.0 ccm
- Power
- 18.0 HP (13.2 kW)
- CO2 Emissions
- 3 CO2 g/km
- Engine type
- Single, four-stroke
- Power/weight ratio
- 0.1525 HP/kg (dry)
- Bore x stroke
- 67.0 x 65.0 mm
- Compression
- 9.2:1
- Cooling system
- Air
- Fuel system
- Carburettor
- Starting
- Electric
- Ignition
- CDI
- Valves per cylinder
- 2
- Lubrication system
- Wet Sump
- Torque
- Not on record - add it
Transmission
- Gearbox
- 4-speed
- Transmission type
- Manual
- Final drive
- Chain
- Clutch
- Wet, 5-plate
Dimensions & weight
- Wheelbase
- 1350 mm
- Seat height
- 940 mm
- Dry weight
- 118.0 kg
- Wet weight
- 129.0 kg
- Fuel capacity
- 8.80 litres
- Ground clearance
- 340 mm
Chassis & suspension
- Frame
- Tubular welded steel. Cast / welded aluminium swing arm.
- Front suspension
- Conventional fork, 40mm
- Rear suspension
- Single shock - adjustable preload
- Front wheel travel
- 240 mm
Brakes & wheels
- Front brakes
- Single disc
- Front brakes diameter
- 210 mm
- Rear brakes
- Single disc
- Rear brakes diameter
- 180 mm
- Front tyre
- 2.50-21
- Rear tyre
- 3.00-18
Other
- Color options
- White/red
Compiled from manufacturer documentation and user contributions, corrected on an ongoing basis. Spotted something wrong? Tell us.
What changed, year to year
Differences highlighted| Specification | 2012 | 2013 |
|---|---|---|
| Capacity | 230 cc | 230 cc |
| Dry weight | 118 kg | 118 kg |
| Seat height | 940 mm | 940 mm |
| Fuel capacity | 8.8 L | 8.8 L |
Illustrative - generated automatically by diffing the year records already on file, not a manufacturer-published changelog.
Rider Reviews
Common questions
What is the engine size of the CCM C-Xr230?
The 2012 CCM C-Xr230 has a Capacity of 230.0 ccm (14.04 cubic inches).
What engine power does the CCM C-Xr230 have?
The 2012 CCM C-Xr230 has a Power of 18.0 HP (13.2 kW).
How many gears does the CCM C-Xr230 have?
The 2012 CCM C-Xr230 has a Gearbox of 4-speed.
How much does the CCM C-Xr230 weigh?
The 2012 CCM C-Xr230 has a Dry weight of 118.0 kg (260.1 pounds).
