Supermotos
2009CCM R35
30 fields on record
The 2009 CCM R35 is a lightweight supermotard powered by a 398cc single-cylinder engine producing 40 horsepower, ideal for riders seeking nimble handling and versatile street-to-dirt capability. Its carburetted DOHC design and dry sump lubrication deliver reliable, characterful performance favored by enthusiasts valuing mechanical simplicity and agility over raw power.
- Capacity
- 398.0 ccm
- Engine
- Single, four-stroke
- Gearbox
- 5-speed
- Dry weight
- 128.0 kg
- Seat height
- 800 mm
- Power
- 40.0 HP (29.4 kW)
What’s new for the 2009 CCM R35
vs the 2008| Spec | 2008 | 2009 |
|---|---|---|
| Seat height | 830 mm (32.7 inches) | 800 mm (31.5 inches) |
| Front brakes | Single disc | Single disc. Brembo single piston |
| Rear brakes | Single disc | Single disc. Brembo single piston |
How it rides
Editorial estimate from the spec sheet - not lab tested- Best for
- Built for supermotard fun: flickable cornering, tight city darting, and sharp handling over outright speed or distance comfort.
- Built for
- A raw, agile, and characterful machine that rewards an aggressive, engaged riding style rather than relaxed cruising.
- Not ideal for
- Not for riders seeking long-distance comfort, pillion-friendly touring, or high-speed motorway cruising.
Scores are derived from the spec sheet using the same model across every bike, so they compare like for like.
Will it fit you?
Worked out in your browser - nothing is sent to usEngine
- Capacity
- 398.0 ccm
- Power
- 40.0 HP (29.4 kW)
- Engine type
- Single, four-stroke
- Power/weight ratio
- 0.3125 HP/kg (dry)
- Bore x stroke
- 90.0 x 62.6 mm
- Compression
- 12.2:1
- Cooling system
- Liquid
- Fuel system
- Carburettor
- Starting
- Electric
- Ignition
- CDI
- Valves per cylinder
- 4
- Lubrication system
- Dry Sump
- Torque
- Not on record - add it
Transmission
- Gearbox
- 5-speed
- Transmission type
- Manual
- Final drive
- Chain
Dimensions & weight
- Seat height
- 800 mm
- Dry weight
- 128.0 kg
- Wet weight
- 143.0 kg
- Fuel capacity
- 12.00 litres
Chassis & suspension
- Frame
- Steel tubular.
- Front suspension
- WP 43mm upside down
- Rear suspension
- WP PDS
Brakes & wheels
- Front brakes
- Single disc. Brembo single piston
- Front brakes diameter
- 320 mm
- Rear brakes
- Single disc. Brembo single piston
- Rear brakes diameter
- 260 mm
- Front tyre
- 120/70-17
- Rear tyre
- 150/70-17
Other
- Color options
- Blue
Compiled from manufacturer documentation and user contributions, corrected on an ongoing basis. Spotted something wrong? Tell us.
What changed, year to year
Differences highlighted| Specification | 2007 | 2009 | 2010 | 2012 | 2013 |
|---|---|---|---|---|---|
| Capacity | 398 cc | 398 cc | 398 cc | 398 cc | 398 cc |
| Dry weight | 132 kg | 128 kg | 128 kg | 128 kg | 128 kg |
| Seat height | 830 mm | 800 mm | 890 mm | 890 mm | 890 mm |
| Fuel capacity | 12 L | 12 L | 12 L | 12 L | 12 L |
Illustrative - generated automatically by diffing the year records already on file, not a manufacturer-published changelog.
Rider Reviews
Common questions
What is the engine size of the CCM R35?
The 2009 CCM R35 has a Capacity of 398.0 ccm (24.29 cubic inches).
What engine power does the CCM R35 have?
The 2009 CCM R35 has a Power of 40.0 HP (29.4 kW).
How many gears does the CCM R35 have?
The 2009 CCM R35 has a Gearbox of 5-speed.
How much does the CCM R35 weigh?
The 2009 CCM R35 has a Dry weight of 128.0 kg (282.2 pounds).
